- Page 1 User Manual V1.1 User Manual -Installation -Operation Omniksol-5k-TL2-3P Omniksol-6k-TL2 Omniksol-8k-TL2 Omniksol-9k-TL2 Omniksol-10k-TL2 Omnik New Energy Co.,Ltd.
-
Page 2: Table Of Contents
Catalog Catalog ............................1 Notes on this manual ......................4 General notes ........................ 4 Symbols Used ....................... 4 Target Group ......................... 5 Preparation ........................6 Safety Instructions ......................6 Explanations of Symbols on Inverter ................7 Product Information ......................8 Overview ........................ - Page 3 Display .........................33 Ground .........................50 State Information ......................51 Communication Setting .....................52 GPRS Card ........................52 Installation of communication card ................53 Register on monitoring website ..................56 Login monitoring System ....................60 WiFi card ........................65 Netwoek Settings ......................66 RS485 card ........................75 Recycling and Disposal .....................76 10.
-
Page 5: Notes On This Manual
Notes on this manual 1.1 General notes The main purpose of this User’s Manual is to provide instructions and detailed procedures for installing, operating, maintaining, and troubleshooting the following three types of Omnik New Energy-Solar Inverters: Omniksol-5k-TL2-3P Omniksol-6k-TL2 Omniksol-8k-TL2 ... -
Page 6: 1.3 Target Group
NOTICE NOTICE indicates a situation that can result in property damage, if not avoided. 1.3 Target Group Chapter 1, 2, 3, 4, 7, 8, 9, 10, 11 and Chapter 12 are intended for anyone who is intended to use Omnik Grid Tie Solar Inverter. Before any further action, the operators must first read all safety regulations and be aware of the potential danger to operate high-voltage devices. -
Page 7: Preparation
Preparation 2.1 Safety Instructions DANGER DANGER due to electrical shock and high voltage DO NOT touch the operating component of the inverter, it might result in burning or death. TO prevent risk of electric shock during installation and maintenance, please make sure that all AC and DC terminals are plugged out. -
Page 8: Explanations Of Symbols On Inverter
NOTICE Public utility only The PV inverter designed to feed AC power directly into the public utility power grid，do not connect AC output of the device to any private AC equipment. CAUTION The PV inverter will become hot during operation; please don’t touch the heat sink or peripheral surface during or shortly after operation。... -
Page 9: Product Information
This device SHALL NOT be disposed of in residential waste Please go to Chapter 9 “Recycling and Disposal” for proper treatments. Without Transformer This inverter does not use transformer for the isolation function. Standards Association of Australian The inverter complies with the requirement of the AS4777. CE Mark Equipment with the CE mark fulfils the basic requirements of the Guideline Governing Low-Voltage and Electromagnetic Compatibility. -
Page 10: Major Characteristics
Effective Shield For DC/AC/Communication Connections Major Characteristics Omnik inverter has following characteristics which make Omnik inverter “High Efficiency, High Reliability, High Cost Effective Ratio” Wide DC input voltage and current ranges, enables more PV panels connected. Wide MPP voltage range ensure high yield under various weather conditions. ... -
Page 11: Technical Data
Technical Data Type Omniksol-5k-TL2-3P Omniksol-6k-TL2 Omniksol-8k-TL2 Input (DC) Max. PV Power 5150W 6150W 8200W Max DC Voltage 1000V 1000V 1000V Nominal DC Voltage 640V 640V 640V Operating MPPT Voltage 150-800V 150-800V 150-800V Range MPP voltage range at full 260-800V 280-800V... - Page 12 Type Omniksol-5k-TL2-3P Omniksol-6k-TL2 Omniksol-8k-TL2 Safety and Protection Array ground insulation resistance monitoring Output over current protection Residual current monitoring Surge protection Array polarity reverse monitoring Output over/under voltage protection Protection Functions Array over voltage protection Output over/under frequency protection Anti-island protection...
