NetComm NB6Plus4 Specifications page 2

TECHNICAL SPECIFICATIONS
ADSL COMPLIANCE
ADSL
• ANSI T1.413 Issue 2
• ITU G.992.1 Annex A (G.dmt)
• ITU G.992.2 Annex A (G.lite)
• ITU G.994.1 (G.hs)
• Support dying gasp
• Maximum Rate: 8 Mbps downstream and 1 Mbps upstream
ADSL2
• ITU G.992.3
• ITU G.992.4
• Maximum Rate: 12 Mbps downstream and 1 Mbps upstream
ADSL2+
• ITU G.992.5
• ITU G.992.5 Annex M
• Maximum Rate: 24 Mbps downstream and 1.2 Mbps upstream
ATM
• PPPoA (RFC 2364) and PPPoA Bridged mode
• PPPoE (RFC 2516) and PPPoE Bridged mode
• IPoA (RFC 2225)
• Bridged mode over AAL5 (RFC2684/1483)
• ATM Forum UNI 3.1 / 4.0 compliant PVCs
• UBR and CBR with traffic shaping
• OAM F4/F5 loopback cells
BRIDgINg
• IEEE 802.1d self-learning bridge
• Learning up to 4096 MAC addresses
• Transparent Bridging between 10/100 Mb Ethernet and USB
ROUTINg
• NAT / PAT allows multiple users to share Internet access
• UPnP IGD with NAT traversal capability
• Port Forwarding: users can setup multiple virtual servers (e.g.,
Web, FTP, Mail servers) on the local network.
• Static routing & dynamic routing RIPv1/v2
• DNS Relay, Dynamic DNS
• DHCP Client/Relay/Server
• IGMP Proxy
• Support IP/Bridge QoS for different traffic classes
• Support reservation of bandwidth to guarantee voice quality of
VoIP applications.
SECURITY
• PAP, CHAP, and MS-CHAP for PPP authentication
• Firewall based on incoming & outgoing filtering of IP address/Port
number/Protocol type
• DMZ hosting
SUPPORTED APPLICATIONS
• Application Level Gateways preset for Auth/Ident, DNS, FTP,
PPTP, IPSEC, POP3, SMTP, SSH, TELNET, TFTP & WEB servers.
Multiple Virtual Servers can be setup in local network.
• Multiple VPN passthrough sessions
• NetMeeting, MSN Messenger, FTP, Quick Time, mIRC, Real
Player, CuSeeMe, online gaming.
CONFIgURATION AND MANAgEMENT
• Embedded web configuration interface with password protection
• Remote management control
• Telnet session for local or remote management
• System events logging
• DSL connection diagnostics
• Firmware upgrade via web browser
• User setting backup & restore
HARDWARE INTERFACE
• One RJ-11 port for ADSL connection
• Four Ethernet ports for IEEE 802.3/802.3u 10/100 Base-T auto-
sensing, auto cross-over
• One hidden reset button for restoring factory default settings
• One Power on/off button
CHIPSET
• Broadcom BCM6348 single-chip ADSL2+ with integrated
MIPS32 CPU, transceiver & Analog Front End
LED
• Ethernet 4, Ethernet 3, Ethernet 2, Ethernet 1, PPP, ADSL,
Power
POWER SUPPLY
• External power adapter 12VAC/1.0A (output)
APPROVALS
• A-Tick N367
ENVIRONMENTAL CONDITIONS
• Operating temperature 0 ~ 40°Celsius
• Relative humidity 20 ~ 90% (non-condensing)
DIMENSIONS
• 190 mm (W) x 30 mm (H) x 150 mm (D)
• Weight: 320g
NetComm NB6Plus4
ADSL2+ Modem Router with 4 Ethernet interfaces
NB6Plus4 ADSL2+ Modem Router
• Broadband Internet Access up to 24 Mbps*
• VoIP Compatible (ATA or other VoIP device required)
• 4 Ethernet Ports for Internet Sharing
• Suitable for Home and Office Networks
• Security Firewall & DMZ
• Multiple VPN Passthrough Sessions
• Port Forwarding, UPnP™ and QoS
* Please note that actual speeds may differ and are dependent on your ISP
Internet
Home
Telephone
Telephone
Wall Socket
Splitter with
Microfilter
Your NetComm dealer:
NETCOMM LIMITED PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
LAN 1 LAN 2
Firewall NB6Plus4
ADSL2+ Broadband Modem
LAN 3 LAN 4
LINE Port
4x LAN Ports
Reset
Power, On/Off
