Technical Manual
Twilight-/Temperature Sensor KNX [SCN-DTSEN1.01]

3 Communication objects

3.1 Standard settings of the communication objects

No. Name
0 In operation
1 Brightness
2 Brightness
3 Brightness
4 Brightness
5 Twilight
6 Twilight
7 Twilight
8 Twilight
9 Temperature
10 Temperature
11 Temperature
Table 1: Communication objects – Standard settings
The table above shows the preset default settings. The priority of the individual communications
objects and the flags can be adjusted by the user as required. The flags assign the communication
objects their respective tasks in programming, where "C" stands for communication, "R" for read,
"W" for write, "T" for transmit and "U" for update.
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
6
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
Standard settings
Object function
Status
Send measured value
Threshold value 1
Threshold value 2
Lock object: Threshold values
Send measured value
Switchover Day/Night
Blinds Up/Down
Lock object: Blinds Up/Down
Send measured value
Threshold value 1
Threshold value 2
Length C R W T
1 Bit X X X
2 Byte X X X
1 Bit X X X
1 Byte
1 Bit X X X
1 Byte
1 Bit X X X
2 Byte X X X
1 Bit X X X
1 Bit X X X
1 Bit X X X
2 Byte X X X
1 Bit X X X
1 Byte
1 Bit X X X
1 Byte
U
