ATZ HDMI-V2-88HE150 Manual

Model : ATZ HDMI-V2-88HE150
Description: 8x8 Matrix Switch over HDBaseT™ w/8x HDBaseT Receiver Box
150m 18Gbps 4K2K@60Hz 4:4:4
This 18Gbps 8x8 HDBaseT(150M) Matrix can connect 8 HDMI sources to 16 displays. It features
8 HDMI outputs and each HDMI output is mirrored to provide a CAT-Cable output which runs
simultaneously. HDBaseT output can extend video transmission distance up to 492ft / 150m via a
single Cat 5e/6/7 cable and the resolution is up to 4K2K@60Hz 4:4:4. Audio de-embedded to
analog and coaxial audio is supported. Each HDMI output supports 4K2K to 1080P downscaler
independently.
The product supports IR matrix. The IR signal is one-to-one control at the Matrix end, but the IR
signal follows HDMI video channel at the HDBaseT Receiver end.
The product provides an intuitive set of front panel with OLED screen and supports control via
front panel buttons, IR remote, RS-232, LAN, and Web GUI.
