Models:
LCZ 837
LV 831
Contents
1.
Introduction .......................................................................................................... - 1 -
2.
Control panel ........................................................................................................ - 1 -
3.
Service Test ........................................................................................................... - 1 -
4.
Error codes ............................................................................................................ - 2 -
5.
Wiring diagram ..................................................................................................... - 4 -
6.
Water circuit scheme ............................................................................................ - 5 -
7.
Electrical components .......................................................................................... - 5 -
Service Manual
MSDW15050
LP7 811
LPM 809
MLP 800
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Teka LCZ 837
Summary of Contents for Teka LCZ 837
-
Page 1: Table Of Contents
Service Manual MSDW15050 Models: LCZ 837 LP7 811 LPM 809 LV 831 MLP 800 Contents Introduction ......................- 1 - Control panel ......................- 1 - Service Test ......................- 1 - Error codes ......................- 2 - Wiring diagram ..................... - 4 - Water circuit scheme .................... -
Page 2: Introduction
Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 1. Introduction El presente manual técnico explica cómo acceder al test de servicio de los modelos indicados, así como el significado de los distintos códigos de error. -
Page 3: Error Codes
Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 Drain pump Drain for 30 sec. Pause Pause for 10 secs. Open inlet valve and feeds with 3.6L (3.0 in Inlet valve 45cm. models) Washing pump Run washing pump for 2 mins. - Page 4 Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 At the same time, the buzzer will sound for 30 seconds and E1 will be shown. Heating exceeds pre-set time. If the heating element has been working for 60 minutes but the water temperature detected by NTC hasn’t reached desired value.
-
Page 5: Wiring Diagram
Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 5. Wiring diagram Service Manual: MSDW15050 - 4 -... -
Page 6: Water Circuit Scheme
Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 6. Water circuit scheme 7. Electrical components Inlet valve Voltage = 220 – 240 V Resistance = 3.4 – 4.3 KΩ NTC sensor Service Manual:... - Page 7 Service Manual LCZ 837 - LP7 811 - LPM 809 - LV 831 - MLP 800 Flowmeter Using a multi-meter in Diode testing mode, there should be electrical pulses sent out while water is passing through the flowmeter. Washing pump Voltage = 220 –...
