ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-DK5849
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev:18-09-25
Advertisement
Related Manuals for Furniture of America CM-DK5849
Summary of Contents for Furniture of America CM-DK5849
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK5849 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs #1 x 1pc Cabinet Body Bolt Ø1/4" x 1-3/8" #B x 1pc #2 x 3pcs Allen Key 4mm #3 x 1pc Mirror Connecting Rod...
- Page 4 Align and attach legs (#2) to the cabinet body (#1). Pull drawer out, then align mirror connecting rod (#3) to the cabinet body (#1), then secure by using bolts (#A). #A x 2pcs Page 4 of 8...
- Page 5 Align mirror (#4) to the mirror rod (#3), then secure by using bolts (#A). #A x 2pcs Attach metal rods of the right and left mirrors (#5R/L) to the metal rods of the mirror (#4). Page 5 of 8...
- Page 6 Detach knobs from the inside of drawers, then reattach knobs to the outside of drawers. Page 6 of 8...
- Page 7 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #B x 1pc #1 x 1pc Allen Key 4mm Seat #C x 8pcs #2 x 4pcs Bolt Ø1/4"...
- Page 8 Align legs (#2) to the seat (#1), then secure by using bolts (#C) with washers (#D,E). #C x 8pcs #D x 8pcs #E x 8pcs ASSEMBLY IS COMPLETED Page 8 of 8...
