[Page 3]
Setup
Page1 Page2 Page3

PC Card Viewer Options

Start Mode
Show Folder List

Capture Options

High Quality
PC Card Viewer Options
Start Mode
Sets the starting condition when PC Card Viewer input is selected
on the projector.
Show Folder List
When PC Card Viewer input is selected on the projector, the folder
lists will be displayed and allows you to select the presentation
from a CompactFlash card.
Auto Play
If this option is checked , any given slide will start to play auto-
matically. You can also specify interval between 5 and 300 sec-
onds using Auto Play Interval.
Manual Play
Views a slide manually when PC Card Viewer input is selected.
NOTE: The Auto Play and Manual Play options determine the
behavior of the Play/Stop [
When selecting "Show Folder List" or "Manual Play" while the
"Auto Play" feature is not checked, and you select PC Card Viewer
for the input source, you can manually advance to the next slide
or the preivious slide.
NOTE: If you check "Auto Play" and select "PC Card Viewer"
on the projector, the slides will automatically start to play back
from any given slide.
Capture Options (available for JPEG only)
These options are used for the Capture function which you can
select from Tools. You have three options for JPEG compression
quality: High quality, Normal and High Compression.
High Quality
Gives quality of JPEG a priority.
Normal
Gives normal JPEG quality.
High Compression
Gives compression a priority.
Auto Play Manual Play
Auto Play Interval
sec
15
Normal High Compression
OK
/ ] icon on the Viewer tool bar.

Tools

Tools

Capture

PC Card Files
ChalkBoard
Capture
Allows you to capture an image from a source that is currently being
displayed. The image is saved as JPEG in the CompactFlash card.
When you select Capture from the menu, you will get a tool bar. You
can capture an image directly using the tool bar when the menu is
not displayed.
Cancel
The tool bar includes the following buttons:
Drag
Capture Exit
Drag: Drags to move the tool bar. (for USB mouse operation
Capture:Captures an image and save it as a JPEG file in a PC
Freeze: Freezes and unfreezes images.
Exit:
Unless a CompactFlash memory card is inserted into the PC Card
Access slot of the projector, the Capture feature is not available.
The "Card Error" display means that the free space of the
CompactFlash card is insufficient for saving images. Make more space
available on the card by erasing unwanted images with your PC. The
number of images that can be captured depends on the size of the
CompactFlash card.
NOTE: Be sure not to turn off the power or remove the CompactFlash
card while capturing an image. Doing so could cause a loss of the
data in the CompactFlash card or damage to the card itself.
NOTE: Captured images with higher resolution than the projector's
native resolution cannot be displayed correctly.
E–24
Provides tools for capturing images, dis-
playing files in a CompactFlash Card and
drawing.
NOTE: The "Tools" feature is required
for a CompactFlash card.
Freeze
only)
card.
Exits the Capture function.
