MIURA_CONFIDENTIAL
START-UP OPERATION
MANUAL
Boiler Operation Terminal
EJ-210
Electric Technical Department

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EJ-210 and is the answer not in the manual?

Questions and answers

Related Manuals for Miura EJ-210

Summary of Contents for Miura EJ-210

  • Page 1 MIURA_CONFIDENTIAL START-UP OPERATION MANUAL Boiler Operation Terminal EJ-210 Electric Technical Department...
  • Page 2 MIURA_CONFIDENTIAL Introduction When performing the start-up operation of EJ-210, the documents described below are required in addition to this Start-up Operation Manual. Document name Manual No. Application Installation Manual This manual is required when checking the installation JPSD-03081 (EJ-210 for North America)

  • Page 3: Table Of Contents

    4. OPERATION CHECK ....................27 4.1 Checking the Communication between the EJ-210 and the Boiler ........27 4.2 Checking the Communication between the EJ-210 and the Boiler System Operation Panel BP-201 ............................ 28 4.3 Checking the Operation of MI Control and Boiler Combustion Control ........29...

  • Page 4: Before Performing The Start-Up Operation

    For details, refer to “6. WIRING” in the Installation Manual of the EJ-210. (3) Wiring check With reference to “6. WIRING” in the Installation Manual of the EJ-210, ensure that the following wires are connected properly. • Power supply wire and signal wire Note that the wiring inside the boiler control box must be added or removed in some cases.

  • Page 5: Ej-210 Internal Layout

    Terminal block Terminal block Terminal block M-NET3 connector Figure 1-1: EJ-210 internal layout 1.3 EJ-210 Circuit Board Configuration OPR board CN10 CN4-2 Switching power supply CPU board RS-422 wire EC11 I/O board Battery M-NET3 cable Figure 1-2: EJ-210 circuit board configuration...

  • Page 6: Indicators And Controls

    “Data” button ▼ button Turns ON when an Used to switch display Used to change alarm occurs. items, clear alarm parameters and displays, and confirm decrease values in setting values. each mode, and select individual letters. Figure 1-3:Overview of EJ-210...

  • Page 7: Display Items

    (1) Explanation of display items and modes The status monitor and settings of the EJ-210 and boiler are shown on the display. The mode is categorized according to the display item content, and the display switches to each mode by button operation, etc.
  • Page 8 Program Version Ver: EJ211000 DATA Press and hold Function-1 switch is turned OFF, or no operation is ▲ ▼ together for 3 seconds performed for 4 minutes while Function-1 switch is OFF Figure 2-1: EJ-210 display status transition diagram (for Asia)
  • Page 9 Ver: EJ211000 DATA DATA Press and hold Function-1 switch is turned OFF, or no operation is ▲ ▼ together for 3 seconds performed for 4 minutes while Function-1 switch is OFF Figure 2-2: EJ-210 display status transition diagram (for North America)

  • Page 10: Explanation Of Each Mode

    2.2.1 Status Monitor Mode This mode is used to display and check the status of the EJ-210 or boiler. The control status of the equipment is displayed in the upper row of the display, and various status information of the equipment is displayed in the lower row.
  • Page 11 Note 5: For “Number of errors in communication with boiler system operation panel”, the total number of errors in the communication between the EJ-210 and the boiler system operation panel BP-201 during the current one hour (being counted) up to the next “00 minute” and past 23 hours is displayed.

  • Page 12: User Operation Mode

    MIURA_CONFIDENTIAL 2.2.2 User Operation Mode This mode is used to make settings that can be changed by the user. Press and hold the “Data” button for 2 seconds while “UserOPRMode / Press&Hold[DATA]” is displayed to switch the display to No. 1 in Table 2-4. The setting items are displayed in the upper row, while the setting values are displayed in the lower row.

  • Page 13: Current Alarm Check Mode

    MIURA_CONFIDENTIAL 2.2.3 Current Alarm Check Mode This mode is used to check the current alarm. Press and hold the “Data” button for 2 seconds while “CURR   Mode / Press&Hold[DATA]” is displayed to switch the display to the items shown in Table 2-5. The control status and judgment time when an alarm is judged are displayed in the upper row, while the current alarm serial number and alarm code are displayed in the lower row.

  • Page 14: Alarm History Mode

    MIURA_CONFIDENTIAL 2.2.4 Alarm History Mode This mode is used to check the history of alarms judged in the past. Press and hold the “Data” button for 2 seconds while “ALM  History / Press&Hold[DATA]” is displayed to switch the display to the items shown in Table 2-7 The control status when an alarm is judged is displayed in the upper row, while the current alarm serial number and alarm code are displayed in the lower row.

  • Page 15: Maintenance Operation Mode

    MIURA_CONFIDENTIAL 2.2.5 Maintenance Operation Mode This mode is used to perform maintenance operations and make settings with regard to MI control. To switch the display to No. 1 in Table 2-8, turn ON the Function-1 switch on the CPU board while the Monitor mode is displayed, or press and hold the ▲...

