ATZ HDMI-V2-42AC Quick Start Manual

Model : ATZ HDMI-V2-42AC
Description: 4x2 HDMI2.0 Matrix Switch 4K2K@60Hz 4:4:4 w/Audio Extractor/ Scale/ARC/
EDID function
This high performance HDMI Matrix Switcher can switch any of these four HDMI
sources to two HDMI displays. It supports resolution up to 4K2K@60Hz YCbCr 4:4:4
and HDCP 2.2. It can extract HDMI source device audio to optical and analog L/R
output. It supports 4K→1080P downscale function if source is 4K but TV only supports
up to 1080P. It also supports ARC and EDID (AUTO/COPY/STD) function. With its
18Gbps bandwidth and the additional features with latest HDMI standards. Flexible
control via front panel buttons and IR remote.

Features:

• HDMI 2.0, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
• Supports 4 HDMI inputs and 2 HDMI outputs
• Video resolution up to 4K2K@60Hz YCbCr 4:4:4
• Supports 18Gbps uncompressed bandwidth on all HDMI
• Supports Dolby Vision, HDR 10+, HLG
Notes
: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered
from time to time.
