Page 1 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E Manufacturer: KAESER KOMPRESSOREN SE 96410 Coburg • PO Box 2143 • GERMANY • Tel. +49-(0)9561-6400 • Fax +49-(0)9561-640130 www.kaeser.com...
Page 2 /KKW/SSC 2.12 en IBA-SIGMA CONTROL FLUID /KKW/SSC 2.12 20210526 085236...
Page 3: Table Of Contents
Contents SIGMA CONTROL 2 Quick reference guide Operating elements ......................Indicator elements ......................Main menu overview ......................Functions overview ......................Regarding this document Using this document ......................Copyright .......................... 2.2.1 Software ......................Certification ........................Updating the operating manual ..................Symbols and labels ......................
Page 4 Control modes ........................105 8.7.1 Setting the control mode ..................105 8.7.2 Setting the DUAL control mode ................106 8.7.3 Setting the QUADRO control mode ..............107 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 5 9.8.1 Checking the operating hours ................184 9.8.2 Checking the switching cycles ................185 Displaying the frequency converter settings ..............9.10 Setting the maintenance interval ..................187 User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 6 12.4 Displaying the version number, machine model, material number and serial number ..233 Decommissioning, Storage and Transport 13.1 De-commissioning ......................235 13.2 Packing ..........................13.3 Storage ..........................235 13.4 Transporting ........................235 13.5 Battery removal and disposal ................... 235 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 7 Insert the communication module....................Fig. 36 Front plate communication module PROFIBUS ................. 130 Fig. 37 Direct connection of two SIGMA CONTROL 2 ................135 Fig. 38 LOAD remote contact ......................... 141 Fig. 39 Wiring diagram for local/LOAD remote contact: ................. 143 Fig.
Page 8 List of Illustrations User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 9 Possible settings for the temperature unit .................. Tab. 51 Display illumination ........................Tab. 52 Network parameters ........................Tab. 53 E-mail parameters ........................Tab. 54 Control key functions ........................User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 10 Warning messages and remedies ....................207 Tab. 91 Operational messages ....................... Tab. 92 System messages and remedies ....................230 Tab. 93 KAESER i.Box − Operating states and troubleshooting ............. 231 User Manual Controller viii SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 11: Sigma Control 2 Quick Reference Guide
SIGMA CONTROL 2 Quick reference guide Operating elements 1 SIGMA CONTROL 2 Quick reference guide Operating elements Fig. 1 Operating elements Item Designation Function «Up» Scrolls the menu up. Increases a parameter value. «Left» Jumps to the left. Moves the cursor position to the left.
Page 12: Indicator Elements
SIGMA CONTROL 2 Quick reference guide Indicator elements Indicator elements Fig. 2 Indicator elements Item Designation Function Indicator illuminates in green when the machine is switched on. Display Graphic display with 8 lines and 30 characters per line. Time control Illuminates continuously in green when the machine is controlled by the timer.
Page 13: Main Menu Overview
SIGMA CONTROL 2 Quick reference guide Main menu overview Main menu overview Press «Up» / «Down» / «Enter» to open the main menu. Menu no. Menu name Function Status Displays messages, statistics and status information Performance data Displays measured data from the machine and its components (e.g.
Page 14: Tab. 4 Functions Overview
SIGMA CONTROL 2 Quick reference guide Functions overview Function Menu Steps Chapter <Compressor clock – Key clock – ☑> Activate 8.6.1.3 «time control» Activates the – Activate the «Time control» key – Press the «Time control» 8.6.1.4 «time control» <Configuration – Compressor start – Compressor on – Key Activate 5.2.3...
Page 15 SIGMA CONTROL 2 Quick reference guide Functions overview Settings can be entered following log-in with an RFID Equipment Card providing access level User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 16: Regarding This Document Using This Document
The licenses can also be found under this address: http://www.gnu.org/licenses http://code.google.com/p/curve25519-donna/ Within three years from receipt of SIGMA CONTROL 2, you may obtain the complete source code of the copyright-protected software packages by sending a corresponding order to the following ad‐ dress: D&D Electrical Design...
Page 17: Certification
➤ Please note the symbols and labels used in this document. 2.5.1 Warnings Warnings indicate danger potentially resulting in personal injury, if the measures specified are not taken. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 18: Potential Damage Warnings
Potential effects when ignoring the warning are indicated here. ➤ The protective measures against the damages are shown here. ➤ Carefully read and fully comply with warnings against damages. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 19: Other Alert Notes And Their Symbols
➤ ... as is a solution. This symbol identifies important information or measures regarding the protection of the envi‐ ronment. Further information Further subjects are introduced here. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 20: Technical Specifications 3.1 Controller Sigma Control 2
Battery-buffered real-time clock ─ Battery service life: more than 10 years ─ Battery replaceable 3.1.1 Versions and Options SIGMA CONTROL 2 is offered in different designs. Type Prepared for connection to control Connection to control technology not centre provided Option Compo‐...
Page 21: Fig. 3 Mcs Interfaces
SD card, SD card slot SD/SDHC card Functional earth (FE) The positions of the interfaces X1–X6 are marked on the rear of the controller. Tab. 11 MCS interfaces User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 22: Fig. 4 Mcsio Interfaces
The positions of the interfaces X1–X10 are marked on the rear of the controller. Tab. 12 MCSIO interfaces Identification with RFID Equipment Card Characteristic Value Hardware on the SIGMA CONTROL 2 controller RFID write/read device Hardware (external) RFID Equipment Card Recognition distance [m] max. 0.05...
Page 23: In- And Outputs With Mcsio
The number of input/output modules actually available depends on the machine type and the avail‐ able options. Refer to the machine's wiring diagram for the input/output modules installed in your equipment. Every input/output module is equipped with: ■ Internal temperature monitoring User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 24: Tab. 16 Sc2Iom-1
Digital output relay (DOR), 250 VAC, 8 A – – Digital output transistor (DOT), 24 VDC, 0.5 A – Analogue output current (AOI), 0–20 mA – – Tab. 18 SC2IOM-3 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 25: Sensors
Power is provided by the machine's power supply unit. Characteristic Value Rated voltage (stabilised) [V DC] Current consump‐ tion SIGMA CONTROL 2 with IOM 1 [A] Current consumption IOM 2 [A] Current consumption IOM 3 [A] IOM ≙ Input/Output module Tab. 19 Power supply specifications 3.1.4.2...
Page 26: Kaeser I.box
Modem i.Box EMEA (Europe, Middle East and Africa) 7.7822.00170 Modem i.Box NA (North America) 7.7822.00180 Modem i.Box LATAM (Latin America) Tab. 25 Modem i.Box − versions and options User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 27: Indicator Elements And Interfaces
Mobile communication equipment: EN301511 v12.5.1; EN301908 v13.1.1 EMC: EN 301489-1 v2.2.0 General Section; EN 301489-52 v0.0.7; DIN EN 61326-1 - 2018-09 Security: DIN EN 61010-1:2020-03; VDE 0411-1:2020-03 User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 28: Tab. 26 Technical Data Kaeser I.box
LAN: 3 x RJ45, 10/100Base-TX Mini-USB socket, USB 2.0 (for service purposes only) Antenna SMA (F), 50 Ohm SIM card Mini-SIM with ejection button Tab. 26 Technical data KAESER i.Box User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 29: Safety And Responsibility Basic Instructions
The safety regulations of the machine in which SIGMA CONTROL 2 is installed apply. Specified use SIGMA CONTROL 2 is solely intended for the control of machines in which SIGMA CONTROL 2 is factory-installed. Any other use is considered incorrect. The manufacturer is not liable for any dam‐...
