ＷＰ２－２００A
This document was formulated in Japan. Comply with the
regulations and standards of the country of usage.
The specifications of products and components may vary
with country of usage and the site situation.
INFORMATION IN THIS MANUAL MAY BE CHANGED
WITHOUT NOTICE.
MIURA CO., LTD.
Manual Code No.
S836-583-8010
Advertisement
Table of Contents
Related Manuals for Miura WP2-200A
Summary of Contents for Miura WP2-200A
- Page 1 The specifications of products and components may vary with country of usage and the site situation. INFORMATION IN THIS MANUAL MAY BE CHANGED WITHOUT NOTICE. MIURA CO., LTD. Manual Code No. S836-583-8010...
- Page 2 In order that your MIURA water treatment equipment can be put to safe and reliable use, it is crucial that in addition to fulfilling these legal obligations, you also establish and implement a safety management system.
- Page 3 3) The documents to be submitted and their destination vary depending on your equipment and facilities. If you have any questions, contact your nearest dealer, MIURA sales office, or the competent supervisory authority. 4) The laws and regulations listed below may not apply to all water treatment equipment. Refer only to those laws and regulations that apply to your equipment and facilities.
- Page 4 Introduction This document is an instruction manual for transport and installation of the water treatment control board for boiler WP2-200A (hereinafter,”the control board”). When installing the Unit, read and understand this manual well and install it safely. In this manual, risk and damage associated with the Unit are classified in the following three levels.
-
Page 5: Table Of Contents
Document No.: Ｓ８３６－５８３－８０１０ Table of Contents Preparation for Installation ························································································· 1 Checking the Installation Location ············································································· 1 Wearing Protective Equipment ················································································· 1 Checking the Model ······························································································· 1 Checking the Provided Items ··················································································· 2 Carrying the Control Board ························································································ 2 Dimensions and Mass ···························································································· 2 Carrying the Control Board ······················································································... -
Page 6: Preparation For Installation
Note) The control board cannot be connected to M-NET. Over the M-NET3 communication line, water treatment equipment information can be transmitted to the boiler room operation panel (BP-201) and central management system (Miura Intelligence Flexibility System), and communications with a MIURA office can be performed. Note 3 The rated power consumption does not include the power consumption of external connected devices, such as chemical feeders. -
Page 7: Checking The Provided Items
1.4 Checking the Provided Items The provided items are listed in the table below. Table 1-2: Provided items Model Part name WP2-200A Main unit Operation Manual Note 1: Anchor bolts and wiring materials required for installation and wiring are to be procured on site. -
Page 8: Installation
Document No.: Ｓ８３６－５８３－８０１０ 3. Installation 3.1 Installation Location and Space WARNING Do not install on a wooden wall or a wall that may corrode. Fix the equipment securely using the specified anchor bolts. If the equipment falls, it may cause injury. 1) Ensure that adequate space is available to work with the control box door open for adjustment or maintenance. -
Page 9: Electrical Wiring
Document No.: Ｓ８３６－５８３－８０１０ 4. Electrical Wiring WARNING Do not operate the power switch with wet hands. Failure to observe this precaution may lead to electric shocks. During power source installation work, use a specified wire diameter for connection and ensure that a ground is established. (Japanese D-class grounding (third-class grounding) or better) Furthermore, a dedicated power supply should be used and an earth leakage circuit breaker (with overcurrent protection) should be set up. -
Page 10: Electrical Wiring Guidelines
For general details about the electrical wiring, refer to the “Wiring” diagrams at the end of this manual. 4.2 Bar Terminals and Tools Use the following bar terminals specified by MIURA according to each wire diameter for the terminal processing of the signal wires connected to a circuit board. Table 4-1: Bar terminals... - Page 11 Document No.: Ｓ８３６－５８３－８０１０ Use the appropriate crimp tool from the table below. Table 4-3: Crimp tools for bar terminals Applicable Crimped wire Crimp tool Manufacturer Model No. terminal range Ferrule WAGO 206-204 AWG24 to 12 PHOENIX CRIMPFOX6 AWG24 to 10 CONTACT Center-pin bar terminal...
-
Page 12: List Of Alarms
Document No.: Ｓ８３６－５８３－８０１０ 5. List of Alarms 5.1 Alarms Evaluated in the Control Board Manual reset Alarm Effect on Integrated Alarm symptom Event information User Maintenance code operation output mode mode Feed water ○ A200-09 Feed water tank low water level ×... - Page 13 Document No.: Ｓ８３６－５８３－８０１０ Manual reset Alarm Alarm Effect on Integrated Event information User Maintenance symptom code operation output mode mode Condensate temperature out of ○ ○ F220-01 × normal range (low) Drain check Condensate temperature ○ ○ F220-02 × out of normal range (high) Control check F500-01 Memory data check (RAM) ×...
-
Page 14: Alarm Notifications From Monitored Equipment
Document No.: Ｓ８３６－５８３－８０１０ 5.2 Alarm Notifications from Monitored Equipment Alarms from equipment connected via DS-NET can be notified by the control board. The alarm is reset when it is confirmed at the equipment where it was evaluated. Effect Manual reset Alarm Alarm Integrated... - Page 15 (AWG14 or larger CV cable (or equivalent)). WARNING Check When installing the WP2-200A, use this checksheet to ensure correct installation. Incorrect installation may result in a serious accident. (For details about other installation precautions that are not listed in this checksheet, read the Installation Manual.)
