- Page 1 INSTALLATION MANUAL MODELS: -STANDARD -EXTRA WIDE KAYAK LIFT 17611 East St, North Fort Myers, FL 33917 (239) 337-4141 REVISION A GoldenMarineSystems.com GoldenBoatLifts.com PUBLISHED 10/18/2020...
- Page 2 REFERENCE NOTES ................12 KAYAK LIFT INTRODUCTION FEATURES • Simple Installation. We at Golden are proud to introduce the Kayak Launch to our • Available in 5 and 7 Step. line of lifts. • Welded Aluminum Frame / Stainless Steel Cables.
- Page 3 Failure to follow this warning can result in personal injury or manuals issued by GOLDEN BOAT LIFTS. death and/or damage to the Kayak Launch. Note: Any installation or operation methods outside the The Kayak Launch has moving parts while in operation.
-
Page 4: Specifications
SPECIFICATIONS KAYAK LAUNCH 5-STEP 7-STEP • • WEIGHT: ≈ 100 lbs.(45 kg) WEIGHT: ≈ 118 lbs. (54 kg) • • MAX CAPACITY: 250 lbs. (114 kg) MAX CAPACITY: 250 lbs. (114 kg) • • MAX HEIGHT: 74-1/4” MAX HEIGHT: 98-1/4” STANDARD •... -
Page 5: Part Identification
PART IDENTIFICATION Ladder Assembly Grab Rail QTY: ( 1 ) QTY: ( 1 ) PN: GBL-01-0270 PN: GBL-KAYAK-SX-GR-W Under Dock Support Bunk QTY: ( 2 ) QTY: ( 2 ) **Optional PN: GBL-KAYAK-SX-BNK-A PN: GMI-01-0317 Cradle QTY: ( 2 ) PN: GBL-KAYAK-S-CRDL-W... -
Page 6: Required Tools
REQUIRED TOOLS HARDWARE 7/16” Open End Wrench Hex Bolt QTY: 9/16” Open End Wrench 1/4” X 2-1/2” 3/8” X 2-1/2” 3/8” Drive Ratchet Washer QTY: 7/16” Socket 1/4” 9/16” Socket 3/8” (12) Lock Washer QTY: 3/8” REPLACEMENT PART(S) PN: GBL-KAYAK-SX-HRL-W 3/16”... -
Page 7: Required Parts
GENERAL ASSEMBLY INSTRUCTIONS REQUIRED PARTS Please read all instruction provided before starting the installation of the Kayak Launch Lift. It is recommended that the Kayak Launch Lift is installed by trained professionals only. Please ensure that there is an appropriate area cleared in order to lay out all components, parts, and applicable tools to ensure there is nothing missing or damaged before starting installation... - Page 8 ATTACH CRADLES REQUIRED PARTS NOTE: It is recommended to use more than one person for this step to ensure the lift stays upright at all times. With the ladder assembly standing straight up, slide the Cradle into the cradle support located at the bottom of the ladder assembly as shown in Figure 2 ensuring the holes are aligned.
- Page 9 REQUIRED PARTS ATTACH GRAB RAIL NOTE: It is recommended to use more than one person for HARDWARE QTY: this step to ensure the lift stays upright at all times. 1/4” x 2-1/2" Hex Align the two (2) ends of the Grab Rail so they are in Bolt line with the cylindrical ends of the Cradles and 1/4"...
- Page 10 ATTACH KAYAK BUNKS REQUIRED PARTS NOTE: It is recommended to use more than one person for HARDWARE QTY: this step to ensure the lift stays upright at all times. 3/8” x 4" Carriage Align the two (2) holes in each bunk with the Bolt mounting holes in each cradle as shown in Figure 4.
- Page 11 REQUIRED PARTS (Seawall) NOTE: Before proceeding, please ensure all previous steps were completed to avoid product or bodily damage. HARDWARE QTY: *Not Included* NOTE: Before proceeding to the next step, fully tighten all hardware, fully securing the kayak Launch. NOTE: It is recommended to use lifting equipment to move REQUIRED PARTS (Dock) the assembled Kayak launch Lift.
-
Page 12: Reference Notes
REFERENCE NOTES Kayak Launch Lift Model: Standard INSTALLATION PROVIDER: ___________________________________________________ INSTALLATION DATE: _________________________ INSTALLATION ADDRESS: _______________________________________________________________________________________________________ INSTALLATION CHECKLIST: STEP DATE/TIME INITIAL NOTES SAFETY REQUIREMENTS PART IDENTIFICATION TABLE REQUIRED PARTS & HARDWARE KAYAK LAUNCH MOUNT LOCATION ATTACH CRADLE ATTACH GRAB RAIL ATTACH KAYAK LAUNCH BUNKS MOUNT KAYAK LAUNCH FINAL HARDWARE/ OPERATION CHECK...