- Page 13 type Omniksol-9k-TL2 Omniksol-10k-TL2 Input (DC) Max. PV Power 9000W 10000W Max DC Voltage 1000V 1000V Nominal DC Voltage 640V 640V Operating MPPT Voltage Range 150-800V 150-800V MPP voltage range at full load 380-800V 380-800V Start up DC Voltage 250V 250V Turn off DC Voltage 150V 150V...
- Page 14 Type Omniksol-9k-TL2 Omniksol-10k-TL2 Safety and Protection Array ground insulation resistance monitoring Output over current protection Residual current monitoring Surge protection Array polarity reverse monitoring Output over/under voltage protection Protection Functions Array over voltage protection Output over/under frequency protection Anti-island protection Over temperature protection Array over current protection Output short circuit protection...
-
Page 15: Packing Checklist
Packing checklist Assembly parts After you receive the Omnik inverter, please check if there is any damage on the carton, and then check the inside completeness for any visible external damage on the inverter or any accessories. Contact your dealer if anything is damaged or missing. Object Quantity Description Omnik inverter... -
Page 16: Product Appearance
Product Appearance Front Object Description Removable front cover LED Light （Three） Functional key（Four） LCD Display Bottom Object Description DC switch Plug connectors for DC input. AC output terminals(connect to grid) Communication interface(RS485/GPRS/WiFi/USB) -
Page 17: Product Identification
The name plate is on the middle part of the right side of the inverter housing. And the following figure is the side name plate example as on Omniksol-5k-TL2-3P. Further Information... -
Page 18: Installation
Installation Safety DANGER DANGER to life due to potential fire or electricity shock. DO NOT install the inverter near any inflammable or explosive items. This inverter will be directly connected with HIGH VOLTAGE power generation device, the installation must be performed by qualified personnel only in compliance with national and local standards and regulations. -
Page 19: Mounting Instructions
Mounting Instructions Omnik inverter is designed for indoors and outdoors installation, in order to extend the service life of inverter, we suggest to install the inverter in the basement or garage or other regions without sun, rain and snow. ... -
Page 20: Safety Clearance
Safety Clearance Observe the following minimum clearances to walls, other devices or objects to guarantee sufficient heat dissipation and enough space for pulling the electronic solar switch handle 30cm 30cm Direction Minimum clearance Above 30 cm Below 40 cm Sides 30 cm... -
Page 21: Mounting Procedure
Mounting Procedure Mark 4 positions of the drill holes on the wall according to the paper installation position scale packed in the carton box. according to the marks, drill 4 holes in the wall. Then, place four expansion tubes in the holes using a rubber hammer. - Page 22 check the 4 holes in the backside of the inverter. Then, lift the inverter carefully, align the 4 holes in the inverter and the 4 screws in the wall, and finally attach the inverter to the screws slightly.
-
Page 23: Safety Lock
Safety lock After the inverter is hang up on the bracket，lock up the device and the bracket together at the Lower Right Corner of the inverter (as the picture showed below) Padlock Recommended padlock dimension： A A． Shackle Diameter 5~7 mm B．... -
Page 24: Electrical Connection
Electrical Connection Safety DANGER DANGER to life due to potential fire or electricity shock. With the inverter powered, comply with all prevailing national regulations on accidents prevention. This inverter will be directly connected with HIGH VOLTAGE power generation device; the installation must be performed by qualified personnel only in compliance with national and local standards and regulations. -
Page 25: Ac Side Connection
In order to reduce the line loss of AC side (no more than 1% of P ), Omnik suggest that the length of AC cable from the inverter to the distribution box should not exceed the limit below. Length of cable Model Rated current 2.5 mm 4 mm 6 mm Omniksol-5k-TL2-3p 7.2A Omniksol-6k-TL2 8.7A... - Page 26 Omniksol-8k-TL2 11.6A Omniksol-9k-TL2 11.8A Omniksol-10k-TL2 1) Remove length y of N,L,1,2 conductor 35mm(1.38’’)/PE conductor 40mm(1.57’’) sheath of AC cable terminal, length x about 14mm(0.55’’) of the inner wrapper, then dress the conductor terminals with ferrules or tin soldering. 2) Check that all parts of AC connector are present. Then slide hex nut onto the cable and insert the cable end through clamp ring.