Page 30: Design And Function
─ Without slot for customer interface ■ Input-Output-Module (IOM): For SIGMA CONTROL 2 (Prepared for connection to control centre): modules with digital and analogue inputs and outputs with autonomous power supply. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 31: Fig. 6 Mcs System Design With Iom
MCS system design with IOM Machine enclosure Inputs/outputs in the interior of the control Control cabinet cabinet SIGMA CONTROL 2 (Prepared for con‐ Inputs/outputs in the interior of the com‐ nection to control centre) pressor Input-Output-Module (IOM): Inputs/outputs for external sensors...
Page 32: Operating Panel
Exits the edit mode and saves. «ON» Switches the machine on. «OFF» Switches the machine off. RFID RFID reader for user log-in with RFID Equipment Card. not for SXC User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 33: Display Elements
Continuous green light when voltage is applied to the controller. controller Warning Flashes in yellow in the following events: ■ Maintenance necessary ■ Warning message not for SXC User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 34: Rfid Reader
Placing a suitable transponder in front of the RFID reader of the controller will automatically acti‐ vate the communication between transponder and SIGMA CONTROL 2. A suitable transponder is the RFID Equipment Card. Two of them have been provided with the ma‐...
Page 35: Operating Mode
Lines 7 and 8: Machine state The following parameters with their current values are displayed in lines 7 and 8: ■ The hours during which the machine was activated User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 36: Main Menu
The «Enter» key affects only the active line. In some lines, you can change more than one parameter. In this case, you must first select the specific parameter with the «Left» or «Right» keys. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 37: Activating Keys With Check Boxes
5.3.4 Activating keys with check boxes Certain keys of the SIGMA CONTROL 2 are locked by default. Activate the corresponding check boxes in the active line of the display to unlock these keys. First, press «Enter» to switch into setting mode. The check box will flash.
Page 38: Kaeser Connect
To do so, you must generate a one-time password (see Chapter 8.2.5). KAESER CONNECT does not require additional software for this purpose. The display language for KAESER CONNECT can be set independently of the language used in the SIGMA CONTROL 2. Fig. 11...
Page 39: Kaeser I.box
The KAESER i.Box is a data transmission component for machines equipped with the SIGMA CONTROL 2. It is arranged between the KAESER controller (SIGMA CONTROL 2) and the KAESER PLANT CONTROL CENTER. It is connected on the one side to the KAESER controller via Ethernet and, on the other, with the wireless network.
Page 40: Menu Overview
Material number and serial number of the controller PN: y.yyyyyy SN: x.xx.xx Software version Software: ABC_V.V.V Subsequently, the software is loaded and the current operating mode is displayed (example): User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 41: Menu Structure
Enter customer-specific settings The menus shown require access level 2. Depending on the software version of SIGMA CONTROL 2, machine type and available op‐ tions, only the menus that are available for this particular machine will be displayed. Main menu...
Page 42 1) 4) ■ Analogue values ■ SIGMA CONTROL 2 Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 43 Configuration menu, please 5 Configuration For details of the see table 36. Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 44: Tab. 34 Menu Structure Of Main Menu
Power switching Components menu, please For details of the see table 41. Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID Tab. 34 Menu structure of main menu User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 45 1) 4) Speed limits 1) 4) Power switching with frequency converter Only visible in the event of a parameterization error SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC User Manual Controller No.: 9_9450 12 E...
Page 46: Tab. 35 Status Menu
1.7 pN/n curve 1) 4) Nominal pressure/Speed Power switching with frequency converter Only visible in the event of a parameterization error SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC Status menu Tab. 35...
Page 47 Date format Time format Pressure unit Temperature unit Display lighting Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC Power switching aircooler fan with frequency converter User Manual Controller No.: 9_9450 12 E...
Page 48 ADT controller ■ Oil cooler ■ Heat recovery Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC Power switching aircooler fan with frequency converter User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 49 Actual value Controller parameter KP/KI/KD Actual values P/I/D/Y Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC Power switching aircooler fan with frequency converter User Manual Controller No.: 9_9450 12 E...
Page 50: Tab. 36 Configuration Menu
Save data Eject SD card Status Format SD card Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID not for SXC Power switching aircooler fan with frequency converter Configuration menu Tab. 36...
Page 51: Tab. 37 Pressure Control Menu
For sensor error: Type of message: Warning Alarm Power switching with frequency converter SIGMA CONTROL 2 FLUID SIGMA CONTROL 2 VAC not for SXC Pressure control menu Tab. 37 User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 52 Group warning interrupted DOR/DOT Remote mode DOR/DOT Clock active DOR/DOT ■ Clock contact DOR/DOT EMERGENCY STOP DOR/DOT Power switching with frequency converter SIGMA CONTROL 2 FLUID not for SXC User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 53 External message 3 ■ External message 4 ■ External message 5 ■ External message 6 Power switching with frequency converter SIGMA CONTROL 2 FLUID not for SXC User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 54: Tab. 38 I/O Periphery Menu
Inlet temperature ■ PD temperature ■ n Compressor motor 1) 4) Power switching with frequency converter SIGMA CONTROL 2 FLUID not for SXC I/O periphery menu Tab. 38 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 55 SMTP Server: User name: Password: ─ Port/Timeout Resend after: ─ Retry attempts: MAC: MAC address SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 56: Tab. 39 Communication Menu
■ Modbus ■ Modbus TCP ■ DeviceNet ■ PROFINET ■ EtherNet/IP SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID Communication menu Tab. 39 Connections menu 5.7.2.4 Navigation Function / Submenu 8.1.2 Connections ■ SIGMA CONTROL 2 ─...
Page 57: Tab. 41 Components Menu
Power switching menu, please For details of the see table 42. Power switching with frequency converter SIGMA CONTROL 2 (Prepared for connection to control centre) SIGMA CONTROL 2 FLUID Power switching with frequency converter and speed sensor is being used Tab. 41...
Page 58 ─ Run-up period T↑ ─ Run-up period T↓ ─ ready ─ Mains contactor/Alarm td ─ Redundancy contactor/Alarm td Power switching with frequency converter SIGMA CONTROL 2 FLUID User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 59: Tab. 42 Power Switching Menu
FC USS or Speed sensor All is activated Selection Speed set point manual Power switching with frequency converter and STO being used in the operating mode Tab. 42 Power switching menu User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 60: Operating Points And Control Modes
The machine-dependant venting phase between the LOAD and READY operating points ensures load changes at minimum material stresses. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 61 Design and Function Operating points and control modes The controller SIGMA CONTROL 2 can operate in the following control modes: ■ DUAL ■ QUADRO ■ VARIO ■ CONTINUOUS ■ DYNAMIC Option C1 ■ MODULATING control DUAL In the DUAL control mode, the machine is switched back and forth between LOAD and IDLE to maintain the machine working pressure between the preset minimum and maximum values.
