Rebotec Big 250 User Manual

BA-Nr.: 02.01.120/2022-06-A01
User Manual
Big 250 & Big 250 Extra long
1. Product description
1.1. Introduction
• The product described here is a medical device of risk class I
according to (EU) 2017/745 MDR.
• In this user manual, you will find information on the safe and
proper initial operation, use, maintenance and care of this prod-
uct. Carefully read this user manual before using the device. Fol-
low the safety instructions and act accordingly.
2. Features
2.1. Intended purpose
• The product is used for support and relief in case of restrictions
of the lower extremities. It allows the user to pursue their desire
for mobility. There must be sufficient upper body musculature for
safe use. Persons with sensory impairments may not be able to
use this item. The article does not impose any special require-
ments on the education of the user.
Specification:
Designation
106.00...
Big 250
106.04...
Big 250, extra long
a=Height-adjustable / c=Indoor & outdoor use
1=standard clip
2= clamping clip
2.2. Conditions of use
• Temperature range: -10°C to +35°C; direct radiant heat on the
product must be avoided. Relative humidity: 40% to 85%. Out-
side of these conditions, the product must only be used for a
short time.
• The product is not suitable for use in swimming pools or saunas,
as surface discolouration and limitations of mechanical strength
may occur.
2.3. Storage & transport
• Temperature range: 5 °C to 25 °C; direct radiant heat on the
product must be avoided. Store the product in dry rooms with a
humidity of up to 65%.
2.4. Disposal
•
Disposal and recycling of used products and packaging must be
carried out in accordance with currently valid regulations. Please
contact a disposal company for further information. The Infection
Protection Act must be observed. Please observe any labels and
information on packaging material and act accordingly.
Read this User Manual
well as for future use and subsequent sales.
EN
1 2 250 kg c a
1 2 250 kg c a
before using the device for the first time
REBOTEC
DE-49610 Quakenbrück, Artlandstr. 57-59
Telephone: +49 (0) 54319416-0
Fax: +49 (0) 5431/9416-66
Web:
Email:
3. Symbols & nameplates
Symbol Meaning
Read the manual!
Article number
Language
EN
Important infor-
mation!
4. Warranty
• For this product the manufacturer grants a warranty of 12
months. Compliance with the general terms and condi-
tions( ), as well as the intended use, are a
www.rebotec.de/agbs
basic prerequisite. The statutory warranty provisions shall apply.
• Unauthorised modifications to this product will void the product's
conformity and the warranty.
4.1. Complaint
• Please contact us before returning the product. To reduce
transport damage, use the original packaging if possible.
• The Infection Protection Act must be complied with.
• Please make sure that the product does not pose a risk of infec-
tion when returned. Enclose an information sheet on safety with
the product. Costs may incur for returns that are not marked
non-objectionable.
5. Safety instructions
Please observe the following safety instructions:
•
Before using the device for the first time, the
User Manual must be read completely in order to avoid
hazards or damage caused by maloperation. Before each use,
check the device for visible damage or deficiencies. In case of
malfunctions or damage of any kind, the device must not be
used. Regularly check the suction foot for damage and wear;
replace if necessary.
• The walking aid must be placed on the floor as vertically as pos-
sible when walking. Therefore, never position the walking aid too
far away from the body or forward in the walking direction. Grasp
the handle completely and firmly with one hand. If possible, have
an assistant accompany and support you so that they can catch
you if you fall.
• The walking aid must not be used for any other purpose. There-
fore, only use them to support your ability to walk and not, for
example, as a stand-up aid, for levering, moving furniture or
other objects. Do not attach any objects (bag, pouch, etc.) to the
walking aid.
• After a long period of disuse: Have the walking aid checked by
qualified personnel or a specialist dealer. Do not perform any
unauthorised mechanical modifications (product liability!). Do
not expose the walking aid to sunlight for a longer period of time
(at the window, at the heater, in the car). Heat can lead to
changes in material properties and durability.
•
Attention, danger of slipping:
damp tiles, floors or crossing loose carpeting. Never clean han-
dles or suction caps with substances containing oil. Be careful
with unevenness, holes in the ground and loose subsoil, be-
cause the walking aid can slip away unexpectedly or sink in.
and keep it at hand for the user as
®
Rehabilitationsmittel GmbH
www.rebotec.de
info@rebotec.de
Symbol Meaning
Year of manufac-
ture of Device
Manufacturer
Maximum user
weight in kg
Product complies
with (EU)
2017/745 MDR
Be careful when walking over