-
Page 27: Dc Side Connection
In order to reduce the line loss of DC side (no more than 1% of P ), Omnik suggest that the length of DC cable for each cable section should not exceed the limit below. Length of cable Model 2.5 mm 4 mm Omniksol-5k-TL2-3p Omniksol-6k-TL2 Omniksol-8k-TL2 128m Omniksol-9k-TL2 144m Omniksol-10k-TL2... - Page 28 MC4 Assembly instructions If, during self assembly, parts and tools other than those stated by MC are used or if the preparation and assembly instructions described here are disregarded then neither safety nor compliance with the technical data can be guaranteed. For protection against electric shock, PV-connectors must be isolated from the power supply while being assembled or disassembled.
- Page 29 （ill. 1） Stripping pliers PV-AZM... incl. built-in blade as well as hexagonal screwdriver A/F 2,5mm. 1,5 / 2,5 / 4 / 6 mm Cable cross section: type： PV-AZM-1.5/6 Order No. ： 32.6029-156 (ill. 2) Crimping tool incl. locator and built-in crimping insert(PV- CZM) Crimping range：...
- Page 30 (ill. 10) Strip cable insulation. L = 6-7, 5 mm. Take care not to cut individual strands. (ill. 11) Open the clamp (K) and hold. Place the contact in the appropriate cross section range. Turn the crimp lugs upwards. Release the clamp (K). The contact is fixed.
- Page 31 (ill. 15) Insert the crimped-on contact into the insulator of the male or female coupler until it clicks into place. Pull gently on the lead to check that the metal part is correctly engaged. (ill. 16) Insert the appropriate end of the test pin into the male or female coupler as far as it will go.
-
Page 32: Display And Operation
Display and Operation LCD Panel The display panel composed of three parts: lights, display and buttons. As shown in Figure 1. Figure 1 Display Panel... -
Page 33: Indicator
Indicator The inverter total has three indicators: running lights(green), Fault lights (red), and Communication lights(yellow), as shown in Figure 2, See Table 1 for specific meaning Figure 2 Indicator Panel Table1 Indicator Description Name State Description light Inverter connects to grid normal Running lights Inverter don’t connect to grid... -
Page 34: Display
Display Display interface is shown as Figure 4. Among them, red dashed box is a fixed display area, the rest is menu display area. Menu display area is in response to key operation, while fixed display area does not support control of keypad. Figure 4 Display interface 7.4.1 Fixed display area Fixed display area is divided into seven by content, contains Instant power display... - Page 35 E-total records the total generating capacity of the inverter, E-Today records the day generating capacity of inverter. 7.4.1.4、Temperature and time display block Heat sink temperature is in the left side, in the right side that is the internal temperature 7.4.1.5、PV connection information display block This mode provides the information of number of PV strings, PV voltage and PV current.
- Page 36 State Description wait Initialization, waiting for the grid Inverter has been connected to grid, and is running normally fault Inverter malfunctions upgrade inverter is upgrading process 7.4.2.2 Menu interface The menu structure is the hierarchical, consists of fault, configuration and equipment, as shown in figure 6, each main menu consists of several sub-menu items, on the left of vertical line is main menu item, the right is submenu item corresponds to main menu item.
- Page 37 then set the next digit password by “ENTER” button, until six correct password is entered, then press “ ENTER” button can enter to clear fault interface, as shown in Figure 8. Figure 7 Password authentication interface Figure 8 Clear fault interface Choose “YES”...