Page 62: Variable Speed Drive With Frequency Converter (Sfc)
If the network pressure falls below the TARGET value: SIGMA CONTROL 2 runs the motor up to a speed at which air delivery matches the air demand. The above description is valid only when the Pressure control option is set to Local mode: in the menu:10.1.1 Power switching .
Page 63: Modulating Control
The load and power consumption of the drive motor rises and falls with the air demand. To ensure optimal control on large compressors, the control air for the proportional controller is tak‐ en from an external air receiver. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 64: Installation And Operating Conditions
Direct sunlight (UV radiation) can destroy the display screen. ➤ Do not allow the display screen to be subjected to direct sunlight. ➤ See the machine's operating manual for required conditions. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 65: Installation
Assembly of the KAESER i.Box Assembly of the KAESER i.Box is carried out ex works for new machines or, for existing machines with the SIGMA CONTROL 2 control system, through the authorised service partner with a retrofit kit (see Chapter 3 Technical data).
Page 66: Initial Start-Up Outline
8 Initial Start-up Outline SIGMA CONTROL 2 was designed and developed for a number of applications. The settings that can be made are correspondingly varied. It is possible that only a few of these settings are needed for the initial start-up. This depends on the application involved.
Page 67: Selecting Menu Options
All menu options can be selected with the «Down», «Up» and «Enter» keys. Example: Open the < Configuration – General > menu. 1. Switch on the machine and wait for SIGMA CONTROL 2 to start. The operating mode is displayed.
Page 68: Setting The Language
7. Use the «Up» or «Down» key to select a menu item in the information . 8. Press «Escape» repeatedly to leave this menu. 8.2.2 Setting the language You can choose and set the user interface language for SIGMA CONTROL 2: Arabic Estonian Italian Norwegian...
Page 69: Noting The User Name
8.2.3 Noting the user name user name displayed on The number of your RFID Equipment Card is identical with the SIGMA CONTROL 2 after you have successfully logged on using your RFID Equip‐ ment Card. User Manual Controller No.: 9_9450 12 E...
Page 70: User Log-In With Rfid Equipment Card
SIGMA CONTROL 2 (see chapter 8.2.5). 8.2.4 User log-in with RFID Equipment Card The RFID Equipment Card enables an easy and quick log-in at SIGMA CONTROL 2. It authorises you to access advanced functions of the controller. Advanced access rights allow you to: ■...
Page 71: Generating A Password
SIGMA CONTROL 2. Note this generated password as well, and store it a suitable location. If your RFID Equipment Card is damaged or lost, the card won't be nec‐ essary to manually log on to SIGMA CONTROL 2 when you have these two pieces of information. Precondition Any menu is displayed Fig.
Page 72: Manual User Log-In
2. Use «Up» or «Down» to select the 3. Press «Enter». The setting mode is active. A column with alphanumeric characters is displayed. The selected character flashes. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 73: Create The Master Rfid Equipment Card
11. Use «Up» or «Down» to select the 12. Press «Enter». Current access level: 2 is displayed. Result You are now logged on to SIGMA CONTROL 2 with access level 2, having manually input your user name and the password. 8.2.7 Create the master RFID Equipment Card If you are running several KAESER machines with the SIGMA CONTROL 2 control it may make sense to create a master RFID Equipment Card with which you can log onto all machines.
Page 74: Checking/Setting Time And Date
See chapter 8.2.16. <Configuration – General> menu. 1. Open the 5.1 Date/time line. 2. Use «Up» or «Down» to select the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 75 4. Press «Enter». 00.00.00 flashes. The display for days 5. Use «Up» or «Down» to set the day. 6. Press the «Right» arrow. 00.00.00 flashes. The display for months User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 76: Set The Time Zone
11. Press «Escape» repeatedly to leave this menu. 8.2.9 Set the time zone Set the time zone for the SIGMA CONTROL 2 to ensure the timely automatic conversion from win‐ ter time (standard time) to daylight savings time, for example. Precondition Access level 2 is activated.
Page 77: Tab. 48 Possible Settings For The Time Format
8 0 ° C Menu 5.1 General Europe/London ········· ▶2 Time server ········· Date format MM/DD/YY time format Time format hh:mm:ssAM/PM 3. Press «Enter». hh:mm:ssAM/PM indication flashes. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 78: Tab. 49 Possible Settings For The Pressure Unit
The display for the set unit flashes. 4. Use «Up» or «Down» to set the unit. 5. Press «Enter». The setting is applied. 6. Press «Escape» repeatedly to leave this menu. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 79: Setting The Display Illumination
Display illumination Precondition Access level 2 is activated. <Configuration – General> menu. 1. Open the 5.1 Display lighting line. 2. Use «Up» or «Down» to select the User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 80: Setting The Contrast And The Brightness
Contrast and brightness are set. 8.2.13 Activating the remote control The «remote control» key on the operating panel of the SIGMA CONTROL 2 can be activated or deactivated. Various menus offer check boxes for this setting. Precondition Access level 2 is activated.
Page 81: Ip Configuration
8.2.14 IP configuration For the SIGMA CONTROL 2 to be connected to the network, you must set the IP configuration (for KAESER CONNECT for example). If you use SIGMA CONTROL 2 as the master control of two machines, you set other network IP configuration menu (see chapter 8.11.4).
Page 82: Tab. 52 Network Parameters
Example address DNS Server 1 008.008.008.008 Example address DNS Server 2 008.008.004.004 Active line Restart network ☐ 12. Press «Enter». The check box Restart network will flash. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 83: Setting The E-Mail Function
The network is restarted. The set network parameters are active. 8.2.15 Setting the e-mail function SIGMA CONTROL 2 is able to send messages per e-mail. For this purpose, a network connection with an SMTP server is required. Setting e-mail parameters Precondition Access level 2 is activated.
Page 84: Tab. 53 E-Mail Parameters
Setting the controller 6. Set the e-mail parameters as described above: If SIGMA CONTROL 2 is connected via SIGMA NETWORK to SAM 4.0 and emails are to be SMTP forwarded via SAM 4.0, then enter the IP address of interface X6 of SAM 4.0 in the Server: field.
Page 85: Setting The Time Server
8.2.16 Setting the time server If SIGMA CONTROL 2 is connected to the network, you can set the access to an SNTP server available in the Internet or a local Intranet. SIGMA CONTROL 2 then automatically imports the date and time settings and ensures continuous synchronisation of the internal clock with the exter‐...
Page 86: Kaeser Connect Benefits
The user name (see chapter 8.2.3) and password (see chapter 8.2.5) are known. The controller's IP address is known, see chapters 8.2.14 and 8.11.4. 1. Use an Ethernet cable to connect SIGMA CONTROL 2 to the Internet-capable device or net‐ work.
Page 87: Fig. 17 Log-In Mask
3. Enter your user name in the 4. Enter your password in the Password: field. 5. Click Login. KAESER CONNECT for SIGMA CONTROL 2 is displayed. Fig. 18 KAESER CONNECT for SIGMA CONTROL 2 6. Click the arrow key to open Select language:.
Page 88: System Status Menu
7. Click to set the selected language Result KAESER CONNECT is displayed in the set language. 8.3.2 System status menu Precondition KAESER CONNECT for SIGMA CONTROL 2 is displayed. System status menu Fig. 20 System status menu element. 1. Click the System status menu is displayed...
