Harman JBL TUNE125BT Quick Start Guide

WHAT'S IN THE BOX


HOW TO WEAR

HOW TO WEAR

POWER ON & CONNECT

POWER ON & CONNECT

  1. Power on and automatically enter pairing mode
  2. Сhoose "JBL TUNE125BT" to connect

BUTTON COMMAND

BUTTON COMMAND

SIRI® google assistant bixby

MULTI-POINT CONNECTION

MULTI-POINT CONNECTION - Enter pairing mode with the 2nd device
(Maximum 2 devices)
Enter pairing mode with the 2nd device


MULTI-POINT CONNECTION
1st Bluetooth device --> Choose "JBL TUNE125BT" to connect --> 2nd bluetooth device

  1. To switch music source, pause the music on the current device and select play on the 2nd device.
  2. Phone call will always take priority.
  3. If one device goes out of bluetooth range or powers off, you may need to manually reconnect the remaining device.
  4. SELECT "forget this device" on your bluetooth devices to disconnect multi-point.

CHARGING

CHARGING

LED BEHAVIORS

LED BEHAVIORS

TECH SPEC

Model: TUNE125BT
Model: Driver Size: 8.6 mm / 0.34'' Dynamic driver
Power supply: 5 V 1 A
Weight: 18.3 g / 0.04 lbs
Weight: Headset battery type: Lithium-ion battery (3.7 V / 130 mAh)
Charging time: < 2 hrs
Charging time: Music playtime with BT on: up to 16 hrs
Frequency response: 20 Hz – 20 kHz
Impedance: 16 ohm
Sensitivity: 95 dB SPL @1kHz 1mw
Microphone sensitivity: -29 dBV/Pa @1kHz
Bluetooth version: 5.0
Bluetooth profile version: HFP 1.7, A2DP 1.3, AVRCP 1.6
Bluetooth transmitter frequency range: 2.4 GHz- 2.4835 GHz
Bluetooth transmitted power: < 6 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Maximum operation temperature: 45°C
