Bob's Discount Furniture CHADWICK PANEL TWIN BED Assembly Instructions

Bob's Discount Furniture CHADWICK PANEL TWIN BED Assembly Instructions

Advertisement

Available languages

Available languages

Quick Links

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all
components are in proper position, tight and free from damage. Keep this assembly instruction for future reference. Adult assembly is required.
HARDWARE LIST
A (2) Wood Dowels
B (4) Short Allen Bolts
C (1) Allen Wrench
D (6) Wood Screws
E (4) Long Allen Bolts
F
(8) Spring Washers
G (8) Flat Washers
H (4) Nuts
PARTS LIST
I
(3) Support Feet
J
(3) Wood Slats
K (2) Side Rails
L
(1) Headboard
M (2) Headboard Legs
N (1) Footboard
L
M
FIGURE 2
STEP 3 - Figure 3 For Metal Frame
Secure Metal Frame (*Not Included)
to the Headboard Legs (M) with 2
Long Bolts (E), 2 Spring Washers (F)
and 2 Flat Washers (G) from the front
of each leg and 2 Flat Washers (G), 2
Spring Washers (F) and 2 Hex Nuts (H)
from the back of each leg.
CARE & MAINTENANCE: The touch of a soft cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing,
as they may cause damage to the finish. Periodic checks are recommended to make sure that all hardware is securely tightened.
CHADWICK PANEL TWIN BED
PART
A
C
E
G
Begin assembly by inserting Wood Dowels (A)
into Headboard Legs (M) and then attach
B B
STEP 2 - Figure 2
Secure Headboard (L)
to Headboard Legs (M)
B B
with 2 Short Bolts (B)
per leg. Tighten bolts
with Allen Wrench (C).
M
F F
E E
E E
QTY
HARDWARE
2
1
4
8
STEP 1 - Figure 1
Headboard (L) on top.
FIGURE 3
M
H H
F F
G G
G G
H H
F F
G G
G G
F F
Date: 09-25-2013
PART
QTY
HARDWARE
B
4
D
6
F
8
H
4
L
A A
FIGURE 1
M
Holes
for
Metal
Frame
The Bed Frame
included. Sold Separately.
Page 1 of 2
A
M
is not