Page 89: Graphs Menu
Initial Start-up KAESER CONNECT benefits Fig. 21 Main menu 2. Click in the SIGMA CONTROL 2 display. The Main menu is displayed. 3. Click the numbered lines. The system displays the corresponding sub-menus. 4. Press ESC repeatedly to leave this menu.
Page 90: Fig. 22 Graphs (Illustration Similar)
«End» Display the current data «Refresh» Load and display the entered machine data from start time to end time Tab. 54 Control key functions User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 91: Messages Menu
An SD card with sufficient free memory is inserted in the X5 SD card slot The SD card was inserted for the entire operating time of the machine. The SIGMA CONTROL 2 data recorder function is activated. Start: . 1. Enter the date and time for the start time in the required time period in End: .
Page 92: I/O Display Menu
I/O display menu. Depending on the machine options, you may select from further displayed in the IOM module tabs. Precondition KAESER CONNECT for SIGMA CONTROL 2 is displayed. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 93: User Management Menu
User name: 6 to 16 characters, the second character must not be a number ■ Password: 6 to 16 characters Precondition The generated password is available. KAESER CONNECT for SIGMA CONTROL 2 is displayed. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 94: Fig. 26 User Management Menu
Log on for write access: window User name: field. 3. Enter your user name in the Password: field. 4. Enter your password in the 5. Click OK. User management menu is displayed User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 95: Fig. 28 User Management Menu
1. Click the required user account in the list. Password: field. 2. Enter a new password in the Repeat password: field. 3. Re-enter the same new password in the 4. Click Update user. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 96: Settings Menu
Settings menu Fig. 29 For example, you want to convert your units to US values: Precondition KAESER CONNECT for SIGMA CONTROL 2 is displayed. 1. Click the Settings menu element. 2. Click the arrow key for the unit of pressure.
Page 97: Save Data Menu
Initial Start-up KAESER CONNECT benefits 8.3.8 Save data menu Backup menu allows you to download data from SIGMA CONTROL 2 to the Internet-capable device. The following backup types are available: ■ Backup all ■ Log files ■ Settings ■ User information Precondition KAESER CONNECT for SIGMA CONTROL 2 is displayed.
Page 98: Kaeser Connect Exit
The downloaded data can be sent to an authorised service partner for the purposes of evaluation and service support. 8.3.10 KAESER CONNECT exit In order to close KAESER CONNECTfor SIGMA CONTROL 2, click Logout in the header. ➤ Click Logout. Result The system displays a message confirming the successful logout.
Page 99: Commissioning The Kaeser I.box
■ Switching point verter (SFC) pB or control pressure pB in machines with frequency con‐ ■ Switching point verter (SFC) not for SXC User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 100: Displaying Pressure Parameters
Setpoint pressure Active line pA SP: 8.0bar ¦ SD: −0.5bar pB SP: 7.5bar ¦ SD: −0.4bar ········· System pressure low ☐ ↓ < 5.0bar ¦ SD: 0.50bar User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 101: Setting Pressure Parameters
Setpoint pressure Active line pA SP: 8.0bar ¦ SD: −0.5bar pB SP: 7.5bar ¦ SD: −0.4bar ········· System pressure low ☐ ↓ < 5.0bar ¦ SD: 0.50bar User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 102: Tab. 59 Displaying And Setting Parameters
SD . 4. Use «UP» or «DOWN» to set the required value for 5. Press «Enter». The setting is applied. 6. Press «Escape» repeatedly to leave this menu. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 103: Activating/Deactivating The "Load/Idle" Key
8.5.3 Activating/deactivating the «LOAD/IDLE» key In order to prevent unauthorised users from switching the machine to IDLE (not for SXC), you can deactivate the «LOAD/IDLE» key on the SIGMA CONTROL 2 control panel. Precondition Access level 2 is activated <Configuration – Pressure control – Load control> menu.
Page 104: Machine Start And Machine Stop
8.6.5 "Autostart" function Activated 8.6.6 Tab. 61 Settings for machine start and machine stop 8.6.1 Automatic start/stop in timer mode Overview Compressor clock menu ■ Open the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 105: Tab. 62 User-Defined Clock Programme Machine On/Off
All current switching points are reset Reset : ☐ ········· Active line n.a. 00:00AM n.a. 00:00AM n.a. 00:00AM User-defined clock program No.: Time Function Tab. 62 User-defined clock programme machine ON/OFF User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 106: Tab. 63 Example Of A Machine On/Off Clock Program
3. Press «Enter». n.a. indication flashes. 4. Use «Up» or «Down» to set the weekdays. 5. Press the «Enter» key. The setting is applied. 6. Press the «Right» key. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 107 : ☐ Switching point 01: Mon-Fri 06:30AM Switching point 02 Mon-Fri 12:00PM Switching point 03 Mon-Fri 01:00PM 3. Press the «Up» key. The check box is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 108: Setting The Company Shut-Down
Precondition The «Time control» key is activated; see chapter 8.6.1.3. ➤ Press the «Time control» key on the SIGMA CONTROL 2 operating panel to activate the time control. Time control LED on the operating panel of the SIGMA CONTROL 2 signalises with green Result continuous light that the machine is operated with activated time control.
Page 109 20. Press «Enter». Result In this example, a company shut-down (standstill time) for the time between 12/23/21 / 05:00PM until 01/04/22 / 06:30AM has been set for the machine. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 110: Controlling Machine From A Remote Location
8 0 ° C Menu 5.4.1 Compressor on Local mode: Remote mode: Active line ------------------------------ DI1.07 ☑ Key + remote contact input. 5. Use «Up» or «Down» to set the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 111: Activating The Remote Control
If your entry is rejected it means that the input is already assigned. ➤ Select a different input. 8.6.4 Activating the remote control ➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 112: Venting" Function
To avoid overloading the mains power supply through several machines starting simultaneously a delay period determining the auto start of each machine can be entered. Autostart: function is activated (default setting). User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 113 The first machine may start immediately and does not require a delay time. Machine number Start time [sec] Delay time [sec] –– –– User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 114: Tab. 64 Auto Start Delay Time
6. Press «Escape» repeatedly to leave this menu. Result The delay time for an auto start after a power failure has been adjusted from 10 s to 12 s. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 115: Control Modes
The standard setting of the control mode depends on the machine type. ■ The machine-dependant venting phase between the LOAD and READY operating modes ensures load changes at minimum material stresses. Precondition Access level 2 is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 116: Setting The Dual Control Mode
The shorter the period, the more often the machine will switch from IDLE to READY. SIGMA CONTROL 2 will take into account the maximum motor switching capacity. Depending on the machine type, the compressor motor may not fall below a minimum idling or standstill time.