  • Page 16: Maintenance Setting Mode

    EJ-210. The EJ-210 collects the setting information from the boiler through communication, and the boiler setting items included in the EJ-210 settings are set automatically using this setting information. Table 2-9: Display items (Auto Setting mode)
  • Page 17 MIURA_CONFIDENTIAL 2.2.6.2 Manual Setting Mode Press the “Data” button while “ ” is displayed to switch the      [▼] Auto Setting / Press & Hold display to No. 1 in Table 2-11. Table 2-11: Display items (Manual Setting mode) Default Setting Item name...
  • Page 18 MIURA_CONFIDENTIAL (3) Blowdown setting (when <Blowdown> is selected) Default Setting Item name Setting item Setting range value increment   B l o wd o wn N o ti c e ― Blowdown notification Yes, No              # # # ...

  • Page 19: Ej-210 Main Unit Setting And Check

    3. EJ-210 MAIN UNIT SETTING AND CHECK Remove the cover of the boiler operation terminalEJ-210, and then perform the setting and check described below. 3.1 CPU Board Switch Settings Set the switches of the EJ-210 as shown in the table below. NET_No. ID_No. Initialize Function ×10...
  • Page 20 OFF. 4) Turn OFF the Initialize-1 switch. If “All clear” is performed, the entire information maintained in the EJ-210 is set to the default value. In order to control the EJ-210, the entire data must be set again.

  • Page 21: Backup Battery Check

    MIURA_CONFIDENTIAL 3.2 Backup Battery Check Before turning ON the EJ-210, check that the backup battery (lithium battery) inside the control box is connected properly. The battery life is approximately 3 years. Therefore, replace the battery every 3 years. 3.3 Display Operation Setting Make all settings necessary for MI control through display operations.
  • Page 22 MIURA_CONFIDENTIAL  Alarm History mode (refer to “2.2.4Alarm History ”) Mode • Even alarms that are not disclosed to the user are displayed. • The event information can be checked. Note: Information that is not disclosed to the user is displayed when this item is set to “Yes”. Therefore, after maintenance has ended, be sure to set this item to “No”, and ensure that flashing of “M...

  • Page 23: Settings In The Maintenance Setting Mode

    BP-201. Set this item to “No” if combustion control is to be performed based on the pressure setting value set in the boiler or the EJ-210. Combustion control is performed in the boiler alone, separately from MI control.
  • Page 24 During MI control, control is performed in consideration of the boiler steam output. Set the equivalent output of the boiler to which the EJ-210 is to be connected. In the case of a boiler with a BG-type or XJ1-type controller mounted, the steam output set in the boiler is set in the Automatic Setting mode.
  • Page 25 The setting value is disabled when “Blowdown notification” is set to “No” in a boiler other than the boilers with a BG-type, BK-type, BL-type, and XJ1-type controller mounted. Note that in the EJ-210, priority combustion is performed by judging that a blowdown has been performed under the following conditions.
  • Page 26 MIURA_CONFIDENTIAL (12) Pressure sensor full scale This item is for setting the full scale value when the optional pressure sensor for the EJ-210 is connected. Set the full scale value of the pressure sensor to be connected to the EJ-210 according to the table shown below.

  • Page 27: Settings In The User Operation Mode

    This item is used for pressure control, when “Manual” operation is performed in the EJ-210. In a boiler with a BG-type, BL-type, or XJ1-type controller mounted, or a boiler in which “Pressure sensor” is set to “Yes” in the EJ-210, make the setting according to the usage conditions of the customer.

  • Page 28: Boiler Pressure Settings

    As for the boiler pressure setting, it is necessary to set a slightly higher pressure value so that MI control by the boiler system operation panel BP-201 (and the EJ-210) is not hindered. To ensure that all conditions of boiler pressure settings shown below are satisfied, set the pressure based on the boiler steam pressure switch or steam pressure sensor.

  • Page 29: Operation Check

    4.1 Checking the Communication between the EJ-210 and the Boiler Check the detection status of the input of each signal from the boiler, as well as the communication status between the EJ-210 and the boiler. Set “Maintenance display” to “Yes”, and then check the following.

  • Page 30: Checking The Communication Between The Ej-210 And The Boiler System Operation Panel Bp-201

    Note 1: If a communication error occurs between the EJ-210 and the boiler system operation panelBP-201, the number of errors is counted up. While the power is supplied to the EJ-210, if the power is not supplied to the boiler system operation panelBP-201 or the panel is in the state immediately after the start of power supply, the number of errors is counted up.

  • Page 31: Checking The Operation Of Mi Control And Boiler Combustion Control

    MIURA_CONFIDENTIAL 4.3 Checking the Operation of MI Control and Boiler Combustion Control Check the operation of combustion control of the boiler when “MI control” is set to “Auto” or “Manual”. The status monitor of the boiler system operation panel BP-201 is used for checking the operation. Connect a PC with the MOM communication software installed and display the status monitor, and then check the operation according to the procedure described below.
  • Page 32 • In the case of a boiler with a BG-type, BL-type, or XJ1-type controller mounted, or a boiler with the EJ-210 on which a steam pressure sensor is mounted, check that operation switches among standby, low-fire operation, and high-fire operation according to the pressure setting value of the EJ-210(refer to “3.3.3Settings in the User Operation Mode (1)”).
