Pre-installation
PLANNING INSTALLATION
It will take one person about 10 minutes to complete the assembly process.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Chaise Lounges
AA
Part
Description
AA
BOLT (M10*115)
BB
WASHER1 (φ10)
CC
WASHER2 (φ10)
DD
NUT(M10)
WASHER3
EE
FF
SPANNER
BB
CC
Quantity
4
8
4
4
4
2
EE
DD
4
Please contact 1-800-986-3460 for further assistance.
FF