Page 117: Setting The Quadro Control Mode
Menu 5.3.3 QUADRO Min. run period Set value for minimum run-time Target 240s ¦ Actual ········· Unloaded period Set value for unloaded period Target 240s ¦ Actual User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 118: Electronic Thermal Management
3. Activate the heat recovery only if you can use the machine's exhaust heat. 4. Deactivate the heat recovery if you cannot use the machine's exhaust heat. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 119: Activating The Heat Recovery For Machine Type 2
0 8 : 1 5 A M 8 0 ° C Menu 5.6 ETM Remote mode: remote contact Status of heat recovery current active ------------------------------ Active line DI1.07 ☑ Key remote : ☑ User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 120: Activating The Heat Recovery For Machine Type 3
Further information The setpoint value for the airend discharge temperature for the regulator of the electrically control‐ led heat recovery valve can be set manually; see chapter 8.8.2.1. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 121: Deactivating Heat Recovery
If the heat recovery is set to inactive, you have improved efficiency in compressed air genera‐ tion. ➤ Set the heat recovery to "inactive" if you cannot use the machine's exhaust heat. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 122: Refrigeration Dryer
5.9 Refrigeration dryer Control mode Compressor ready: Active line Continuous Compressor Clk/RC/RB off: ········· 4. Press the «Enter» key. The indicator flashes for the operating mode currently selected. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 123: Output Messages
DOR1.07 ☐¦Logic : DOT1.01 ☐¦Logic : Temperature⇟ DOR1.03 ☐¦Logic : DOT2.01 ☐¦Logic : 3. Press the «Down» key. 4. Press the «Enter» key. Setting mode is active. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 124: Refrigeration Dryer Alarm - Compressed Air Quality Has Priority
8.9.3 Refrigeration dryer alarm – Compressed air quality has priority In the event of a refrigeration dryer alarm, the SIGMA CONTROL 2 shuts the machine down. No compressed air will be delivered. As compressed air quality (i.e. dried compressed air) is crucial, the authorised service partner must be contacted immediately.
Page 125 6. Press the «Enter» key. The setting is applied accordingly. Result The function “Fault mode without refrigeration dryer” is activated. The machine supplies compressed air to connected consumers. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 126: Refrigeration Dryer Alarm - Compressed Air Supply Has Priority
8.10.1 Menu Load control Precondition Access level 2 is activated. <Configuration – Pressure control – Load control> menu. 1. Open the 5.2.3 Load control menu is displayed. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 127: Setting The Nominal Pressure Change Via Timing Program
Base load period: Weekdays from 06:30AM–05:00PM, Fridays 06:30AM–03:00PM ■ Low load period: Midday from 12:00PM–01:00PM and remaining time The timing program is established with the following switching points (maximum 10 switching points available): User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 128 6. Press the «UP» key. The check box is activated. 7. Press the «Enter» key. The timing program is now deleted. Setting the switching point Precondition Access level 2 is activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 129 16. Set the other switching points in the same manner. The timing program is now set. pA/pB Clock : see chapter 8.10.3.3. 17. Select the operating mode User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 130: Setting The Nominal Pressure Change Via Timer
8.10.3.2 Set starting time for pA or pB 1.Start pA line. 1. Use the «Up» or «Down» keys to select the 2. Press the «Right» key. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 131 4. Press the «Up» or «Down» keys to set the desired operating mode ( pA/pB Cycle ). 5. Press «Enter». The setting is applied. 6. Press «Escape» repeatedly to leave this menu. Result The timer setting is completed. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 132: Setting The Machine For Master Control Operation
Examples of timing programs for equal machine loading are given in section 8.11.9. 8.11.2 SAM 4.0 mode You must modify the settings in SIGMA CONTROL 2 for the operation via SIGMA NETWORK us‐ ing, for example, the KAESER SIGMA AIR MANAGER 4.0 (SAM 4.0). User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 133 Setting the machine for master control operation Precondition SIGMA CONTROL 2 is connected to SAM 4.0 via SIGMA NETWORK and ready for operation (see the SAM 4.0 operating manual in the chapter “Installation”) Network pressure pB is set as the pressure for the “SAM 4.0 manual mode".
Page 134 13. Press the «Enter» key. The setting is applied. Result SIGMA CONTROL 2 communicates with SAM 4.0 via SIGMA NETWORK. The communication is working smoothly when neither SIGMA CONTROL 2 nor SAM 4.0 report any communication fault. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 135: Setting Profibus Operation (Sigma Air Manager)
For the communication with SAM 4.0, the value of Start td must be set to 30 s. SIGMA CONTROL 2 can monitor the bus communication at user level. For this purpose, the bus master reads a value ("toggle bit") that changes with every bus cycle and returns it without change.
Page 136: Fig. 32 Wiring Of The Profibus Connection
Pin assignment of SUB-D 9-pole interface on the PROFIBUS module Interface connector wiring Fig. 32 Wiring of the PROFIBUS connection Terminal 1A Terminal 2B Terminal 1B Slide switch, terminating resistor Terminal 2A User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 137: Fig. 33 Electrical Diagram Example With Sigma Air Manager
Initial Start-up 8.11 Setting the machine for master control operation Electrical diagram example with SIGMA AIR MANAGER (extract) Fig. 33 Electrical diagram example with SIGMA AIR MANAGER User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 138: Fig. 34 Communication Interface
Before you can insert the communication module in the X4 interface, you must remove the plastic cover from the SIGMA CONTROL 2 . The designation of the interfaces is provi‐ ded on the rear of the SIGMA CONTROL 2.
Page 139: Fig. 35 Insert The Communication Module
The bus is wired to the bus master. The machine's voltage supply is activated. The machine is parametrised as a slave in the bus master. The bus master is operational. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 140: Fig. 36 Front Plate Communication Module Profibus
8 0 ° C Menu 8.2 Com-Module Status Counter 1 Com-Module deactivated ------------------------------ Type PROFIBUS Send/receive Active line Com-Module active ☑ 6. Press «Escape» repeatedly to leave this menu. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 141 8.2 Com-Module Send/receive Com-Module active ☑ Reset ☐ Active line Slave No. ········· Monitoring for communication malfunction is active. Communication error ☑ 104 is set. Result Slave address User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 142 Communication monitoring is activated Communication error ☑ active line Start td Timeout : ☑ 5. Press «Enter». 00 seconds display flashes. 6. Use «Up» or «Down» to set the seconds. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 143: Interconnection Of Two Machines In Master/Slave Operation
➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. The bus master can remotely control the SIGMA CONTROL 2. 8.11.4 Interconnection of two machines in master/slave operation Example 1 Two machines with different flow rates...
Page 144: Tab. 72 Master-Slave Settings
. See example for the master: The master regulates to set-point pressure pB and con‐ pA . sequently, the slave to To run two machines with SIGMA CONTROL 2 in interconnected operation, both controllers must be equipped with the same software version. ➤ Follow the configuration steps as described in table 72:...
Page 145: Fig. 37 Direct Connection Of Two Sigma Control 2
2. Lead the Ethernet cable through the cable ducts to SIGMA CONTROL 2. Use the wiring path in the 24V range (blue wiring) of the ducts. 3. Attach the RJ45-plug to the cable end. 4. Plug the RJ45 plug into the Ethernet interface X1 of the SIGMA CONTROL 2 until it latches. User Manual Controller No.: 9_9450 12 E...
Page 146 6. If necessary, adjust the value for the Setting the times The following options for load control are are provided by SIGMA CONTROL 2 for selecting times: ■ 1: Time program ■...
Page 147 The IP address of machine 1 (master) is set correctly. <Communication – Ethernet/SIGMA NETWORK – Connections – SIGMA 2. Open the 8.1.2.1 CONTROL 2> menu. Mode line. 3. Use «Up» or «Down» to select the User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 148 SP: 8.2bar ¦ SD: −0.5bar ········· System pressure low ☐ ↓ < 5.0bar ¦ SD: 0.50bar pA value. 3. Use «Up» or «Down» to set the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 149 6. If necessary, adjust the value for the Activating the remote control ➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. Set the remote operating mode Precondition The electrical connection is made. Access level 2 is activated.
