BenQ G Series User Manual

Stylish monitor with eye care technology
Hide thumbs Also See for G Series:
Table of Contents

Advertisement

Quick Links

LCD Monitor
User Manual
Stylish Monitor with Eye Care Technology | G Series
https://tm.by
Интернет-магазин TM.by

Advertisement

Table of Contents
loading

Related Manuals for BenQ G Series

Summary of Contents for BenQ G Series

  • Page 1 LCD Monitor User Manual Stylish Monitor with Eye Care Technology | G Series https://tm.by Интернет-магазин TM.by...

  • Page 2: Copyright

    (Applicable for flicker-free models only.) BenQ ecoFACTS BenQ has been dedicated to the design and development of greener product as part of its aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision with the ultimate goal to achieve a low-carbon society.

  • Page 3: Product Support

    BenQ to ensure compatibility. Do not disassemble the product unless you are aware of the consequences. If you cannot find the dismantled information on your product, contact the local customer service for assistance.
  • Page 4 • An approved power cord greater or equal to H03VV-F or H05VV-F, 2G or 3G, 0.75mm must be used. • Use only the power cord provided by BenQ. Never use a power cord that appears to be damaged or frayed. For Germany only: •...
  • Page 5 If any of the above mentioned misuse or other accident such as dropping or mishandling occurs, contact qualified service personnel for servicing. • Contact your place of purchase or visit the local website from Support.BenQ.com for more support. Caution •...
  • Page 6 Typographics Icon / Symbol Item Meaning Warning Information mainly to prevent the damage to components, data, or personal injury caused by misuse and improper operation or behavior. Useful information for completing a task. Note Supplementary information. In this document, the steps needed to reach a menu may be shown in condensed form, for example: Menu >...

  • Page 7: Table Of Contents

    Viewing angle adjustment ........................33 Using the monitor wall mounting kit ....................34 Getting the most from your BenQ monitor ..............35 Downloading the LCD Monitor driver files from the Internet ............. 35 How to install the monitor on a new computer ................36 How to upgrade the monitor on an existing computer ..............
  • Page 8 Picture Advanced menu ......................... 53 Audio menu ............................... 56 System menu ............................. 57 Troubleshooting ........................60 Frequently asked questions (FAQ) ...................... 60 Need more help?............................62 12/17/20 G80-EM-V2 https://tm.by Интернет-магазин TM.by...

  • Page 9: Getting Started

    Getting started When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. BenQ LCD Monitor (Models with height adjustment stand) (Models with Bright Intelligence function) (Models with standard bezel)
  • Page 10 Monitor Base (for models without height adjustment stand) Monitor Base (for models with height adjustment stand) Quick Start Guide Safety Instructions Regulatory Statements Power Cord (Supplied item may differ by model or region.) Video Cable: D-Sub (Optional accessory) Video Cable: DVI-D (Optional accessory) Getting started https://tm.by...
  • Page 11 Video Cable: HDMI (Optional accessory) Video Cable: DP (Optional accessory) Audio Cable (Optional accessory) • Available accessories and the pictures shown here may differ from the actual contents and the product supplied for your region. And the package contents may subject to change without prior notice. For cables that are not supplied with your product, you can purchase them separately.

  • Page 12: Getting To Know Your Monitor

    Getting to know your monitor Front view (Models with Bright Intelligence function) (Models with standard bezel) (Models with 16:10 aspect ratio) (Models without Bright Intelligence function) 3 3 4 1. Light sensor (available for models with Bright Intelligence) 2. Control buttons 3.

  • Page 13: Back View

    Back view 1. Input and output ports (vary by model, see Input and output ports on page 2. Stand release 3. Cable cover 4. Kensington lock slot LINE IN D-SUB • Above diagram may vary depending on the model. • Picture may differ from product supplied for your region. Input and output ports Available input and output ports may vary depending on your purchased model.
  • Page 14 GW2280 / GW2283 1. AC power input jack 2. DisplayPort socket LINE IN D-SUB 3. HDMI socket 4. D-Sub socket GL2780 5. Audio Line In 6. Headphone jack 7. DVI-D socket 4 5 6 Getting to know your monitor https://tm.by Интернет-магазин...

