Laica GERM STOP Quick Start Manual

1
5
7
9
UNSCREW
and REMOVE
Germ-STOP
Ready for use
10
and REMOVE
x5
Germ-STOP
Ready for use
REPEAT THESE OPERATIONS ALSO IN CASE YOU DON'T USE THE SYSTEM FOR 15 DAYS
若15天以上未使用本產品，請重複以上操作 。
若15天以上未使用本产品，请重复以上操作 。
SİSTEMİ 15 GÜN KULLANMADIYSANIZ YİNE BU İŞLEMLERİ TEKRARLAYIN
ULTRA-FILTRATION SYSTEM
EN
Dear customer, Laica wishes to thank you for choosing this product, designed for reliability and quality to provide complete satisfaction.
IMPORTANT
READ CAREFULLY BEFORE USING
KEEP FOR FUTURE REFERENCE
The instruction manual must be considered an integral part of the product and must be kept for its entire life.
If the appliance is transferred to another owner, its documentation must also be transferred in its entirety.
To ensure the safe and correct use of the product, the user must carefully read the instructions and warnings contained in the manual insofar as they provide
important information regarding safety, user and maintenance instructions. If you lose the instruction manual or require further information or explanations,
please contact Laica at the following address: Laica S.p.A. - Viale del Lavoro, 10 - 36048 Barbarano Mossano (VI) - Italy
Phone +39 0444 795314 - info@laica.com - www.laica.com
Germ-STOP filter is made to be used in Predator Water Filtration System, and other Laica Ultrafiltration Systems, together with Biflux cartridge.
GENERAL WARNINGS ON SAFETY OF YOUR LAICA ULTRA-FILTRATION SYSTEM
• Prior to use, ensure the product is intact and that there is no visible damage. If in doubt, refrain from using the device and contact your retailer.
• Keep the plastic bag out of reach of children: danger of suffocation.
• Follow the instructions of the present manual. Failure to do so may affect the product safety or damage the product itself.
• This product must be used only for its intended purpose which is DEVICE TO TREAT POTABLE WATER and according to the instructions for use. All
other types of use shall be considered inappropriate and therefore hazardous.
• Do not use this product for the production of potable water.
• In case of Authorities warning to boil the tap water for safety against a temporary contamination risk, also the water filtered with this filtration system
must be boiled.
• When Authorities declare that the tap water is potable and safe again, both Biflux cartridge and Germ-STOP filter must be replaced.
• People affected by specific diseases, allergies or following controlled diets should refer to a doctor before using the ultra-filtration system.
NEVER use the ultra-filtration system with previously treated water.
•
• In the case of emergency situations reported by the competent authorities, contact the competent authority in your area for further information.
NEVER tamper with or break the filter for any reason.
•
• The manufacturer shall not be deemed liable for any damage caused by inappropriate or incorrect use.
• This device may be used by anyone aged 12 years and over.
• Children and individuals with physical, sensory or mental disabilities or unskilled people, may use and perform maintenance on the product only under
adult supervision. Children must not play with the device.
• Product cleaning and maintenance must only be performed by adults.
• In the event of failure or poor operation, contact an authorized dealer. Information on technical support can be requested by contacting info@laica.
com.
• Handle the product with care, protect it against accidental impact, extreme temperature fluctuations, dust, direct sunlight and sources of heat.
• Keep the device away from the stove, electric hot plate, oven or flammable materials.
• NEVER use in a microwave oven.
NEVER expose the product to weather (rain, sun).
•
• Do not insert any objects into openings.
• NEVER filter hot water.
• Only filter cold running water from the household mains, always already filtered by Bi-flux cartridge.
NEVER put the device into a working disinfection cabinet.
•
• NEVER freeze the device.
• This device is not intended for professional use, but rather only for domestic use
IMPORTANT:
1) Always remove the Germ-STOP filter and Bi-flux cartridge before washing the hopper.
N.B. The filter may be difficult to remove: this is normal because, due to safety issues, the filter adheres to the hopper
in order to prevent unwanted leakages. DO NOT WASH THE CARTRIDGE AND FILTER WITH SOAP OR DETERGENTS.
2) Never wash Germ Stop filter with tap water and never filter directly tap water with Germ-STOP filter.
Always use water already filtered by Bi-flux cartridge.
IMPORTANT NOTES FOR PRODUCT USE
This system is for use on water supplies that have been treated to public water system standards or that otherwise are determined to be microbiologically
safe as demonstrated by routine testing. This system has been tested to demonstrate protection against intermittent accidental microbiological contamination
of otherwise safe drinking water.
