- Page 1 RB-1D RB-1 Gas Stock Pot User’s Manual...
- Page 2 Dear Client & User, Firstly, thanks for purchasing and using our product. All the information and guidelines of this user’s manual comply with certain applicable regulations, which come out from our long-term accumulated knowledge and experience as well as current project development situations. Limited to some special structures, additional specified items or new technology changes, the actual usage situation might be some different from what stated in this user’s manual.
- Page 3 Warning ⚫ Any self-modification, wrong installation, adjustment or maintenance can lead to property loss or casualty. Please contact the manufacturer for any adjustment or maintenance, and have the work done by a trained & qualified person. ⚫ For your safety sake, please keep the machine away from any liquid, gas or other object, which is flammable or explosive.
-
Page 4: Table Of Contents
Contents 1. Functional Introduction------------------------------------------------------------------5 2. Structure Schematic Diagram----------------------------------------------------------5 3. Basic Features & Parameters-----------------------------------------------------------6 4. Precautions & Recommendations-----------------------------------------------------7 5. Working Instructions & Operation Flow----------------------------------------------9 6. Routine Inspection------------------------------------------------------------------------9 7. Cleaning & Maintenance-----------------------------------------------------------------9 8. Failure Analysis & Trouble Shooting---------------------------------------------------10... -
Page 5: Functional Introduction
1. Functional Introduction This product is manufactured and developed by our company, which is combined with advantages from home and abroad. It is integrated with merits of attractive design, reasonable structure, easy operation, durable using and convenient maintenance. The flames of the inner and outer crown could be controlled separately and regulated freely at certain range. -
Page 6: Precautions & Recommendations
4. Precautions & Recommendations 4.1 Transportation and Storage During transportation, the machine should be carefully handled and do not put it upside down to prevent from damaging to the shell and inside. The packaged machine should be stored in a... - Page 7 ventilated warehouse without corrosive gas. If it needs to be stored in open air temporarily, measurement against raining is needed. 4.2 Notice for Installment 1. Installation of the appliance should be done by professional technicians. 2. Connection of the appliance shall comply with provisions in gas safety, installation and operation.
-
Page 8: Working Instructions & Operation Flow
pipeline. If it cannot be lit up for the first time, turn the ignition switch off and turn it on 3min after the remaining gas is exhausted to prevent from deflagration. 4. Do not use gas that not applicable to the appliance as fuel, neither does high-pressure or medium-pressure regulating valve. -
Page 9: Cleaning & Maintenance
Whether the fire hole is blocked? Whether the gas inlet pipe is aged, cracked or damaged? Whether the control panel is damaged? During using: Whether there is strange smell or vibration noise? Whether the burner flame is normal? Any backfire or flame lift? 7. - Page 10 Aforementioned troubles are just for reference. If any failure occurs, please stop using and inform the professional technicians to check and repair. Safety is first and maintenance should be done after shutting down the power supply and gas supply.
