Component Access/Removal

COMPONENT ACCESS AND REMOVAL

This section explains how to adjust, access and remove components.
An attempt has been made to arrange these procedures in such a way as to simulate which components would
need to be removed first in order to gain access to other components. When following a component removal proce-
dure, it may be necessary to reference another component removal procedure listed earlier in this section.
This section is arranged as follows:
• Model ICBWS-30 Exterior Cosmetic / Mechanical Components ..........................................................................................
• Model ICBWS-30 Interior Cosmetic / Mechanical Components ............................................................................................
• Model ICBWS-30 Compressor Area Mechanical Components..............................................................................................
• Model ICBWS-30 Sealed System Components ....................................................................................................................
IMPORTANT NOTE: Before continuing, please take note of the
• IF NECESSARY TO REMOVE A UNIT FROM ITS INSTALLATION, REMEMBER THAT THE UNIT COULD TIP
FORWARD WHEN PULLED FORWARD BEYOND THE ANTI-TIP COMPONENTS, RESULTING IN SERIOUS
INJURY OR DEATH. PULLING A UNIT FROM ITS INSTALLATION SHOULD ONLY BE PERFORMED BY AN
AUTHORIZED SERVICE TECHNICIAN OR INSTALLER.
• TO AVOID ELECTRIC SHOCK, POWER TO THE UNIT MUST BE DISCONNECTED WHENEVER ACCESS-
ING AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR OTHER
ELECTRICAL COMPONENTS. IF THE UNIT IS PLUGGED IN, BUT HAS NOT BEEN SWITCHED ON BY
PRESSING THE UNIT ON/OFF KEY, 115 VOLTS AC IS STILL PRESENT AT THE CONTROL BOARD.
• IF REMOVING A DOOR OR DRAWER FROM A UNIT, REMEMBER THAT DOORS AND DRAWERS ARE
HEAVY. IF THEY WERE TO FALL, THEY COULD CAUSE SERIOUS PERSONAL INJURY.
• When removing or disconnecting door closers and/or hInge assemblies, remember they are spring
loaded and may recoil quickly when released.
• To avoid static electric damage to the control board, always handle the board by the edges.
• If working in the compressor area, remember that compressor and tubing may be hot.
• If working on or around the evaporator or condenser, remember that evaporator and condenser fins are
sharp.
#7013455 - Revision A - April, 2009
International W ine Storage
International W ine Storage
6-2
Series
Series
(ICBWS)
(ICBWS)
WARNINGS and CAUTIONS
Page:
6-3
6-8
6-14
6-16
below.