Germ-STOP is effective in the mechanical block of bacteria, that may be present in the municipal potable water for accidental situations. Germ-STOP flow
rate and life time may vary depending on the quantity, quality and temperature of the filtered water.
Declaration of conformity:
Filtration systems produced by Laica are compliant with the following standards:
• Ministry Decree no. 174 dated 6/04/2004 regarding materials and objects that may be used in collection, treatment, supply and distribution systems
for water intended for human consumption.
• Legislative Decree no. 31 dated February 2, 2001, Italian transposition of the Directive 98/83/EC related to water meant for human consumption.
• Regulation (EU) 1935/2004 regarding materials in contact with food.
• Regulation (EU) 10/2011 regarding plastic materials and objects intended to come in contact with food.
PREPARATION OF Germ-STOP FILTER
Germ-STOP filter (fig. 1) must be activated using the Germ-STOP Activation pump (fig. 2), a manual piston-type module made of two components: a
cylinder (fig. 3A) and a piston (fig. 3B), which is supplied with your Laica Ultrafiltration System.
The Germ-STOP Activation pump is also available as spare by authorized dealers.
1) Before preparing the device, wash your hands thoroughly with water and soap.
2) Remove Germ-STOP filter from its bag.
3) Use a clean dish or surface to place the filter. Never work in dirty conditions.
4) Remove the Activation pump from its bag and never place it on dirty surfaces during operation.
5) Hook the Germ-STOP filter to the Germ-STOP Activation pump by screwing it to its cylinder (fig. 4 and 5).
6) Fill the cylinder, once hooked to the filter, with cold potable previously boiled water or bottle water (fig. 6).
NEVER USE UNBOILED TAP WATER.
7) Take the piston and push it downwards inside the cylinder strongly enough to make the water go out from the Germ-STOP filter and then pull it upwards
(fig. 7 and 8).
8) Repeat points 6 and 7 for 3 times. Important: make sure to never push the piston downwards inside the cylinder if it is still empty and not filled with
cold tap boiled water, in order to avoid any air to enter.
9) Unscrew the Germ-STOP filter from the cylinder of the activation pump (fig. 9).
10) Assemble the Germ-STOP filter to the bottom of the hopper by screwing it (fig. 10).
11) Place the hopper into the ultrafiltration system.
Your Laica ultrafiltration system is now ready to be completed with the Bi-flux cartridge (for Bi-flux cartridge preparation, follow the specific paragraph in
the Instruction Manual of your Laica Ultrafiltration System).
FILTER LIFE-TIME
Germ-STOP filter: Germ-STOP blocks bacteria and suspended particles (water turbidity). The cartridge stops working when its hollow fibers pores are
completely blocked. Tests carried out with challenge water with a 30 FAU turbidity indicate a life-time of 1000 Liters.
FILTER REPLACEMENT
Germ-STOP filter: For replacement of the filter remove it from the hopper by unscrewing it as shown in fig. 11 and repeat the operations as indicated in
the section "ULTRA FILTRATION SYSTEM PREPARATION - PREPARATION OF Germ-STOP FILTER".
TROUBLE SHOOTING
PROBLEM
The water flow slows
down until stopping
DISPOSAL PROCEDURE
Dispose the Germ-STOP Filter as solid municipal waste.
TW TW
TW
親愛的客戶，感謝您選擇LAICA，我們將提供您安全可靠的產品，及完美的使用體驗。
重要
請在使用前仔細閱讀說明書
TW TW
請保留說明書以便隨時翻閱
使用說明書被視為產品的一部分，請妥善保存。
若設備轉讓給其他使用者，則說明書也須一併轉讓。
為確保產品被正確且安全地使用，用戶需仔細閱讀說明書中的說明和警告，並留意有關安全事項、使用方式、保養維修的
重要訊息。
若您遺失本說明書，請透過以下方式聯繫LAICA
台灣萊卡股份有限公司
231新北市新店區北新路三段207-1號2樓
客服電話: 0800-366-055
www.laica.com.tw
LAICA除菌濾水系統之一般性安全警告
• 使用前請確認產品之完整性；若有明顯損壞，請勿使用本產品，並聯繫您的零售商。
• 請將塑膠袋放置於遠離兒童處，避免窒息危險。
• 為避免影響使用安全或造成產品損壞，請遵循使用說明。
• 本產品僅適用於預設用途，即處理飲用水，並根據說明使用。
請勿用作其他用途，避免造成危險。
• 請勿使用本產品大量生產飲用水。
• 若當地主管機關發布通知，需將飲用水煮沸以避免暫時的汙染風險，則本過濾系統過濾後的飲用水也必需煮沸。
• 若當地主管機關宣布汙染問題排除後，需按照"除菌濾水系統使用前準備"章節進行清潔，並更換 Bi-flux 雙流濾芯及
Germ-STOP除菌濾芯。
• 特定疾病、過敏、或飲食控制影響人士，使用本產品前應先諮詢醫生。
• 切勿使用經特殊處理的水源。
• 若當地主管機關公告緊急情況，請與該機關連繫以獲取更多訊息。
• 切勿因任何原因自行改造或拆解、破壞濾芯。
• 任何其他不正當使用方式所造成之危險或危害，製造商不負擔任何責任。
• 此設備僅供12歲以上人員使用。
• 肢體、感官、精神殘疾人士或不熟悉產品操作者，請於成人之監督下使用此產品，並請勿讓孩童玩弄此產品。
• 產品之清潔及維護請由成人進行。
• 若產品發生故障，請關閉設備、拔除電源，請勿自行拆解，請聯繫您的零售商進行維修。有關技術問題請聯繫info@laica.
