Item #1008 285 659
1008 285 663
Model #YG990-MBK
YG990-MWH
USE AND CARE GUIDE
44 IN. LOOMIS
INDOOR CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Visual instruction of how to install this fan:
Visit www.homedepot.com and enter either the Item or Model number to nd
this fan and click the link of visual instruction in the product overview section.
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY LOOMIS YG990-MBK
Summary of Contents for HAMPTON BAY LOOMIS YG990-MBK
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........Assembly . -
Page 3: Warranty
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut 9 Watt LED bulb Pull chain and fob...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Blade Canopy ring (preassembled) Blade arm Canopy Switch housing Hanger ball/downrod assembly Light kit Coupling cover Plastic shade Fan motor assembly HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Installation
Installation MOUNTING OPTIONS WARNING: To reduce the risk of re, electric shock, or NOTE: You may need a longer downrod to maintain proper personal injury, mount the fan to an outlet box marked blade clearance when installing on a steep, sloped ceiling. acceptable for fan support using the screws provided with the The maximum angle allowable is 18°... -
Page 7: Assembly
Assembly Preparing the canopy Preparing the motor Remove the canopy ring (B) from the canopy (C). Remove the cotter pin (EE) and clevis pin (FF), and loosen the two collar set screws (GG) from the fan motor assembly Remove the two non-slotted canopy mounting screws with (F) collar. - Page 8 Assembly — Hanging the Fan Installing the mounting bracket to the Hanging the fan on the mounting electrical box bracket WARNING: To reduce the risk of re, electric shock or other WARNING: The tab in the ring must rest in the groove of personal injury, mount the fan only to an outlet box or supporting the hanger ball/downrod assembly (D).
- Page 9 Assembly — Hanging the Fan (continued) Making the electrical connections WARNING: To avoid possible electrical shock, be sure Ground electricity is turned off at the main fuse box before wiring. conductor Neutral Black White WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts, except for the ground wire.
- Page 10 Assembly — Hanging the Fan (optional) Single Switch Connections Dual Switch Connections On a single switch the fan and light can be turned on or off On a dual switch the fan and light can be turned on or off together.
- Page 11 Assembly — Hanging the Fan (continued) Installing the canopy Outlet Box WARNING: Make sure the tab on the mounting bracket (A) properly sits in the groove in the hanger ball/downrod assembly (D) before attaching the canopy (C) to the mounting bracket (A) by turning the canopy (C) until it drops into place.
- Page 12 Assembly — Attaching the Fan Blades (continued) Attaching the blades to the blade arms WARNING: Failure to properly seat the blades (G) on the blade arms (H) and engage in the spring locking mechanism (JJ) could result in the fan blades (G) loosening and possibly falling. NOTE: Your fan blades are reversible.
- Page 13 Assembly — Installing the Light Kit Attaching the switch housing to Attaching the light kit to the the mounting ring switch housing Remove one of the two light kit mounting screws (SS) from CAUTION: Before starting installation, disconnect the the switch housing (I) and loosen the other one screw (SS). power by turning off the circuit breaker or removing the fuse at the fuse box.
- Page 14 Assembly — Installing the Light Kit (continued) Installing the light bulbs Installing the plastic shade Position the notches (UU) in the outer rim of the plastic shade CAUTION: Before starting installation, disconnect the (K) so they line up with the tabs (VV) on the inside of the rim power by turning off the circuit breaker or removing the fuse on the light kit (J).
-
Page 15: Operation
Operation Installation PULL CHAIN OPERATING INSTRUCTIONS Install three pull chains and fobs (CC) onto the pull chain located in the switch housing (I). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off. -
Page 16: Care And Cleaning
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically. - Page 17 - Consult the dealer or an experienced radio/TV technician for help. Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM...
