Bob's Discount Furniture KING PANEL BED Assembly Instruction

ASSEMBLY INSTRUCTION FOR
Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble
your newly purchased product correctly and efficiently.

PARTS LIST

NO. PART DESC.
A HEADBOARD
HB - LEG (L / R)
B
C HB - STRETCHER
B
KING PANEL BED
QTY
PART CODE
1 pc
MC400KH
2 pcs
PMC400HBLEG1
1 pc
PMC400THSTR1
A
C
MADE IN MALAYSIA

HARDWARE LIST

NO.
HARDWARE DESC. PART
1 ALLEN BOLT
2 ALLEN BOLT
3 SPRING WASHER
4 FLAT WASHER
5 ALLEN KEY
BACK VIEW
STEP 2
3 4
1
5
QTY
SIZE CODE
4 pcs
M6 x 35mm
4 pcs
M6 x 45mm
8 pcs
PMC400KBHW
M6
8 pcs
M6 x 13mm
1 pc
M4
BACK VIEW
STEP 1
3 4
2
5
PAGE 1 OF 2
