For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-DK5207
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 4
(Included)
Rev: 19-06-06
Advertisement
Related Manuals for Furniture of America CM-DK5207
Summary of Contents for Furniture of America CM-DK5207
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK5207 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 12pcs #1 x 1pc Side Table Bolt 5/16" x 2" #2 x 1pc #B x 12pcs Shelves Spring Washers Ø5/16'' #C x 12pcs...
- Page 4 Align legs (#3) to the side table (#1), then secure by using bolts (#A) with washers (#B,C). # A x 8pcs #B x 8pcs # C x 8pcs Please do not fully tighten screws until all screws are in place Align shelf (#2) to the legs (#3), then secure by using bolts (#A) with washers (#B,C).