- Page 38 Figure 9 Current fault record interface Figure 10 Current fault record interface c) History fault information This page provides the history fault record, through “UP” and “DOWN” button to scroll up the records, at most can display 10pcs of history fault information. Every page will show single fault time, fault code and fault content, shown in Figure 11.
- Page 39 Figure 11 History fault information interface Setting item Setting menu is consist of fourteen sub-items, contains language setting, communication, safety regulation, WiFi and so on, shown in Figure 12. Figure 12 Setting item display interface a) Language setting The inverter supports three languages, Chinese, English and Deutsch. Select the language through “...
- Page 40 Figure 13 Setting language interface b) Set communication Does not support this feature. c) Set Safety regulation and country Set safety regulation, also needs the password authentication, to be verified by entering the safety selection interface, shown in Figure 14, the unit supports 43 types of safety regulations, VDE-4105, VDE-0126, Spain and so on, through the "UP"...
- Page 41 d) WiFi reset WiFi reset is to reset the WiFi AP address, as shown in Figure 15, select “YES” through “UP” and “DOWN” button, then press “ENTER”, operation is complete. Figure 15 WiFi reset interface e) Clear generating capacity Clear generating capacity, means clear total generating capacity(E-Total) and clear day generating capacity(E-Today), through the "UP"...
- Page 42 set the firmware g) set the price h) set time Time format is hours: minutes: seconds, shown in Figure 17, by "UP" and "DOWN" button to adjust the "hour", then press "ENTER" to adjust "minutes" Similarly, adjust "seconds", and finally press the "ENTER" key to finish the setup. Figure17 setting time interface set date Date The date format is month - day - year, shown in Figure 18, by "UP"...
- Page 43 set password k) set Over voltage and frequency limit Over voltage and frequency have two pages, over frequency (PAGE 19) and under frequency ( page 20) ,and press the button “up” and “down” to set it , over frequency setting have four limitation data , over frequency 1, over frequency 2, over frequency 3, over frequency 4.
- Page 44 set over voltage limit Over voltage setting is also divided to 2 pages, overvoltage settings (Figure 21) and under voltage setting (Figure 22). The way to set up under frequency limit is the same with set over frequency limit. Figure 21 Set overvoltage limit interface Figure 22 Set voltage limits interface m) Set MPPT scan time MPPT scan setting interface is shown as Figure 23, by "UP"...
- Page 45 Figure 23 Set MPPT scan interface n) protective item The inverter is consist of 11pcs of protection items, ISO, GFCI, DCI and so on, user can turn on or off by themselves, as shown in Figure 24, through “ UP” and “DOWN” button, can scroll up to view the state of protected item.
- Page 46 In setting state, through "UP" and "DOWN" button to turn on or off, then press "ENTER" button to confirm and enter to set up the next protection item state, until finish all the setup, through "ESC" button to exit settings page. Figure 25 Set interface protection items Equipment items Equipment menu is consists of four sub-menus, version, WiFi, model and serial number,...
- Page 47 a) Version NO. The version number menu is consist of three sub-menu, the main CPU version number page, Vice-CPU version page, CPU version number displayed page, through "UP" and "DOWN" to scroll to view, shown as figure 27, figure 28 and figure 29. Figure 27 main CPU version interface Figure 28 Vice CPU interface version...
- Page 48 Figure 29 display CPU version interface WiFi SN and add Figure 30 WiFi SN interface...
- Page 49 图 31 WiFi AP add interface c) Type of inverter Model information is shown in Figure 32. Figure 32 Models display interface d) Inverter SN...
- Page 50 Inverter serial number information is shown as Figure 33. Figure 33 Inverter SN interface 7.4.3.3 Curves interface Curve interface draws day power curve, X-axis represents time in 1 hour, from the left, the first is 1:00 to 2:00, and the far right represents the night 22:00. Y-axis represents the power value, the full scale means rated power, as shown in Figure 34.