Page 150: Configuring Interconnected Operation Using The Load Remote Contact (E.g. Sigma Air Manager Basic)
. ■ If required, set temporary pressure increase ■ Activating the «remote control» key PISTON: Applies only to Airbox ➤ Set interconnected operation as described below: User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 151: Fig. 38 Load Remote Contact
▶1 pA/pB Clock ········· pA/pB Cycle Load RC input. 4. Use «Up» or «Down» to set the 5. Press «Enter». The LOAD remote contact operating mode is set. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 152: Setting The Master Control With Local/Load Remote Contact
Detailed information on the pressure parameters is provided in chapter 8.5.2. 8.11.5.4 Activating the remote control ➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. 8.11.6 Setting the master control with local/LOAD remote contact Overview ■...
Page 153: Fig. 39 Wiring Diagram For Local/Load Remote Contact
■ Contact A open: SIGMA CONTROL 2controls with ■ Contact A closed: SIGMA CONTROL 2 controls via external LOAD mode contact. ■ DI 1.07: LOAD/IDLE external ■ DI 1.06: LOAD control – switch to local/LOAD remote contact.
Page 154 Access level 2 is activated. <Configuration – Pressure control – Load control> menu. 1. Open the 5.2.3 Local mode line. 2. Use «Up» or «Down» to select the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 155 8.11.6.4 Activating the remote control ➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. 8.11.6.5 Assign an input for the LOAD remote contact for switching the pressure control Precondition Access level 2 is activated.
Page 156: Setting The Nominal Pressure Pre-Selection Via Remote Contact
Assigning the remote contact input A spare input can be found in the machine circuit diagram. pA/pB RC line. 1. Use «Up» or «Down» to select the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 157: Master Control For Machines Regulated By Pressure Switch
Master control via floating relay contact Requirement: A machine with SIGMA CONTROL 2 (e.g. series BSD) and a conventional machine without SIGMA CONTROL 2 with the same flow rate are to run in sequence as base load or peak load machines. Suggestion: ■...
Page 158: Fig. 40 Machine With Pressure Switch Regulation
8.11 Setting the machine for master control operation Establishing the electrical connection ■ Contact A open: SIGMA CONTROL 2 controls with network nominal pressure pB ■ Contact A closed: SIGMA CONTROL 2 controls with network nominal pressure pA ■ B 1.1: Pressure switch for network nominal pressure pB ■...
Page 159 This output can now be used for the changeover between the two pressure switches. Setting local mode Precondition Access level 2 is activated. 1. Open the 5.2.3 <Configuration – Pressure control – Load control> menu. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 160 Requirement: A machine with SIGMA CONTROL 2 (e. g. type BSD) and high flow rate is to work as a base load machine. A second machine (e.g., SK) without SIGMA CONTROL 2 is to supply air in times of low demand.
Page 161: Fig. 41 Function Diagram
8.5bar ¦ SD: −0.5bar pB SP: 8.2bar ¦ SD: −0.5bar ········· System pressure low ☐ ↓ < 5.0bar ¦ SD: 0.50bar 3. Press «Enter». pA display flashes. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 162: Examples Of Time Settings For Equal Overall Load
On Mon-Sun 06:30AM pB On Mon-Sun 12:00PM pA On pB On Mon-Sun 05:00PM Tab. 74 Example for a clock program for equal duty cycling during the day User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 163: Setting Input And Output Signals
Each output can be assigned only once. The following messages can be output: Message Explanation Output Controller on Controller is powered up Compressor on The machine is switched on not for SXC User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 164: Tab. 76 Assigned Output Signals
1. Select the required message with the «Up» or «Down» keys. 2. Press the «Down» key once. Output DOR has been selected 3. Press «Down» twice. Output DOT has been selected User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 165: Output Input Signals On The Display
External messages menu for specifying the settings. Use the ■ Enter the message text ■ Assign and activate the input ■ Set the time delay ■ Setting the logic User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 166 The cursor jumps to the next position of the message text. 6. Enter the remaining characters of the message text in the same manner. 7. Press «Enter». The message text has been entered. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 167 «DOWN» key and counted upwards from 0 (zero) in 1 second increments with the «UP» key. 1. Use «Up» or «Down» to select the td line. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 168: Tab. 77 Logic Settings
For messages at 24 V, the logic is set with the + symbol. 8.12.2.6 Setting the message type 1. Select the message type line with the «Up» and «Down» keys. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 169: Output Measured Values On The Display
The signal at the DI digital input is available as selected DOR output. 8.12.3 Output measured values on the display For analogue measured values you can define customised messages. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 170: Tab. 78 Assigned Analogue Measured Values
Below, the settings are displayed based on an example in the Switch menu analogously for specifying the settings. 8.12.3.1 Analogue values menu Precondition The electrical connection has been made. Access level 2 is activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 171 The cursor is located at the first character of the message text. A column with alphanumeric characters is displayed. The selected character flashes. 6. Select the required character with the «Up» or «Down» keys. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 172 ☑ ········· Switching point (SP) and switching differential (SD) 8.0bar ¦ SD: −0.5bar Time delay (td) ········· 8. Press «Enter». The measured value is assigned and activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 173 4. Press «Enter». td delay time has been set. Result 8.12.3.6 Setting the message type 1. Select the message type line with the «Up» and «Down» keys. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 174 ☐ ¦ Logic: 5. Press the «Right» arrow. 6. Press «Enter». The check box assigned to the output flashes. 7. Press the «Up» key. The check box is activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 175: Switching And/Or Triggering Messages With Thresholds
Power switching with frequency converter Tab. 79 Available measured values System pressure pNloc . Example: Setting for the local network pressure at compressor output Precondition Access level 2 is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 176 SD switching differential in the same way. 5. If necessary, adjust the value for the SP switching point and the SD switching differential are set. Result The threshold for the User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 177 ☐ 5. Press the «Right» key. 6. Press «Enter». The check box assigned to the output flashes. 7. Press the «Up» key. The check box is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 178 −0.6bar Delay (td) and logic 0s ¦Logic Output DOR DOR1.03 ok ☑ Type of message Warning ☑ 3. Press the «Up» key. The check box is activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 179: Timer
8.13 Timer SIGMA CONTROL 2 is equipped with an integrated timer that can control an adjustable DOR out‐ put for customer-specific applications. Valid setting values for the cutting in and out duration are between 10 h ≥ t ≥ 1 s.
Page 180: Activating Remote Acknowledgement
A controller input has been assigned for the acknowledgement signal. Overview <Configuration – Acknowledgement> menu. ■ Select the ■ Set the "Remote acknowledgement" function. ■ Activating the remote control User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 181: Setting The Remote Acknowledgement Function
Result The Remote acknowledgement function is set. 8.14.2 Activating the remote control ➤ Activate remote control see chapter 8.2.13. Result SIGMA CONTROL 2 remote control is activated. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 182: Assigning An Input
Key remote : ☑ 9. Press the «Remote control» key to enable remote acknowledgement. Result Should a message occur, it can now be acknowledged from a control centre. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 183: Linking To An External Pressure Transducer
■ Pressure according to the assigned external transducer ■ The local system pressure transducer (pNloc) remains active. Overview Example: The external pressure transducer is connected to SIGMA CONTROL 2. <Configuration – Pressure control> menu. ■ Open the ■ Assigning an input 8.15.1...
