- Page 1 CUBA Dresser...
- Page 2 IMPORTANT RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Please read the instructions and warnings carefully before use to ensure safe and satisfactory operation of this product. Your child’s safety is your responsibility. If you have a query with this product or require replacement parts, please contact 01692 408802.
- Page 3 Wooden Parts Changer Surface Upper Drawer Front Front Crossbar Centre Drawer Front Front Trim Lower Drawer Front Back Panel x 2 Side Panel x 2 (L&R) Upper Crossbar (Dark wood finish) Centre Crossbar Lower Crossbar Drawer Side x 6 (L&R) Drawer Back x 3 Drawer Base x 3...
- Page 4 Assembly 1 NOTE: Take care to insert the dowels into the correct holes as indicated. Repeat for the opposite end of each crossbar. (Total 12 x part D) Upper Crossbar Centre Crossbar D x 2 Lower Crossbar Assembly 2 Side Panel B x 3 Repeat for the second Side Panel (Total 6 x part B).
- Page 5 Assembly 3 Upper Crossbar Lower Crossbar Centre Crossbar C x 3 Side Panel Assembly 4 Changer Surface H x 2 A x 3...
- Page 6 Assembly 5 C x 3 A x 3 Side Panel Assembly 6 Front Trim D x 4 B x 9 D x 4...
- Page 7 Assembly 7 Front Crossbar Front Trim C x 3 Assembly 8 Front Trim Front Crossbar C x 6 Changer Surface...
- Page 8 Assembly 9 Drawer Side Drawer Back F x 2 Lower Drawer Front F x 2 Drawer Side G x 2 Drawer Base I x 4 G x 2 NOTE: Insert parts I (ensuring that the slots in part I are visible) before attaching the drawer back. Repeat for Centre Drawer and Upper Drawer.
- Page 9 Assembly 11 Upper Drawer Centre Drawer Lower Drawer...
- Page 10 Assembly 12 The dresser is supplied with a fixing kit which will secure it and help to guard against accidental tipping. WARNING : Installation only to be carried out by a competent person. Check the suitability of the wall before fitting. Washer x 2 Screw (15mm) Screw (25mm)
- Page 11 BLANK PAGE...
-
Page 12: Care And Maintenance
Do not use the dresser if any of the parts are broken, torn or missing. Any additional or replacement parts can only be obtained from the manufacturer or the distributor. Customer Care line for this product 01692 408802 East Coast Nursery Ltd. Robertson House, North Walsham, Norfolk, NR28 0BX www.eastcoastnursery.co.uk 7837-1...
