PC Card Files

Displays a list of all the files stored in the CompactFlash card so that
you can select a file you want to display. You can also sort files by file
name or date, or display the file.
Although a list of all the files in the CompactFlash card is displayed,
you can view files in text, HTML, JPEG and BMP format only.
PC Card Files
File Name Size
@. <DIR>
@.. <DIR>
12345678.txt 1234567890
12345678.bmp 1234567890
12345678.htm 1234567890
Path /
Info. 5 Files
Selecting "Execute" displays the file you selected.
ChalkBoard (available only when using with a USB mouse)
Provides the tool bar for producing freehand drawings.
Pen: Left-click and drag to draw. Right-click to display the
pen palette containing four lines of different thickness
from which you can select a line you prefer by left-
clicking.
Erase: Left-click and drag to erase part of a drawing. Right-
click to display the eraser palette containing four eraser
of different thickness from which you can select an
eraser you prefer by left-clicking.
Clear: Clears the drawing completely from the ChalkBoard
screen.
Color: Selects a color. Left-click to display the color palette
from which you can select a color you prefer by left-
clicking.
View: Hides the tool bar by left-clicking. Right-clicking any-
where on the screen displays the ChalkBoard tool bar
again.
Exit: Clears the complete drawing and exits the ChalkBoard.
Date
Execute
1999/06/01 HH:MM
1999/06/01 HH:MM
Exit
1999/06/17 HH:MM
1999/06/17 HH:MM
Sort
1999/06/17 HH:MM
Name (abc..)
File Group
All (*. *)
Free Space
NOTE:
* The ChalkBoard feature is available only when a USB mouse is
used. Free-hand drawings cannot be saved or captured.
* The main menu is not available while you display the ChalkBoard
screen.
* The Capture and the Source Display function are not available on
ChalkBoard screen.
* Switching slides clears a drawing completely.
* Selecting BMP and JPEG files automatically switches to the PC
Card Viewer source.

Help

Help

Contents

Source Information

Projector Information

E–25
Contents
Provides an online help about how to use
the menus. An underlined link means that
you can move to an adjustment item di-
rectly. Selecting the underlined link and
pressing ENTER moves to the corre-
sponding adjustment item.
Source Information
Displays the status of the current signal.
This dialog box has three pages.
Projector Information
Displays the lamp usage hours.
