Furniture of America CM-DK5234 Assembly Instructions Manual

Download this manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM-DK5234

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

(Not Included)

Rev:19-01-14

Need help?

Do you have a question about the CM-DK5234 and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK5234 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 12pcs #1 x 1pc Cabinet body Bolt Ø1/4" x 1-3/16" #B x 8pcs #2 x 4pcs Shelf Pin #3 x 2pcs #C x 2pcs...
Page 4 Align legs (#2) to cabinet body (#1), then secure by using bolts (#A). #A x 12pcs #B x 8pcs Attach shelf pins (#B) to the pin holes of the cabinet body (#1), then place shelves (#3) onto shelf pins (#B). Page 4 of 6...
Page 5 #C x 2pcs #D x 2pcs Align knobs (#C) to cabinet doors (#1), then secure by using bolts (#D). ASSEMBLY IS COMPLETED Page 5 of 6...
Page 6 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #E x 1pc Seat Allen Key 4mm #2 x 4pcs #F x 8pcs Bolt Ø1/4"...