  • Page 15: Connections

    Connections The following connection illustrations are for your reference only. For cables that are not supplied with your product, you can purchase them separately. For detailed connection methods, see page - 22. GW2381 / GW2480 / GW2480T / GW2780 / GW2780T LINE IN D-SUB Speakers /...
  • Page 16 LINE IN D-SUB GL2580HM GL2480 / GL2580H Speakers / Speakers / Headphone Headphone PC / Notebook PC / Notebook Getting to know your monitor https://tm.by Интернет-магазин TM.by...
  • Page 17 GW2280 / GW2283 LINE IN D-SUB Speakers / Headphone PC / Notebook Getting to know your monitor https://tm.by Интернет-магазин TM.by...
  • Page 18 GL2780 Speakers / Headphone PC / Notebook The location and available input and output jacks may vary depending on the purchased model. Getting to know your monitor https://tm.by Интернет-магазин TM.by...

  • Page 19: How To Assemble Your Monitor Hardware (For Models Without Height Adjustment Stand)

    How to assemble your monitor hardware (for models without height adjustment stand) • If the computer is turned on you must turn it off before continuing. • Do not plug-in or turn-on the power to the monitor until instructed to do so. •...
  • Page 20 Tighten the thumbscrew on the bottom of the monitor base as illustrated. Orient and align the stand arm with the monitor, then push them together until they click and lock into place. Carefully lift the monitor, turn it over and place it upright on its stand on a flat even surface.
  • Page 21 2. Remove the cover of the cable management system. The stand arm also works as a cable management system that helps keep the cables neat and clean. Slide the cable cover up to align the marking on the cable cover with the unlock icon on the stand arm. Remove the cover as illustrated.
  • Page 22 To Connect the D-Sub Cable Pass the cable through the cable management hole on the stand arm first. Connect the plug of the D-Sub cable (at the end without the ferrite filter) to the monitor video socket. Connect the other end of the cable (at LINE IN D-SUB the end with the ferrite filter) to the computer video...
  • Page 23 Follow the instructions in Getting the most from your BenQ monitor on page 35 to install the monitor software. To extend the service life of the product, we recommend that you use your computer's power management function.

  • Page 24: How To Detach The Stand And The Base

    How to detach the stand and the base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like a towel on the desk for padding, before laying the screen face down on a flat clean padded surface.
  • Page 25 3. Remove the monitor base. Release the thumbscrew on the bottom of the monitor base and detach the monitor base as illustrated. How to assemble your monitor hardware (for models without height adjustment stand) https://tm.by Интернет-магазин TM.by...

  • Page 26: Using The Monitor Wall Mounting Kit (For Models Without Height Adjustment Stand)

    Using the monitor wall mounting kit (for models without height adjustment stand) The back of your LCD monitor has a VESA standard mount with 100mm pattern, allowing the installation of a wall mount bracket. Before starting to install a monitor wall mounting kit, please read the precautions carefully.
  • Page 27 Use four M4 x 10 mm screws to fix a VESA standard wall mount bracket to the monitor. Make sure that all screws are tightened and secured properly. Consult a professional technician or BenQ service for wall mount installation and safety precautions. How to assemble your monitor hardware https://tm.by...

  • Page 28: Assembling Your Monitor With A Height Adjustment Stand

    Assembling your monitor with a height adjustment stand How to attach the monitor base • If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. •...
  • Page 29 You might want to adjust the monitor stand height. See Adjusting the monitor height on page 31 for more information. Your monitor is an edge to edge monitor and should be handled with care. Adjust the screen angle by placing your hands on the top and on the base of the monitor as illustrated.

