0000 000 000
Model #FZA71015R-2PKB
USE AND CARE GUIDE
ST. CHARLES STEEL/ALUM 2PK ROCKER CHAIR-BARE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection ST. CHARLES
Summary of Contents for Home Decorators Collection ST. CHARLES
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Package Contents ..............4 Save These Instructions ............2 Assembly ..............5 Read All Instructions Before Use ..........2 Care and Cleaning ............ -
Page 3: Warranty
Warranty 5 YEAR FRAME WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser f years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover is warranty. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Support Bar Backrest Left Arm Right Arm Seat Support Tube Left Leg Right Leg Connector Bar Back Cushion Seat Cushion... -
Page 5: Assembly
Assembly Insert the Support Bar, Backrest and Seat to the Left Arm Place the left arm (C) on a soft surface. Insert the support bar (A), backrest (B) and seat (E) to the left arm (C). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance... - Page 6 Assembly (continued) Attaching the Seat to the Left Arm Attach the seat (E) to the left arm (C) using M6x35 combination bolts (BB). NOTE: Loosely tighten the bolts using the hex wrench (EE).
- Page 7 Assembly (continued) Insert the Right Arm to the Support Bar, Backrest and Seat Insert the right arm (D) to the support bar (A), backrest (B) and seat (E). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
- Page 8 Assembly (continued) Attaching the Right Arm to the Seat Attach the right arm (D) to the seat (E) using M6x35 combination bolts (BB). NOTE: Loosely tighten the bolts using the hex wrench (EE).
- Page 9 Assembly (continued) Connecting the Support Bar to the Arms Turn the chair right side up. Connect the support bar (A) to the left arm (C) and right arm (D) using M6x20 bolts (DD). NOTE: Loosely tighten the bolts using the hex wrench (EE). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460...
- Page 10 Assembly (continued) Attaching the Support Tube To the Seat Attach the support tube (F) to the seat (E) using M8x28 combination bolts (CC). NOTE: Loosely tighten the bolts using the wrench (FF).
- Page 11 Assembly (continued) Attaching the Legs to the Support Tube Attach the left leg (G) and right leg (H) to the support tube (F) using M8x28 combination bolts (CC). NOTE: Loosely tighten the bolts using the wrench (FF). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
- Page 12 Assembly (continued) Connecting the Connector Bar to the Legs Connect the connector bar (I) to the left leg (G) and right leg (H) using M6x20 combination bolts (AA). NOTE: Loosely tighten the bolts using the hex wrench (EE).
-
Page 13: Care And Cleaning
Assembly (continued) Place the Seat Cushion and Back Cushion on the Chair Once all the bolts are in place, fully tighten all the bolts. Turn the chair right side up. Place the seat cushion (K) and back cushion (J) on the chair. Ensure that all connections are secure before use. - Page 14 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. Factory chair ID # FZM71015R...
