Page 1
All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp.
Ecosystem Partners, and to facilitate the development of additional partner projects. The kit design to use the RA2L1 MCU with LQFP 48pin package as the core logic device, with OPAMP and power devices chosen from the Renesas product portfolio.
Renesas VUI Reference Solution VOICE-RA2L1 Engineering Manual 4. Kit Peripheral Features Following is a list of the specific features that have been implemented: ⚫ PMOD: 1 Digilent PMOD connectors, supporting UART, SPI and I2C configurations. ⚫ Microphones: 1 I2S MEMS digital microphones and 2 MEMS analog microphones, distance between each pair of microphones is 50mm which is suitable for beamforming applications.
Page 6
Renesas VUI Reference Solution VOICE-RA2L1 Engineering Manual • SRAM parity error check • Flash area protection • ADC self-diagnosis function • Clock Frequency Accuracy Measurement Circuit (CAC) • Cyclic Redundancy Check (CRC) calculator • Data Operation Circuit (DOC) • Port Output Enable for GPT (POEG) •...
Renesas VUI Reference Solution VOICE-RA2L1 Engineering Manual 6.2 Jumper Settings Two types of jumpers are provided on the VOICE-RA2L1 board. 1. Traditional pin header jumpers copper jumpers 2. Copper jumpers (trace-cut type and solder bridge type) 6.2.1 Traditional Pin Header Jumpers These jumpers are traditional small pitch jumpers that require an external shunt to open/close them.
This board includes a pair of analog MEMS microphones (M2 & M3, ZillTek ZTS6053). These 2 analog microphone signals are amplified by Renesas READ2302GSP OPAMP, then fed to RA2L1 ADC channels 0 & 1. One digital I2S MEMS microphone (M1, ZillTek ZTS6672) is also provided, which is connected to RA2L1 SPI0 channels.
8.2 Audio out A stereo headphone jack is connected to the MCU DAC. The DAC signals are connected through an OPAMP for drive earphone, which is Renesas READ2302GSP, in ultra-small 8 pins TSSOP packages. Table 8. Headphone Jack Pin Assignments...
The J-Link On-Board (JLOB) debug interface supporting JTAG, SWD debug interface and also supports the VCOM (Virtual COM port) function. The debug MCU is a Renesas RA4M2, programmed with J-Link firmware licensed by Segger. This interface includes one USB micro-B connector (J6) for host debug through the J- Link MCU, one 10-pin and one 20-pin debug header (supporting JTAG and SWD).
Renesas VUI Reference Solution VOICE-RA2L1 Engineering Manual 8.6 Power 5V may be supplied from an external USB host to the USB Debug connector (J6) labelled with J-Link OB on the board or from USB type-C connector(J1) labelled with USB-C. Figure 5. VOICE-RA2L1 Power Block Diagram 8.7 USB Type-C...
Renesas VUI Reference Solution VOICE-RA2L1 Engineering Manual 9. Certifications To support international distribution, the following certification requirements are met, both by design and test. Americas: FCC Class B Europe: CE Class B Revision History Description Rev. Date Page Summary September 2022 Initial release VOICE-RA2L1 Engineering Manual Rev.1.0...
Page 16
Engineering Manual for Project VOICE-RA2L1 Publication Date: September, 18, 2022 Published by: Renesas Electronics Corporation...