com.tw 或 info@laica.com
• 請妥善保存產品，防止意外碰撞、極端溫度變化、灰塵、陽光直曬、並遠離熱源。
• 請使產品遠離瓦斯爐、電熱板、烤箱等熱源或易燃物品。
• 切勿將本產品放入微波爐。
• 切勿將本產品暴露於不良環境下(如下雨、太陽直曬)。
• 請勿將異物插入開口中。
• 切勿過濾熱水。
• 僅供過濾經Bi-flux高效雙流濾芯過濾後之家庭自來水。
• 切勿將本產品放入消毒櫃消毒。
• 切勿冷凍本產品。
• 產品僅限家用，請勿作商業用途。
Stop 99,999% of germs
for safe drinking water
Preparation of Germ-STOP
2
B
A
6
ONLY
BOILED
NEVER USE UNBOILED TAP WATER
切勿使用未煮沸之自來水。
切勿使用未煮沸之自来水。
KAYNATILMAMIŞ MUSLUK SUYUNDA KESİNLİKLE KULLANMAYIN
8
PUSH
PUSH
UNSCREW
and REMOVE
UNSCREW
Germ-STOP
and REMOVE
Ready for use
ON
Germ-STOP
Ready for use
ATTENTION! MANDATORY:
注意！強制性！
注意！强制性！
DİKKAT! ZORUNLU:
At FIRST USE
第一次使用時:
第一次使用时:
İLK KULLANIMDA
UNSCREW
1) Fill the hopper with cold mains water up to the top level of the same and allow
EN
filtering without closing the lid.
2) Discard the water filtered in the previous section (or use it to water your plants).
3) Repeat the operation until 5 L have been filtered and discarded.
L
1) 將濾芯槽加滿冷水並讓水流過濾芯進入壺中，此時不需要蓋上壺蓋。
TW
2) 將過濾的水倒掉(或用來澆花)。
3) 重複此操作直到過濾超過5公升。
1) 将滤芯槽加满冷水并让水流过滤芯进入壶中，此时不需要盖上壶盖。
CN
2) 将过滤的水倒掉(或用来浇花)。
3) 重复此操作直到过滤超过5公升。
1) Hazneyi en üst seviyesine kadar soğuk şebeke suyuyla doldurun ve kapağı
TU
kapatmadan filtreleme yapmasına izin verin.
2) Önceki bölümde filtrelenen suyu atın (veya bitkilerinizi sulamakta kullanın).
3) 5 L su süzülüp atılana kadar bu işlemi tekrarlayın.
POTENTIAL CAUSE
1) Germ-STOP filter life time has elapsed.
2) Germ-STOP filter is new but it has not been
activated properly.
3
A
cylinder
or
PULL
PULL
* Tests carried out by Accredited Laboratories on
PUSH PULL
Escherichia Coli ATCC 25922 (WDCM 00013),
PUSH
Legionella pneumophila ATCC 33152 (WDCM
00107), Pseudomonas aeruginosa ATCC 9027
(WDCM 00026) and Staphylococcus aureus ATCC
25923 (WDCM 00034).
11
*
B
piston
ONLY
BOILED
BOTTLE
WATER
PUSH
PUSH
PUSH
PULL
PUSH
SOLUTION
1) Replace Germ-STOP filter with a new one.
2) Repeat the procedure described in the section
"PREPARATION OF Germ-STOP FILTER"
4
BOTTLE
or
WATER
PULL
PULL
PULL
UNSCRE
and REM
Germ-S
Ready fo
PUSH
PULL
OF
UNS
and R
Germ
Read
