- Page 1 USER’S GUIDE GUIDA OPERATIVA BIGII Touch PC BIGII Touch PC...
- Page 3 GENERAL SAFETY INFORMATION THE CE MARK AFFIXED TO Your attention is drawn to the following THE PRODUCT CERTIFY actions that could compromise the char- THAT THE PRODUCT SAT- acteristics of the product: ISFIES THE BASIC SAFETY CUSTOM ENGINEERING S.p.A. • Read and retain the instructions which REQUIREMENTS.
- Page 4 INFORMAZIONI GENERALI IL MARCHIO CE APPLICATO SULLA SICUREZZA AL PRODOTTO CERTIFICA Si richiama l’attenzione sulle seguenti CHE IL PRODOTTO STES- azioni che possono compromettere la con- SO SODDISFA I REQUISITI CUSTOM ENGINEERING S.p.A. formità e le caratteristiche del prodotto: BASE DI SICUREZZA. Str.
- Page 5 TABLE OF CONTENTS Indice Table des matières Inhaltsverzeichnis Indice DESCRIPTION INSTALLATION MAINTENANCE TECHNICAL SPECIFICATIONS...
- Page 7 DESCRIPTION UNPACKING THE DEVICE Disimballo dispositivo Remove the device from its carton being careful not to damage the packing material so that it may be re-used if the device is to be transported in the future. Make sure that all the components illustrated below are present and that there are no signs of damage.
- Page 8 DEVICE DESCRIPTION Descrizione dispositivo credit cards Se poste in contatto con il suppor- brought into contact with the to, carte di credito e bancomat cradle may be demagneti- possono subire fenomeni zed and information stored smagnetizzazione con conseguen- 1. Magnetic card reader on the card erased.
- Page 9 SWITCH OFF: It is recommended to always use the “Turn off TG” button in the “Functions” menu on the touch BIGII TOUCH PC Power supply screen. Never disconnect the power supply without fi rst completing the shutdown procedure because you might damage the terminal.
- Page 10 PAPER ROLL INSERTION Inserimento rotolo carta To change the paper roll, proceed as follows: 1. Lift the opening levers A. 2. Open the printer cover B. 3. Place the paper roll into the paper compart- ment. 4. Pull out a few centimetres of the paper roll edge and close the printer cover.
- Page 11 INSTALLATION ROOM...
- Page 12 CONNECTIONS Collegamenti NOTE: If serial and USB con- nectors are inserted, commu- nication port is USB. NOTA: Se i connettori seriale e USB sono inseriti, la porta di comunicazione è la USB. VIn 24Vdc Power supply Power supply cable...
- Page 13 MAINTENANCE CLEANING SCHEDULE Pianifi cazione pulizia Cleaning your device regularly maintains print quality and may extend the life of the printer. The recommended cleaning schedule is shown in the following table. EVERY ROLL CHANGE Printing head Use isopropyl alcohol Roller Use isopropyl alcohol EVERY 5 ROLL CHANGES Paper compartment...
- Page 14 OGNI 6 MESI O QUANDO NECESSARIO Strapperina manuale Utilizzare aria compressa Carrozzeria Utilizzare aria compressa o un panno morbido Per le procedure specifi che, vedere le pagine successive. NOTA: Se si utilizza il dispositivo in ambienti molto polverosi, occorre ridurre gli intervalli di pulizia.
- Page 15 MAINTENANCE OUTSIDE CLEANING Pulizia esterna 1. Switch off the device by pressing the button for 2 seconds. 2. Unplug the power supply cable from the mains outlet. 3. Use a soft cloth. WARNING: Do not use alcohol (methyl, ethyl or isopropyl) or strong solvents. Do not use thinner or benzene, abrasive cleaners, compressed air or stiff brushes.
- Page 16 TOUCHSCREEN CLEANING Pulizia dello schermo touch 1. Switch off the device by pressing the button for 2 seconds. 2. Unplug the power supply cable from the mains outlet. 3. Wait a few minutes to allow the screen to get to room temperature. 4.
- Page 17 MAINTENANCE RUBBED ROLLER AND PRINTING HEAD CLEANING Pulizia del rullo gommato e della testina di stampa 1. Switch off the device by pressing the button for 2 seconds. 2. Unplug the power supply cable from the mains outlet. 3. Lift the opening levers A. 4.
- Page 18 ATTENTION: Do not touch the head heating line with bare hands or metal objects. Do not perform any operation inside the printer immediately after printing beacuse the head and motor tend to become very hot. ATTENZIONE: Non toccare la linea di riscaldamento della testina a mani nude o con oggetti metallici.
- Page 19 TECHNICAL SPECIFICATIONS DEVICE SPECIFICATIONS Caratteristiche del dispositivo GENERAL Processor Intel ATOM N270 1,6GHz ® Chipset Intel 945GSE and ICH7M ® BIOS AWARD System memory 1 x SODIMM socket (up to 2GB DDR2 533 SDRAM) Internal storage SSD 8GB SATA II IEEE802.3 10/100/1000BASE-T Ethernet Compliant, RJ45 connector...
- Page 20 Core thickness 2 mm (+1mm) Paper end Not attached to roll core Core type Cardboard or plastic ELECTRICAL SPECIFICATIONS (BIGII TOUCH PC) Power supply 24 Vdc ±10% (external power supply) Stand-by consumption 0,08 A Medium consumption in print 1,2 A POWER SUPPLY ELECTRICAL SPECIFICATIONS cod.
- Page 21 TECHNICAL SPECIFICATIONS DEVICE DIMENSIONS Dimensioni dispositivo Length 246 mm Width 249 mm Height cover open = 138.5 mm cover closed = 237.5 mm Weight 2 000 g...
- Page 22 POWER SUPPLY DIMENSIONS Dimensioni alimentatore CODE 963GE020000003 Length 127 mm Width 56 mm Height 35,5 mm AC INLET +24V DC OUTPUT WIRE...
- Page 24 CUSTOM ENGINEERING S.p.A. World Headquarters Via Berettine, 2 - 43010 Fontevivo, Parma ITALY Tel. +39 0521 680111 - Fax +39 0521 610701 info@custom.biz - www.custom.biz All rights reserved www.custom.biz...