  • Page 30: How To Detach The Base

    How to detach the base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. Gently lift the display up and extend the stand to the maximum extended position.

  • Page 31: Adjusting The Monitor Height

    Adjusting the monitor height To adjust the monitor height, hold both the top and the bottom of the monitor to lower the monitor or lift it up to the desired height. • Avoid placing hands on the upper or lower part of the height-adjustable stand or at the bottom of the monitor, as ascending or descending monitor might cause personal injuries.

  • Page 32: Rotating The Monitor

    Rotating the monitor 1. Pivot the display. Before rotating the monitor with a portrait viewing orientation, the display has to be rotated 90 degrees. Right-click the desktop and select Screen resolution from the popup menu. Select Portrait in Orientation, and apply the setting. Depending on the operation system on your PC, different procedures should be followed to adjust the screen orientation.

  • Page 33: Viewing Angle Adjustment

    4. Adjust the monitor to the desired viewing angle. Viewing angle adjustment You may position the screen to the desired angle with monitor tilt, swivel, and height adjustment functions. Refer to the product specifications on the website for details. Assembling your monitor with a height adjustment stand https://tm.by Интернет-магазин...

  • Page 34: Using The Monitor Wall Mounting Kit

    Use four M4 x 10 mm screws to fix a VESA standard wall mount bracket to the monitor. Make sure that all screws are tightened and secured properly. Consult a professional technician or BenQ service for wall mount installation and safety precautions. Assembling your monitor with a height adjustment stand https://tm.by...

  • Page 35: Getting The Most From Your Benq Monitor

    Getting the most from your BenQ monitor To gain the most benefit from your new BenQ LCD monitor, you should install the custom BenQ LCD Monitor driver software as provided on the local website. See Downloading the LCD Monitor driver files from the Internet on page 35 for details.

  • Page 36: How To Install The Monitor On A New Computer

    BenQ LCD Monitor is the first ever monitor to be connected to it. If you are adding the BenQ LCD Monitor to an existing computer that has already had another monitor connected to it (and has monitor driver software installed), you should not be following these instructions. You...

  • Page 37: How To Upgrade The Monitor On An Existing Computer

    The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems.

  • Page 38: How To Install On Windows 10 System

    Internet as instructed in Browse Downloading the LCD Monitor driver files from the Internet on page 8. Click Close You may be prompted to restart your computer after the driver update is complete. Getting the most from your BenQ monitor https://tm.by Интернет-магазин TM.by...

  • Page 39: How To Install On Windows 8 (8.1) System

    Internet as instructed in Browse Downloading the LCD Monitor driver files from the Internet on page 8. Click Close You may be prompted to restart your computer after the driver update is complete. Getting the most from your BenQ monitor https://tm.by Интернет-магазин TM.by...

  • Page 40: How To Install On Windows 7 System

    Internet as instructed in Browse Downloading the LCD Monitor driver files from the Internet on page 8. Click Close You may be prompted to restart your computer after the driver update is complete. Getting the most from your BenQ monitor https://tm.by Интернет-магазин TM.by...

  • Page 41: How To Adjust Your Monitor

    How to adjust your monitor The control panel Name Description Control keys Accesses the functions or menu items displayed on the screen, right next to each key. Power key Turns the power on or off. How to adjust your monitor https://tm.by Интернет-магазин...

  • Page 42: Basic Menu Operation

    Basic menu operation All OSD (On Screen Display) menus can be accessed by the control keys. You can use the OSD menu to adjust all the settings on your monitor. 1. Press any of the control keys. 2. The hot key menu is displayed. The left three controls are custom keys and are designated for particular functions.
  • Page 43 OSD icon OSD in hot key in main Function menu menu • By default, the key is the hot key for . To change Custom Key 2 Input the default settings, see Customizing the hot keys on page (GL2480 / GL2780) By default, the key is the hot key .

