USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Hampton Bay!
GAZEBO III 42 IN. CEILING FAN
call Hampton Bay Customer Service
1-855-HD-HAMPTON
HAMPTONBAY.COM
Visual instruction of how to install this fan:
Visit www.homedepot.com and enter either the Item or Model number to nd
this fan and click the link of visual instruction in the product overview section.
THANK YOU
Item #1007 743 832
1007 743 839
1007 743 823
Model #YG988-BN
YG988-MBK
YG988-MWH
Advertisement
Related Manuals for HAMPTON BAY GAZEBO III YG988-BN
Summary of Contents for HAMPTON BAY GAZEBO III YG988-BN
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........Assembly . -
Page 3: Warranty
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut Pull chain and fob...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Coupling cover Canopy ring (preassembled) Fan motor assembly Canopy Blade Canopy bottom cover (preassembled) Blade arm Hanger ball/downrod assembly HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of re, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°... -
Page 7: Assembly
Assembly — Standard Ceiling Mounting Preparing the canopy Preparing the motor Remove the canopy ring (B) from the canopy (C). Remove the cotter pin (DD) and clevis pin (EE), and loosen the two collar set screws (FF) from the fan motor assembly Remove the two non-slotted canopy mounting screws with (G) collar. - Page 8 Assembly — Close-to-Ceiling Mounting Preparing the canopy Preparing the motor Remove the canopy ring (B) from the canopy (C). Remove the cotter pin (DD) and clevis pin (EE), and two collar set screws (FF) from the fan motor assembly (G) collar. Remove the mounting bracket (A) from the canopy (C) by loosening the four canopy mounting screws with lock Remove three of the six collar mounting screws with lock...
- Page 9 Assembly — Hanging the Fan Attaching the fan to the electrical box WARNING: To reduce the risk of re, electric shock or other personal injury, mount the fan only to an outlet box or supporting system marked acceptable for fan support and use the mounting screws provided with the outlet box.
- Page 10 Assembly — Hanging the Fan (continued) Making the electrical connections WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. Ground Neutral conductor WARNING: Check to see that all connections are tight, Black White including ground, and that no bare wire is visible at the wire...
- Page 11 Assembly — Hanging the Fan (optional) Single Switch Connections Dual Switch Connections On a single switch the fan and light can be turned on or off On a dual switch the fan and light can be turned on or off together.
- Page 12 Assembly — Hanging the Fan (optional) Standard ceiling mounting Close-to-ceiling mounting WARNING: Make sure the tab on the mounting bracket (A) WARNING: The locking slots of the canopy (C) are provided properly sits in the groove in the hanger ball (E) before attaching only as an aid to mounting.
- Page 13 Assembly — Attaching the Fan Blades Removing the rubber packing mounts The fan motor assembly (G) is shipped with rubber packing mounts (HH) to prevent movement during transportation. Remove the ve rubber packing mounts (HH) from the fan motor assembly (G) and discard prior to attaching the blade arms (I).
- Page 14 Assembly — Attaching the Fan Blades (continued) Fastening the blade assemblies to the motor WARNING: To reduce the risk of personal injury, do not bend the blade arms (I) while installing, balancing the blades (H), or cleaning the fan. Do not insert foreign objects between rotating fan blades (H).
-
Page 15: Operation
Operation Installation PULL CHAIN OPERATING INSTRUCTIONS Install the pull chain and fob (BB) onto the pull chain located in the switch housing (OO). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off. -
Page 16: Care And Cleaning
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically. - Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
