nader NDM2 Series Product Manual page 16

6.3 断路器叠装之间最小距离
6.3 Minimum center distance between stacked circuit breakers
NDM2-63
NDM2(X)- 125
NDM2-250
NDM2-400
NDM2-630
NDM2-800
注：1、电缆绝缘联接
2、联接且无绝缘
3、产品通电前检查端子罩或相间隔板装配到位。
Note: 1. Cable insulating connection
2. Connection without insulation
3. Check whether the terminal cover or phase partition is assembled
properly before products are energized.
地址：上海市浦东新区申江南路 2000 号
文件编号：NDT2920016
H(断路器上下距离)
H (distance of circuit breaker from bottom)
带端子罩
With a terminal cover
90
90
90
155
155
155
邮编：201315
第 16 页 共 24 页
不带端子罩
Without a terminal cover
90
91
93
155
155
155