-
Page 51: Ground
Ground Protective ground port position On the right side of the inverter has a protective earth hole, users can link to ground. Grounding screw has been attached to the machine, when user is connecting to the ground, first remove the screws, then put terminal with grounding cable to fix to the machine (support Grounding Cable use 5mm2) Crimping steps：... -
Page 52: State Information
State Information State Display State information Waiting Initialization & waiting Reconnect s Reconnect Wait Checking s Checking Normal Normal Normal state GFCI failure oversized Ground I Fault leakage current Fac Failure Grid frequency failure Vac Failure Grid voltage failure Utility Loss No Utility &... -
Page 53: Communication Setting
Communication Setting GPRS Card GPRS card is an optional device. If your inverter had installed the GPRS card, please go to 8.3. Register on monitoring website. After unpacking the box, please check the parts according to the below list. Contact the manufacturer immediately when you find any damage, missing or wrong model. -
Page 54: Installation Of Communication Card
Fig. GPRS card with card slot Name 14 pin connector SIM card slot I-PEX Interface The serial number is shown as below. Fig. Serial Number Installation of communication card Warning: Before installing the GPRS card to inverter, you must turn off both the AC side and DC side of inverter to make sure personal safety. - Page 55 Fig. Dismantle the communication box Unscrew the four screws on the interface panel with the screwdriver as shown in Picture above and keep the screws aside. Fig. Communication box and connector The standard connector has two holes. Use the single-hole connector to take place of the double-hole connector.
- Page 56 Fig. Single-hole connector Insert the GPRS antenna through the gland and screw the hex nut with a torque of 2.0 N.m. Connect the data line into the I-PEX interface. While using the second kind of GPRS card, just insert the SIM card into the card slot. Then insert the GPRS card into the inverter.
-
Page 57: Register On Monitoring Website
Install the communication box back to the inverter. While the installation is completed, Antenna can be turned in 360 degrees. Fig. Complete the installation Register on monitoring website The PV monitoring system of Omnik is supported by: IE8, Firefox, Chrome, and Safari. Login the website http://www.omnikportal.com, click register to enter the user registration page, follows the requirements for registration;... - Page 58 Fig. Choose the account type Remarks: please read the < Omnik service agreement > carefully, the enclosure is the cost list for all the countries; please choose your operators End User means the final user “*” you must fill it...
- Page 59 Fig. Fill in the power station information...
- Page 60 Fig. Fill in the power station information After the register, you may enter next chapter 8.4 Login Monitoring System.
-
Page 61: Login Monitoring System
Login monitoring System After the successful register and account activation, open the login interface as below. Input the correct email and code. Enter the PV monitoring system. Then you can monitor and manage the power station. Input the correct email and code Fig. - Page 62 Fig. List of power station Enter the configure Enter the Back to user “company account” Not yet open sharing case interface interface Reset Add one case under your account passwor Fig. Navigation Bar...
- Page 63 Change case Energy saving Case info search Real-time power and generated energy switchover Print current figure Power station info Fig. Main interface of Power Station...
- Page 64 Internal temperature Latest data collecting time Fig . Real Time Interface Parameter options Choose the aim inverter Fig. History Interface...
- Page 65 Fig. Alert Interface Fig. System Setting Interface...
-
Page 66: Wifi Card
Fig. Add serial number WiFi card WiFi card is an optional device. If your inverter had installed the WiFi card, please go to 8.6. Network Settings. If your inverter had not installed the WiFi card, please go to 8.2. Installation of communication card first, then go to 8.6. Network Settings. After unpacking the box, please check the parts according to the below list. -
Page 67: Netwoek Settings
WiFi card is shown as below: Name 14 pin connector Reset Button I-PEX Interface Fig. WiFi card Fig. Serial Number Netwoek Settings 1) Prepare a computer or device, e.g. tablet PC and smart phone that enables WiFi 2) Obtain an IP address automatically Open Wireless Network Connection Properties, double click Internet Protocol ... - Page 68 3) Open wireless network connection and click View Wireless Networks Select wireless network of the data logging module, no passwords required as default. The network name consists of AP and the serial number of the product. Then click Connect.
