- Page 1 Service Manual Dishwasher LP8 850 Service Manual: MS-DW-0071-00-0913 (September 2013) SERVICE MANUAL LP8 850 Service Manual: MS-DW-0071-00-0913...
-
Page 2: Table Of Contents
Service Manual Dishwasher LP8 850 Contents 1. General description and operation instructions ......... - 2 - 2. Product components ................- 3 - Inlet Valve .................... - 3 - Air Breaker ................... - 4 - Drain Pump ..................- 5 - Heater Element .................. -
Page 3: General Description And Operation Instructions
Dishwasher LP8 850 General description and operation instructions This manual describes the new dishwasher LP8 850 and its components. This new range of dishwashers has been developed to reduce the water consumption (12.5L per cycle) and energy consumption (0.95-1.05 KW/h). -
Page 4: Product Components
Service Manual Dishwasher LP8 850 Product components Inlet Valve Nominal voltage (V AC) 220-240 Frequency (Hz) 50/60 Resistance (KΩ) 3,4-4,4 Flow rate (L/min.) 2,5 ± 15% Power (W) Work Pressure (Mpa) 0,04 - 1 Service Manual: MS-DW-0071-00-0913 - 3 -... -
Page 5: Air Breaker
Service Manual Dishwasher LP8 850 It is an electromagnetic device commanded by the PCB. The inlet valve is composed by the electric coil, body and filter. It allows the water load into the dishwasher filtering it in order to avoid that any strange element gets inside the water circuit. -
Page 6: Drain Pump
Service Manual Dishwasher LP8 850 Drain Pump Nominal voltage (V AC) 220-240 Frequency (Hz) 50/60 Resistance (Ω) 167 ± 10% ≥ 17 L/min. (230 Flow rate (L/min.) VAC) Following the line of the new design, the drain pump is directly mounted on water sump assy. -
Page 7: Heater Element
Service Manual Dishwasher LP8 850 Heater Element Nominal voltage (V AC) 220-240 Resistance (Ω) 29,4 ± 10% Power (W) 1800 Fuse(⁰C) It is fixed directly to the hydraulic block by 3 screws. In order to check its correct performance, it is needed to measure the resistance value on its terminals. -
Page 8: Washing Pump
Service Manual Dishwasher LP8 850 Washing Pump Nominal voltage (V AC) 220-240 Frequency (Hz) 50/60 Main 120,10 ± 7% Resistance (Ω) Auxiliary 107,7 ± 7% Flow rate (L/min.) ≥ 50 Lock Rotor current (A) (230VAC) 0,5 ± 10% Operating current (A) (230VAC) 0,24 ±... -
Page 9: Ntc Sensor
Service Manual Dishwasher LP8 850 NTC Sensor Ambient T. Resistance 15⁰C 17,48 20⁰C 12,12 25⁰C 30⁰C 8,299 NTC Values 40⁰C 5,807 50⁰C 4,144 60⁰C 3,011 70⁰C 2,224 80⁰C 1,667 The NTC controls the temperature of the water. As a Negative Temperature Coefficient device, it will change its resistance depending on the temperature of the water. -
Page 10: Electric Aquastop
Service Manual Dishwasher LP8 850 To check the flow meter, use a multimeter in ohm position and observe the pulses while it turns. If there are not pulses shown in the multimeter, the flow meter is broken. Do not forget that connections must always be checked before proceeding with its replacement. -
Page 11: Power Control Board
Service Manual Dishwasher LP8 850 Power Control Board It is responsible for collecting and processing all the signals received from the components of the dishwasher, as well as returning the adequate signals in order to perform the cycle selected by the customer. - Page 12 Service Manual Dishwasher LP8 850 Half load Valve output There is a flat connector for the Salt Detector input display panel (CN4). Rinse detector input IAQS Overflow switch input If you have to check the outputs Flow meter input of the PCB, always connect one probe of the multimeter to ACN.
-
Page 13: Hydraulic Circuit
Service Manual Dishwasher LP8 850 Hydraulic circuit Service Manual: MS-DW-0071-00-0913 - 12 -... -
Page 14: Service Test
Service Manual Dishwasher LP8 850 Service test To run the service test: 1.- Disconnect the power of the dishwasher. 2.- Reconnect the main power. 3.- Open de door and push program button (P). 4.- Switch on the dishwasher with On/Off button. -
Page 15: Troubleshooting Section
Service Manual Dishwasher LP8 850 Troubleshooting section Some errors can be shown in the display depending on the fail. - E1 Water filling exceeds the preset time. The inlet valve has been opened for more than 4 minutes and the amount of water measured by the flow meter is incorrect. - Page 16 Service Manual Dishwasher LP8 850 - E6 NTC sensor with open circuit. This error is detected by the PCB in the test program procedure. With this error the drain pump will run till the flowmeter keeps stopped during 2 minutes. After that the dishwasher will stop and the buzzer will beep during 30 seconds while the error is shown on display.
-
Page 17: Flow Chart Procedure For Errors
Service Manual Dishwasher LP8 850 Flow Chart Procedure for errors The next flow charts are only for reference, and they cannot show all possible situations that occur dishwasher. Service Manual: MS-DW-0071-00-0913 - 16 -... - Page 18 Service Manual Dishwasher LP8 850 Service Manual: MS-DW-0071-00-0913 - 17 -...
- Page 19 Service Manual Dishwasher LP8 850 Service Manual: MS-DW-0071-00-0913 - 18 -...
- Page 20 Service Manual Dishwasher LP8 850 If any of the procedure shown above doesn´t solve the problem, you have to replace the main PCB. Service Manual: MS-DW-0071-00-0913 - 19 -...
