Rebotec ECO 100 User Manual

BA-Nr.: 02.01.001/2021-07-A01
User Manual
Walking aids

1. Product description

1.1. Introduction
• The product described here is a medical device of risk class I ac-
cording to (EU) 2017/745 MDR.
• In this user manual, you will find information on the safe and proper
initial operation, use, maintenance and care of this product. Care-
fully read this user manual before using the device. Follow the safety
instructions and act accordingly.

2. Features

2.1. Intended purpose
• The product is used for support and relief in case of restrictions of
the lower extremities. It allows the user to pursue their desire for
mobility. There must be sufficient upper body musculature for safe
use. Persons with sensory impairments may not be able to use this
item. The article does not impose any special requirements on the
education of the user.
Specification:
Designation
100.20...
ECO 100
100.22...
ECO 120
101...
Magic-Twin
102...
Magic-Twin
103...
Magic-Twin
Magic-Twin, extended
104...
length
105...
Magic-Soft
Magic-Soft, extended
105...10
length
106.10 Big 150
106.30 Big 130 Soft-Anatom
107...
Magic-Soft-Anatom
109...
Combi-Soft
110...
Comfort-Soft
112...
Comfort
115...
Combi
116...
Safe-In
116...20
Safe-In, extended length
117...
Safe-In-Soft
118...
Safe-In-Anatom-Soft
119...
Safe-In-Anatom
120...
Light-Line
122...
Fun-Kids
a=Height adjustable / b=Continuous tube, can be shortened
c=Indoor & outdoor use
1=Standard clip / 2=Squeeze pressure / 3=Squeeze clip
4=Standard pressure
2.2. Conditions of use
• Temperature range: -10°C to +35°C; direct radiant heat on the prod-
uct must be avoided. Relative humidity: 40% to 85%. Outside of
these conditions, the product must only be used for a short time.
• The product is not suitable for use in swimming pools or saunas, as
surface discolouration and limitations of mechanical strength may
occur.
Read this User Manual
well as for future use and subsequent sales.
EN
1 100kg c a
4 120kg c a
1 130kg c a
2 130kg c a
3 130kg c a
3 130kg c a
2 130kg c a
3 130kg c a
- 150kg c b
- 130kg c b
2 130kg c a
2 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 130kg c a
3 100kg c a
3 100kg c a
before using the device for the first time
REBOTEC
®
Rehabilitationsmittel GmbH
DE-49610 Quakenbrück, Artlandstr. 57- 59
Telephone: +49 (0) 5431/9416-0
Fax: +49 (0) 5431/9416- 66
Web: www.rebotec.de
Email: info@rebotec.de
2.3. Storage & transport
• Temperature range: +5° C to +25° C; direct radiant heat on the prod-
uct must be avoided. Store the product in dry rooms with a humidity
of up to 65%.
2.4. Disposal
• Disposal and recycling of used products and packaging must be car-
ried out in accordance with currently valid regulations. Please con-
tact a disposal company for further information. The Infection Pro-
tection Act must be observed. Please observe any labels and infor-
mation on packaging material and act accordingly.
3. Symbols & nameplates
Symbol Meaning
Read the man-
ual!
Article number
Language
EN
Important infor-
mation!

4. Warranty

• For this product the manufacturer grants a warranty of 12 months.
Compliance with the general terms and conditions(
), as well as the intended use, are a basic prerequi-
tec.de/agbs
site. The statutory warranty provisions shall apply.
• Unauthorised modifications to this product will void the product's
conformity and the warranty.
4.1. Complaint
• Please contact us before returning the product. To reduce transport
damage, use the original packaging if possible.
• The Infection Protection Act must be complied with.
 Please make sure that the product does not pose a risk of infec-
tion when returned. Enclose an information sheet on safety with
the product. Costs may incur for returns that are not marked non-
objectionable.

5. Safety instructions

Please observe the following safety instructions:
•
Before using the device for the first time, the User
Manual must be read completely in order to avoid damage
caused by fault operation or hazards. Before each use, check the
device for visible damage or deficiencies. In case of malfunctions or
damage of any kind, the device must not be used. Regularly check
the suction foot for damage and wear; replace if necessary.
• The walking aid must be placed on the floor as vertically as possible
when walking. Therefore, never position the walking aid too far away
from the body or forward in the walking direction. Grasp the handle
completely and firmly with one hand. If possible, have an assistant
accompany and support you so that they can catch you if you fall.
• The walking aid must not be used for any other purpose. Therefore,
only use them to support your ability to walk and not, for example,
as a stand-up aid, for levering, moving furniture or other objects. Do
not attach any objects (bag, pouch, etc.) to the walking aid.
• After a long period of disuse: Have the walking aid checked by qual-
ified personnel or a specialist dealer. Do not perform any unauthor-
ised mechanical modifications (product liability!). Do not expose the
and keep it at hand for the user as
Symbol Meaning
Year of manufacture
Device
Manufacturer
Maximum user
weight in kg
Product complies
with (EU) 2017/745
MDR
www.rebo-