  • Page 44: Picture Optimization

    If you wish, you can always adjust the screen geometric settings manually using geometry menu items. To assist you in this endeavour, BenQ has provided a screen test image utility which you can use to check for screen color, grayscale and line gradient display. The utility is available on the website.

  • Page 45: Choosing An Appropriate Picture Mode

    Choosing an appropriate picture mode Your monitor provides various picture modes that are suitable for different types of images. Picture Mode on page 53 for all the available picture modes. Go to for a desired picture mode. Picture Advanced Picture Mode is preferred, select to enable it.

  • Page 46: Navigating The Main Menu

    Navigating the main menu You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor. Press any of the control keys to bring up the hot key menu, and press to access the (Menu) main menu.

  • Page 47: Eye Care Menu (Selected Models Only)

    Eye Care menu (selected models only) Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
  • Page 48 (Models with Color Weakness function) Item Function Range Bright Turns the Bright Intelligence function on or off. The built-in • Intelligence light sensor works with Bright Intelligence technology to • detect the ambient light, image brightness and contrast, and then balance the screen automatically. Sets to display the light condition around the •...

  • Page 49: Display Menu

    Display menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
  • Page 50 Item Function Range Use this to change the input to that appropriate to • Input D-Sub your video cable connection type. • (for models with DP inputs) • (for models with DVI inputs) • HDMI Adjusts the horizontal position of the screen image. 0 to 100 H.

  • Page 51: Picture Menu

    Picture menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
  • Page 52 Item Function Range Adjusts the tone luminance. The default value is 3 (the • Gamma standard value for Windows). • • • • Color Allows video and still photographs to be viewed Normal Temperature with natural coloring. This is the factory default color.

  • Page 53: Picture Advanced Menu

    Picture Advanced menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
  • Page 54 Item Function Range Low Blue Decreases the blue light emitted from the display to Light reduce the risk of blue light exposure to your eyes. (Models without The value for each mode indicates how Low Blue Light Color much blue light is decreased compared with the Standard Weakness mode.
  • Page 55 Item Function Range Slightly enlarges the input image. Use this feature to hide annoying • ON Overscan edge noise if present around your image. • OFF Available only when the input source is HDMI or D-Sub (VGA converted from Component). Display This feature is provided to allow aspect ratios other than 16:9 or Mode...

  • Page 56: Audio Menu

    Audio menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.

  • Page 57: System Menu

    System menu Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. For models without certain functions, their settings and related items will not appear on the menu.
  • Page 58 Item Function Range Sets the OSD menu language. • Language English Settings • Français The language options displayed on your OSD may • Deutsch differ from those shown on the right, depending • Italiano on the product supplied in your region. •...
  • Page 59 Item Function Range Sets the function to be accessed by custom key 1. • Custom Key Picture Mode • Low Blue Light Custom Key Sets the function to be accessed by custom key 2. • Display Mode • Brightness Custom Key Sets the function to be accessed by custom key 3.

  • Page 60: Troubleshooting

    Troubleshooting Frequently asked questions (FAQ) Imaging The image is blurred. • Download file from the website (see Product support on page 3). Refer to Resolution " ". And then select the correct resolution, refresh rate Adjusting the Screen Resolution and make adjustments based on these instructions. •...
  • Page 61 You are running the monitor at its native resolution, but the image is still distorted. Images from different input sources may appear distorted or stretched on the monitor running at its native resolution. To have the optimal display performance of each type of input sources, you can use the function to set a proper aspect ratio for the input sources.

  • Page 62: Need More Help

    Need more help? If your problems remain after checking this manual, please contact your place of purchase or visit the local website from Support.BenQ.com for more support and local customer service. Troubleshooting https://tm.by Интернет-магазин TM.by...

This manual is also suitable for:

Gw2280Gw2280eGw2283Gw2480Gw2480eGw2480t ... Show all