Page 184: Commissioning The Machine
8.2.2 ➤ Date and time correct? 8.2.8 ➤ Display format correctly set? 8.2.10 ➤ System pressure setpoint correctly set? Tab. 81 Check list for starting the machine User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 185 ------------------------------ Operating parameters 2500h Load 2490h Maintenance indicator Maintenance in 500h 2. Continue the commissioning process as described in chapter "Commissioning" of the ma‐ chine's operating manual. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 186: Operation
The ambient conditions as described in Chapter "Installation and Operating Conditions" are met 1. Switch on the user's power supply isolating device. 2. Switch on the machine and wait for SIGMA CONTROL 2 to start. voltage applied to controller LED lights green.
Page 187: Switching Off
The EMERGENCY STOP command device remains latched after actuation. The compressor's pressure system is vented and the machine is prevented from automatically re- starting. Switching on Precondition The fault has been rectified User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 188: Acknowledging Alarm And Warning Messages
Alarm LED flashes. The red Precondition The fault has been rectified ➤ Press «Ack» to acknowledge the fault message. Alarm LED extinguishes. The machine is again ready for operation. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 189: Displaying Messages
Selected submenu: ■ Compressor messages ■ Diagnostic messages ■ System messages Segment: ■ Message number ■ Message type ■ Message status ■ Message date ■ Message time User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 190: Status - Messages Menu
▶2 Message history Only displayed in the event of I/O parametrisation ▶3 Address error error Status report 01:00 ☐ ------------------------------ Number of currently registered faults current Alarms User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 191 Message text for message 0015 Com-Module communication error 0034 O c 04/13/21 08:15:37AM Message text for message 0034 E-mail send unsuccessful! 3. Press «Escape» repeatedly to leave this menu. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 192: Displaying The Current Operating Mode
LOAD remote contact (external LOAD signal) Load RC Remote bus (external bus signal) Load RB Local/LOAD remote contact loc.-load RC PISTON: Applies only to Airbox FLUID Tab. 87 Abbreviation of operating modes User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 193: Setting The Working Pressure
System pressure pNloc 6.1 bar ········· Airend discharge temperature 80°C Rise of airend discharge temperature dT/dt 0.0°C/s ········· Differential pressure, oil separator cartridge Oil separator Δp 0.0bar User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 194: Displaying Operating Data
On load: Machine running time in LOAD mode ─ Motor: Running time of compressor motor (adjustable) ─ Compressor block: Running time of airend (adjustable) ─ SIGMA CONTROL 2: Controller running time ■ Switching cycles ─ Load valve on ─ Mains contactor on (adjustable) ■...
Page 195: Checking The Switching Cycles
For the mains contactor, the usage time is defined by the maximum permissible number of switching cycles. The mains contactor switching cycle counter in SIGMA CONTROL 2 records the number of switching cycles and generates a warning message when the maximum permissible number of switching cycles is exceeded.
Page 196: Displaying The Frequency Converter Settings
Replacing the mains contactor If the displayed value of the mains contactor exceeds the maximum permissible number of 0024 Mains contactor switching cycles, SIGMA CONTROL 2 generates the warning message operations ⇞ . The mains contactor must be replaced. ➤ Have the mains contactor replaced by an authorised service partner.
Page 197: Setting The Maintenance Interval
4 Maintenance active line, Description maintenance interval Oil change Preset interval 3000 h 3000h¦ 0150h Reset: ☐ ········· Air filter 3000h¦ 0150h Reset: ☐ Prefilter changed: ☐ User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 198: Resetting The Maintenance Interval Counter
The applicable maintenance task has been carried out in accordance with the stipulations of the manufacturer Maintenance menu Maintenance . 1. Open the menu 4 Oil change . 2. Using the «Up» or «Down» keys, select the line User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 199 Reset check box has been deactivated ········· Air filter 3000h¦ 0150h Reset: ☐ Prefilter changed: ☐ 9. Press the «Escape» key repeatedly to return to the main menu. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 200: Check The Safety Valve
0°C ¦ ADT ⇞ 0.0°C Performing the inspection 1. Use «Up» or «Down» to select the Safety valve line. 2. Press «Enter». The check box Safety valve will flash. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 201 ➤ Close all access doors, replace and secure all removable panels. ➤ Wear eye protection. 7. Depending on the machine machine model, perform inspection as follows. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 202 Result The machine is ready for operation. Resetting If the test is cancelled when opening the safety valve, SIGMA CONTROL 2 will indicate the highest measured value as reached pressure. Reset check box. To reset the saved value, activate the Reset check box.
Page 203: Excessive Temperature Shut-Down Test
SIGMA CONTROL 2 will simulate a higher temperature for checking this function. For this purpose, SIGMA CONTROL 2 automatically determines an offset value to be displayed. During the test mode, this offset is added to the actual airend discharge temperature to cause the machine to shut down prematurely.
Page 204: Save Data
The test mode is de-activated and the test is completed. Resetting SIGMA CONTROL 2 will display the highest measured value if the test for switching off at exces‐ sive temperature is aborted. Reset check box in order to reset the stored value.
Page 205 Precondition An SD card with compatible file system (FAT32) and minimum 50 MB free memory is plugged into the SD card slot X5 of SIGMA CONTROL 2 The write protection of the SD card has been deactivated. Access level 2 is activated.
Page 206: Format Sd Card
Status recognised ········· Active line Format SD card : ☑ 5. Press the «Enter» key. A security query is displayed. 6. Press «Enter». SD card being formatted. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 207: 10 Fault Recognition And Rectification
10.1 Basic information The following tables are intended to assist in locating the causes of faults. There are three types of fault indicated in the SIGMA CONTROL 2: ■ Fault with the machine: red LED flashes, the machine shuts down: see chapters 10.2 and 10.5.
