NetMedia CTV1-M Specifications

V
Single Channel Modulator with Caller-ID
Distribute Caller-ID information with the Video Source
I
The NetMedia CTV1-M is the premiere Single Channel Digital Modulator on the market. This
advanced unit is a 100% Digital Modulator with PLL Audio, Video and Adjustable Gain. The
D
Modulator also features on-screen programming of the channel selection and gain level.
This combines with a single-line Caller-ID input to distribute not only your video source but
your Caller-ID information as well.
E
O
Digitally Controlled
Features:
100% Digital ModulatorPLL Locked
Audio, Video, & Adjustable Gain
Digital Adjustable Gain Control
Single-Line Caller-ID built-in
Caller-ID information overlays on the
video source when a call comes in
On-screen programming of the
channel selection and Gain level
Memory retained during power outages
Rugged aluminum enclosure
Includes Wall Transformer, 1 Video
Cable, 1 Audio Cable and 1 RJ11
Telephone Cable
1 Year Limited Warranty
Audio , Video, and

Specifications

Output Frequency Range:
Modulation Method:
Output Level:
Video Output Connector:
Video Input Connector:
Audio Input Connector:
Power Requirement:
Telephone Connection:
Size:
10940 North Stallard Place, Tucson, Arizona 85737
(520) 544-4567 Fax: (520) 544-0800
www.netmedia.com
Gain
Ch. 14-72 UHF
Ch. 66-94 CATV
Ch. 100-127 CATV
Digital Audio, Video, Gain
Crystal Stabilized PLL
Digitally Selectable
0, +10, +20, +30dBmV
F-connector, 75 Ohm
RCA, 75 Ohm, 1 Vp-p
3.5mm Stereo Jack
75,000 Ohm, 1 Vp-p
12V DC, 300mA
CL2, UL Approved
Indoor Use Only
RJ11 Type
3.2" x 2.2" x 0.9"
C
T
V
1
M
M
O
D
U
L
A
T
O
R
S
Rev. 0310A