- Page 69 Connection successful Notice: If AP_ (serial number of product) is not available in the wireless network list, there may be problems in the connection or setting of data logging module. Please check if the WiFi had installed ok, and inverter has been powered on. Before troubleshooting, please inquire with your inverter installer whether you are allowed to remove the cover of the inverter to trouble shoot the module.
- Page 70 admin admin (b) In the configuration interface of WiFi module, you can view general information of the module. Follow the setup wizard to start quick setting. Click Wizard to start...
- Page 71 Click Start to continue Click Refresh to search available wireless networks...
- Page 72 Next Select the wireless network you need to connect, then click Notice: ① If the signal strength (RSSI) of the selected network is <10%, which means unstable connection, please adjust the antenna of the router, or use a repeater to enhance the signal. ②...
- Page 73 Enter the password for the selected network, then click Next Select Enable to obtain an IP address automatically, then click Next Notice: ① Turn off the firewall of the router ② Make sure the DHCP function of the router is enable...
- Page 74 If setting is complete, the above page will display. Click OK to restart. If setting is complete, the above page will display. After your WiFi card set ok and get IP address from your router for example: 192.168.16.8, (You may see the IP address from inverter) Input: http://192.168.16.8/ will display the following page:...
- Page 75 You may also add your domain name of WiFi card to easy access according below picture , after you set ok, input http://wifi, you may also access the related page.
-
Page 76: Rs485 Card
Now we finish the network setting, please go to 8.3. Register on monitoring website. RS485 card Fig. RS485 card RS485 card is an optional device. RS485 card has two RJ45 ports and one USB port. The USB port is used to update the inverter. The RJ45 port is used to communicate with WiFi kit or GPRS kit. -
Page 77: Recycling And Disposal
Fig. WiFi/GPRS Kit You can get more information in the user manual of WiFi/GPRS kit. Recycling and Disposal To comply with European Directive 2012/19/EU on waste Electrical and Electronic Equipment and its implementation as national law, electrical equipment that has reached the end of its life must be collected separately and returned to an approved recycling facility. -
Page 78: Troubleshooting
Troubleshooting LCD display Possible actions 1. Check the impedance between PV (+) & PV (-) and the inverter is earthed. The impedance must be greater than Isolation Fault 2M. 2. Check whether the AC-side has contacts with earth. 1. The ground current is too high. 2. -
Page 79: Abbreviation
Abbreviation Liquid Crystal Display Light Emitting Diode MPPT Maximum Power Point Tracking Photovoltaic Voltage at the DC side Voltage at the AC side Vmpp Voltage at the Maximum Power Point Impp Amperage at Maximum Power Point Alternating Current ( Form of electricity supplied by Utility Company ) Direct Current ( Form of electricity generated by PV modules ) -
Page 80: Contact
Contact Omnik New Energy Co., Ltd. (Headquarters) Address: Third Floor, Building 3, No.63 Weixin Road, SIP, Suzhou, China Tel: +86-512-6956-8216 Fax: +86-512-6295-6682 E-mail: Sales@omnik-solar.com Service@omnik-solar.com Website: www.omnik-solar.com Omnik New Energy B.V Address: De Liesbosch 82-A 3439 LC Nieuwegein Tel: +31 30265 7845... - Page 81 GUARANTEE CARD Agency retention ------------------------------------------------------------------------------------------------------------ 的 User information 得 Product Model Product ID Purchase Date Customer Name 的 Historical Warranty 的 Warranty date Troubleshooting Finished date Customer Signature Client retention 的 User Information 得 Product Model...
- Page 82 Product ID Purchase Date Customer Name 的 Historical Warranty 的 Warranty date Troubleshooting Finished date Customer Signature -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 的 的 Warranty Terms 1. Please fill in this card carefully and read the following warranty terms carefully to ensure that the product is effectively guaranteed. ①...
