◆USB-C fast charging: Use a standard USB-C interface charger to charge
Subnado; support PD3.0, QC2.0, QC3.0, BC2.1, and other charging protocols. The
maximum charging power can reach 100W.
(Note: It needs to be supported by the charger and use of an e-Mark charging
cable to reach 100W charging power).
◆Reverse charging: Subnado can be used as a power source to charge other
devices. Reverse charging supports standard protocols such as PD3.0, PPS,
QC3.0, QC2.0, and BC1.2. The maximum reverse charging power can reach 100W.
(Note: It needs to be supported by the charging device and use of the e-Mark
charging cable to reach 100w charging power)
◆Cruise Mode: In this mode, the unit will enter auto cruise after 15-seconds of the
propeller's continuous rotation, and users can release the trigger. Pull the trigger
again to exit auto cruise.
IV Charging

4.1 How to charge Subnado

1. Select a charger that supports PD protocol
to speed up charging.
2. Open the waterproof cover (facing down to
prevent water from falling in). Check for
moisture around and inside the USB-C port. If
there is water, it needs to be dried first; if there
is seawater, it must be thoroughly cleaned
with alcohol. After confirming that there is no
abnormality, insert the USB-C charging cable
to start charging.
3. During the charging process, the power
indicator is displayed circularly in the form of a
marquee, and the number of lights indicates
the current power.
4. The speed of the marquee indicates the
charging speed; the faster the marquee
speeds, the faster the charging is.

4.2 Reverse charging function

1. Open the waterproof cover (make sure
that no water enters inside the USB-C plug
or remains on the surface).
2. Power on the Subnado first, then plug in
the USB-C cable. Connect the cable to the
target device, charging begins. (Note that
Subnado needs to be powered on before
connecting the device)
3. After charging is completed, unplug the
charging cable and turn off the Subnado.
4. Install the waterproof cover.
05
②
③
①
V Assembly Steps
Install the handle bracket on the main unit and install the Wired
Thumb Controller on the corresponding position.
handle bracket
Accessories Use Instruction
Use M4X8 screws to connect handgrip to Arm mount
(as shown in the figure)
M4X8
handgrip
Subnado Arm Mount
Assembly Completion Figure
