- Page 1 User Manual -Installation -Operation Omniksol-3k-TL Omniksol-4k-TL Omniksol-5k-TL Omnik New Energy Co.,ltd...
- Page 2 User Manual 2 ...
-
Page 3: Table Of Contents
User Manual ATALOG Catalog ........................................ 3 1. Notes on this manual .................................. 5 1.1 Scope of Validation .......................... 5 1.2 Symbols Used ............................ 5 1.3 Target Group ............................. 6 2. Preparation ...................................... 7 2.1 Safety Instructions ............................ ... - Page 4 User Manual 7.2 LCD Display ............................. 3 6 7.3 Set Language ............................ 3 8 7.4 State Information ............................ 3 9 8. Recycling and Disposal ................................ 4 0 9. Troubleshooting ................................... 4 1 Abbreviation .................................... ...
-
Page 5: Notes On This Manual
OTES ON THIS MANUAL Scope of Validation The main purpose of this User’s Manual is to provide instructions and detailed procedures for installing, operating, maintaining, and troubleshooting the following two types of Omnik New Energy-Solar Inverters: • Omniksol-3k-TL • Omniksol-4k-TL • Omniksol-5k-TL Please keep this user manual all time available in case of emergency. -
Page 6: Target Group
User Manual Target Group • Chapter 1, 2, 3, 4, 7, 8, 9, 10 and chapter 11 are intended for anyone who is intended to use Omnik Grid Tie Solar Inverter. Before any further action, the operators must first read all safety regulations and be aware of the potential danger to operate high-voltage devices. -
Page 7: Preparation
User Manual REPARATION Safety Instructions DANGER DANGER due to electrical shock and high voltage DO NOT touch the operating component of the inverter, it might result in burning or death. TO prevent risk of electric shock during installation and maintenance, please make sure that all AC and DC terminals are plugged out. - Page 8 User Manual CAUTION The PV inverter will become hot during operation; please don’t touch the heat sink or peripheral surface during or shortly after operation。 Risk of damage due to improper modifications. Never modify manipulate inverter other components of the system. 8 ...
-
Page 9: Explanations Of Symbols On Inverter
User Manual Explanations of Symbols on Inverter Symbol Description Dangerous electrical voltage This device is directly connected to public grid, thus all work to the inverter shall only be carried out by qualified personnel. DANGER to life due to high electrical voltage! There might be residual currents in inverter because of large capacitors. - Page 10 User Manual No unauthorized perforations or modifications Any unauthorized perforations or modifications are strictly forbidden, if any defect or damage (device/person) is occurred, Omnik shall not take any responsibility for it. 10 ...
-
Page 11: Product Information
User Manual RODUCT NFORMATION Overview • Industrial Layout • Excellent Heat Elimination 11 ... -
Page 12: Major Characteristics
User Manual • Effective Shield For DC/AC/Communication Connections Major Characteristics Omnik inverter has following characteristics which make Omnik inverter “High Efficiency, High Reliability, High Cost Effective Ratio” •... -
Page 13: Datasheet
User Manual Datasheet Omniksol-3k-TL Type Omniksol-3k-TL Input (DC) Max. PV-generator power 3400 Max DC voltage max(DC) MPPT DC voltage range 120 – 500 mppt Turn off DC Voltage min(DC) Max. DC current max(DC) Nominal DC current N(DC) Number of DC connection... - Page 14 User Manual Dimensions and weight Dimensions (WxHxD) [mm] 367x526x163 Weight [kg] Environmental limits IP protection type IP 65 according to IEC 60529 Operating temperature range -20°C to +60°C Relative humidity 0% to 98%, no condensation Maximum altitude (above sea level) 2000 Noise level [dBA]...
- Page 15 User Manual Power consumption at night nig(AC) Power consumption at standby std(AC) Efficiency Max. Efficiency (at 360VDC) 97.6% Euro efficiency (at 360VDC) 97.0% MPPT efficiency 99.9% Safety and protection Internal overvoltage protection DC Insulation monitoring Earth fault protection According to VDE 0126-1-1, RD1663, ENEL2010,C10/11, Grid monitoring G83/1, AS4777 According to VDE 0126-1-1, RD1663, ,ENEL2010,C10/11,...
- Page 16 User Manual Omniksol-5k-TL Type Omniksol-5k-TL Input (DC) Max. PV-generator power 5000 Max DC voltage max(DC) MPPT DC voltage range 120 – 500 mppt Turn off DC Voltage min(DC) Max. DC current max(DC) Nominal DC current N(DC) Number of DC connection DC-connection Number of MPP trackers Turn on power...
- Page 17 User Manual Weight [kg] Environmental limits IP protection type IP 65 according to IEC 60529 Operating temperature range -20°C to +60°C Relative humidity 0% to 98%, no condensation Maximum altitude (above sea level) 2000 Noise level [dBA] < 40 General data Isolation type Transformerless...
-
Page 18: Packing Checklist
User Manual ACKING CHECKLIST Assembly parts After you receive the Omnik inverter, please check if there is any damage on the carton, and then check the inside completeness for any visible external damage on the inverter or any accessories. Contact your dealer if anything is damaged or missing. ... - Page 19 User Manual Product Appearance • Front Object Description Removable front shield LED light(Green) – RUN LED light(Red) – FAULT LED light(Yellow) – COM Function key for displays and choice of language Monitoring LCD with backlighting • Bottom 19 ...
- Page 20 (SN.), type of the inverter, as well as inverter specifications are specified on the side name plate. The name plate is on the middle part of the right side of the inverter housing. And the following figure is the side name plate example as on Omniksol-3k-TL. Further Information...
