- Page 1 Pneumatic L4080 Rev. E 10/21 Torque Wrench PTW Series PTW1000 PTW2000 PTW3000 PTW6000 English (EN) Instruction Sheet...
-
Page 3: Table Of Contents
Index 1 Introduction ............................ 2 2 Safety .............................. 3 3 Assembly and Adjustment ......................5 4 Operation ............................6 5 Maintenance ........................... 9 6 Troubleshooting ..........................9 7 Technical Specifications ......................10 Instruction Sheet © 2021 Enerpac, All Rights Reserved. -
Page 4: Introduction
Optional reaction long as you own them. Any misuse or alteration arms are available for different applications. invalidates the warranty. The PTW Series is available as a package with the • Observe all instructions as communicated in this following: manual. -
Page 5: Safety
Safety Definitions Be aware that the operator is fully responsible for the correct operation of this tool. Enerpac is not The Safety Alert Symbol appears responsible for damage or injury caused by misuse throughout this manual. It is used to alert of this tool. - Page 6 PTW Series Pneumatic Torque Wrench PTW Series Safety CAUTION The following warnings are specific to the PTW Series Pneumatic Torque Wrench. Failure to observe and comply with the following precautions could result in minor or moderate personal injury. Property damage could also occur.
-
Page 7: Assembly And Adjustment
PTW Series Pneumatic Torque Wrench 3 ASSEMBLY AND ADJUSTMENT 3. Install a quick coupler or air hose (not supplied) into the 1/2 inch NPT inlet port. The air source must be capable of at least 50 CFM (85 CMH) at 100 psi (6.9 bar). A minimum hose size of 1/2 inch (13 mm) must be used. -
Page 8: Operation
PTW Series Pneumatic Torque Wrench 4 OPERATION 6. Connect the air hose to the tool. WARNING: Before using the tool, inspect the tool, reaction arm, air hoses and Filter/Regulator/Lubricator (FRL) for any cracks, wear or other damage. Immediately replace any worn or damaged parts with genuine Enerpac parts before using the tool. - Page 9 Fig. 6 so the tool is set to the highest speed and direction of rotation. The tool calibration chart provided by Enerpac for this tool was produced with the tool on the highest speed. Tool performance in this speed will most closely reproduce the pressure/torque ratio listed in this chart.
- Page 10 PTW Series Pneumatic Torque Wrench NOTE: For counterclockwise rotation, the adjustment 12. To loosen a fastener (or to apply torque in the lever is set to the “R” position. counterclockwise direction): Be sure that the adjustment lever is set to the “R” position and 10.
-
Page 11: Maintenance
PTW Series Pneumatic Torque Wrench 5 MAINTENANCE NOTICE: Failure to maintain proper lubricator oil level and drip rate will result in reduced output NOTICE: Failure to keep the air motor properly torque and possible air motor failure. lubricated can cause a reduction in output torque. -
Page 12: Technical Specifications
PTW Series Pneumatic Torque Wrench 7 TECHNICAL SPECIFICATIONS 10.70 in. (272 mm) Ø 2.83 in. (72 mm) PTW1000 11.26 in. (286 mm) Ø 3.11 in. (79 mm) PTW2000 13.5 in. (343 mm) Ø 3.74 in. (95 mm) PTW3000 14.4 in. - Page 13 PTW Series Pneumatic Torque Wrench NOTES _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ © 2021 Enerpac, All Rights Reserved.
- Page 14 PTW Series Pneumatic Torque Wrench NOTES _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ _____________________________________________________________________________ © 2021 Enerpac, All Rights Reserved.