Page 208 Contact an authorised service Internal pressure pi in idle partner. ⇟ 0021 A Refrigeration dryer: Contact an authorised service Refrigeration dryer T ⇟ Compressed air temperature too partner. low. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 209 0050 A Power switching not ready or faul‐ Check the power switching. Customer-provided power element 0051 A Unit A failed. Contact an authorised service Aggregate A partner. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 210 0067 A Electrical connection interrupted. Check the electrical connection. SC2 <=> SC2 IP configuration incorrect. Check the IP configuration. communication error 0073 A External message 1 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 211 AnMod_T_4 0092 A T-Switch inlet temperature 0093 A p-Switch pi 0094 A T-Switch ADT 0095 A p-Switch pN 0096 A T-Switch PDT 0098 A n-Switch Compressor motor User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 212 Contact an authorised service Compressor motor FC partner. PKW error P%d.E%d 0205 A Frequency converter fault Contact an authorised service Compressor motor FC partner. PKW error P%d.E%d User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 213 Contact an authorised service Compressor motor FC partner. PKW error P%d.E%d 0242 A Fault on bus to frequency convert‐ Contact an authorised service Compressor motor USS partner. error %d User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 214 Oil-/air cooler fan USS partner. error %d 0283 A Frequency converter alarm mes‐ Contact an authorised service Oil-/air cooler fan FC sage with message number. partner. Alarm %d User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 215 0337 A Frequency converter parametrisa‐ Check the frequency converter Oil cooler fan FC: STO tion incorrect. parametrisation. function inactive Contact an authorised service partner. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 216: Interpreting Warning Messages
In this table, “%d” represents a variable value, e.g. a number, period of time or I/O address. Messages 0073-0078, 0081-0096 and 0098 are customer-specific. Add in the meaning for the message text you have defined (see chapter 8.12). User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 217 0024 W Maximum permissible number of switch‐ Have the mains contactor re‐ Mains contactor ing cycles exceeded. placed by an authorised operations ⇞ service partner. User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 218 Blow-off protection ↑ exceeded. cartridge. Open the shut-off valve in the venting line. 0041 W 1. Power supply interrupted: Check the power supply. Mains voltage ↓ Machine restarts automatically. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 219 Condensate cannot be drained. Check the ECO-DRAIN. 0058 W Electrical connection interrupted. Check electrical connection. SC2 <=> SC2 IP configuration incorrect Check the IP configuration. communication error User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 220 0069 W Refrigeration dryer defective. Contact an authorised serv‐ Error operation without Compressed air supply without air drying ice partner immediately. RD → Call service! is activated. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 221 AnMod_T_1 0084 W AnMod_T_2 0085 W AnMod_I_1 0086 W AnMod_I_2 0087 W AnMod_p_3 0088 W AnMod_p_4 0089 W AnMod_T_3 0090 W AnMod_T_4 0092 W T-Switch inlet temperature User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 222 Contact an authorised serv‐ Compressor motor FC cy converter. ice partner. alarm %d 0251 W Frequency converter in service mode. Exit service mode. Oil-/air cooler fan FC Service mode active User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 223 AII%d.0%d - short- logue input. connection. circuit 0872 W Power supply for ext. sensor at analogue Check the power supply. AII%d.0%d - error input faulty. power supply User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 224 Check line paths and sensor AIR%d.0%d - sensor connection. fault 0900 W Wire break in line for indicated analogue Check line paths and sensor AIR%d.0%d - open input. connection. circuit User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 225 Check line paths and sensor AIR%d.0%d - open input. connection. circuit 0923 W Sensor fault at indicated analogue input. Check line paths and sensor AIR%d.0%d - sensor connection. fault User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 226 Check line paths and sensor AIR%d.0%d - short- input. connection. circuit 0946 W Wire break in line for indicated analogue Check line paths and sensor AIR%d.0%d - open input. connection. circuit User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 227 1043 W Short circuit in line for ext. sensor at ana‐ Check line paths and sensor AII%d.0%d - short- logue input. connection. circuit User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 228 AIR%d.0%d - accidental logue input. connection. ground 1065 W Short circuit in line for indicated analogue Check line paths and sensor AIR%d.0%d - short- input. connection. circuit User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 229 AIR%d.0%d - accidental logue input. connection. ground 1083 W Short circuit in line for indicated analogue Check line paths and sensor AIR%d.0%d - short- input. connection. circuit User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 230 AIR%d.0%d - accidental logue input. connection. ground 1101 W Short circuit in line for indicated analogue Check line paths and sensor AIR%d.0%d - short- input. connection. circuit User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 231 AIR%d.0%d - accidental logue input. connection. ground 1119 W Short circuit in line for indicated analogue Check line paths and sensor AIR%d.0%d - short- input. connection. circuit User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 232 1217 W Short circuit in line for ext. sensor at ana‐ Check line paths and sensor AII%d.0%d - short- logue input. connection. circuit User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 233 AIR%d.0%d - open input. connection. circuit 1238 W Ground fault in line for ext. sensor at ana‐ Check line paths and sensor AIR%d.0%d - accidental logue input. connection. ground User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 234 AIR%d.0%d - open input. connection. circuit 1256 W Ground fault in line for ext. sensor at ana‐ Check line paths and sensor AIR%d.0%d - accidental logue input. connection. ground User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 235 AIR%d.0%d - open input. connection. circuit 1274 W Ground fault in line for ext. sensor at ana‐ Check line paths and sensor AIR%d.0%d - accidental logue input. connection. ground User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 236: Tab. 90 Warning Messages And Remedies
1290 W Wire break in line for indicated analogue Check line paths and sensor AIR%d.0%d - open input. connection. circuit Tab. 90 Warning messages and remedies User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 237: Interpreting Operating Messages
No e-mail sending of machine information. E-mail send unsuccessful! 0073 O External message 1 0074 O External message 2 0075 O External message 3 0076 O External message 4 User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 238 0200 O The internal voltage monitoring reports undervoltage fault IOSlot1 IOSlot1 Undervoltage error %d 0201 O The internal voltage monitoring reports undervoltage fault IOSlot2 IOSlot2 Undervoltage error %d User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 239 1053 O Short-term overload fault without shut-down occurred at All. AII%d.0%d - overload fault 1186 O Short-term IOM bus fault without shut-down has occurred IOSlot%d - bus error User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 240: Interpreting Diagnostic Messages
Contact an authorised service partner if the mes‐ RFID error: switch SIGMA sage is displayed again after restarting. CONTROL power supply OFF → ON! Tab. 92 System messages and remedies User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 241: Kaeser I.box − Operating States And Troubleshooting
Check cable between i.Box and SIGMA CONTROL 2 SIGMA CONTROL 2 fault Contact an authorised service partner Flashing Flashing SIGMA CONTROL 2 fault Check cable between i.Box and (2x/s fol‐ (2x/s) SIGMA CONTROL 2. lowed by Contact an authorised service short...
Page 242: 11 Maintenance
When the battery is discharged, the date and time of the controller will always re‐ set to 01/01/1970 at 01:00:00 in the Europe/Berlin time zone. User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 243: 12 Spares, Operating Materials, Service
8 0 ° C Menu 5.1.1 System information Active line ▶1 SIGMA CONTROL 2 MCS ▶2 Compressor ▶3 I/O modules applies to FLUID only ▶4 FC information User Manual Controller No.: 9_9450 12 E SIGMA CONTROL 2 SCREW FLUID ≥5.0.X...
Page 244 0 8 : 1 5 A M 8 0 ° C Menu 5.1.1.1 SIGMA CONTROL 2 MCS 123456 ········· Manufacturer Prodrive Material number 6309.1000.7900 Serial number 10.34.000.961 Manufacturing date MFGDT 2017/04 User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...
Page 245: 13 Decommissioning, Storage And Transport
4. Use a suitable tool to remove the internally installed battery. 5. Battery disposal in accordance with environmental guidelines. 6. Hand the SIGMA CONTROL 2 over to an authorised disposal expert. Further information Refer to the machine’s Operating Manual for details regarding the battery’s environmentally sound disposal.
Page 246 Decommissioning, Storage and Transport 13.5 Battery removal and disposal User Manual Controller SIGMA CONTROL 2 SCREW FLUID ≥5.0.X No.: 9_9450 12 E...

This manual is also suitable for:

9 9450 12 e

KAESER KOMPRESSOREN SIGMA CONTROL 2 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KAESER KOMPRESSOREN SIGMA CONTROL 2

Summary of Contents for KAESER KOMPRESSOREN SIGMA CONTROL 2
