5
Fully tighten the four partially tightened screws.
*Push the speaker against the monitor while driving the screw.
R
6 1
L
R
6 1
Connecting the cords
Turn off the power of all connected units before connecting the cords.
Connect the monitor's SPEAKER R and L
terminals with the speakers' terminals using the
included connection cords.
R
6 1
L
R
6 1
RIGHT
LEFT
Cord Clamper
Peel off the protective tape from the back of the clamper, then
mount the clamper in the desired position and clamp the cords
together.
L
6 1
R
L
6 1
WARNING
● Do not move the monitor by holding onto the speakers which
have been mounted to the monitor.
This could cause the monitor to fall and result in injury.
● Fasten the screws securely. Failing to do so could cause the
speakers to fall and result in injury.
There is polarity
connection cord.
Connect each conductor to the correct terminal.
L
6 1
R
L
6 1
Hold down the button of the speaker terminal with
your finger, insert the conductor of the connection
cable, and release your finger.
9
with the conductor of each
+ −
Black
Red
