NetMedia RM70 Installation Instructions

Connecting the RM70 Coax-Powered
The RM70 uses a Power Injector which allows it to be powered remotely through the coaxial cable.
The modulator may also power a 12V DC video or surveillance camera.
WARNING: Improper installation may damage electronic equipment. Please follow the power
connection steps below in the proper sequence.
RM70 MODULATOR
Connect the other end of the coaxial cable
to the Power Injector side marked MOD.
WARNING: Reversing power injector direction
could damage other electronic equipment.
10940 N. Stallard Place, Tucson, Arizona 85737
520-544-4567 Fax: 520-544-0800
E-Mail: info@netmedia.com
www.netmedia.com
RM70-2page.cdr
POWER
VIDEO
AUDIO
Connect the coaxial cable to the
1.
modulator RF output connector.
2.
POWER INJECTOR
Connect the power injector side marked TV to your
cable system using a splitter/combiner. This side
of the Power Injector will not receive DC power.
NetMedia, Inc.
VIDEO/SURVEILLANCE CAMERA
5.
A 12V DC camera may be powered from
the modulator, however the power
supply rating must increase 100mA
in addition to the camera requirement
to allow for the modulator.
FOR EXAMPLE: If your camera
requires 12V DC 300mA then use a
12V DC 400mA transformer or larger.
Connect the DC power supply to the Power
3.
Injector and plug in to an AC power source.
CABLE MAIN OR
OTHER TV SIGNAL
4.
SPLITTER/COMBINER
ANTENNA/CABLE IN
TELEVISION
™
Modulator
12V DC TRANSFORMER
POSITIVE CENTER POLARITY
R
M
7
0
I
N
S
T
A
L
L
A
T
I
O
N
M
O
D
U
L
A
T
O
R
S
Rev.9806A
