NetMedia MicroModulator MM70 Specifications

V
I
D
Great for security surveillance, audio/video distribution and video monitoring. View a camera, VCR,
laserdisc, DVD or satellite receiver on a TV channel you choose and distribute it to every TV in the
home. Combine with existing TV channels for seamless CCTV systems.
Features:
World's First 100% Digital Modulator
PLL Locked Audio, Video, & Gain
Zero parts to drift, no adjustments
E
Combines with existing TV channels
UHF & Cable coverage
One button setup
Internally generated test pattern
Memory retained during power outages
Rugged aluminum enclosure
O
Includes Wall Transformer
5 Year Limited Warranty
MicroModulator™
Digitally Controlled
For Making Your Own TV Channels
Audio , Video, and
Actual Size Actual Size

Specifications

Output Frequency Range:
Modulation Method:
Output Level:
Video Output Connector:
Video Input Connector:
Audio Input Connector:
Power Requirement:
Size:
Weight:
10940 North Stallard Place, Tucson, Arizona 85737
(520) 544-4567 Fax: (520) 544-0800
www.netmedia.com
Gain
Ch. 14-69 UHF
Ch. 70-94 CATV
Ch. 100-125 CATV
Digital Audio, Video, Gain
Crystal Stabilized PLL
Digitally Selectable
0, +10, +20, +30dBmV
F-connector, 75 Ohm
RCA, 75 Ohm, 1 Vp-p
3.5mm Stereo Jack
75,000 Ohm, 1 Vp-p
12V DC, 100mA
CL2, UL Approved
Indoor Use Only
3.2" x 2.2" x 0.9"
4.0 oz
