Specifications

Monitor
Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colors
Synchronization
Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Display Area
Landscape : Horiz. :
Portrait : Horiz. :
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
* 1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This
is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
LCD2080UX+manual0624.p65
MultiSync LCD
®
Monitor
Diagonal: 20.1 inch
20.1 inch
1600x1200
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7Vp-p and Sync Negative 0.3V p-p)
16,777,216
Horizontal: 31.5 kHz to 91.1 kHz
Vertical: 50.0 Hz to 85.0 Hz
Left/Right: +88˚ (CR>10)
Up/Down: +88˚ (CR>10)
16ms (Typ.)
Landscape: 720 x 400* 1 :VGA text
640 x 480* 1 at 60 Hz to 85 Hz
800 x 600* 1 at 56 Hz to 85 Hz
832 x 624* at 75 Hz
1
1024 x 768* at 60 Hz to 85 Hz
1
1152 x 870* 1 at 75Hz
1280 x 1024* 1 at 60 Hz to 85 Hz
1600 x 1200 at 60 Hz ............................... display performance.
Portrait: 480 x 640* at 60 Hz to 85 Hz
1
600 x 800* at 56 Hz to 85 Hz
1
624 x 832* 1 at 75 Hz
768 x 1024* 1 at 60 Hz to 85 Hz
870 x 1152* 1 at 75 Hz
1024 x 1280* at 60 Hz to 85 Hz
1
1200 x 1600 at 60 Hz ............................... display performance.
408 mm/16.1 inches
Vert. : 306 mm/12.0 inches
306 mm/12.0 inches
Vert. : 408 mm/16.1 inches
100 - 50/60 Hz
240 V ~
0.7 – 0.35A
442.0 mm (W) x 366.3 - 496.3 mm (H) x 200 mm (D)
Landscape:
17.4 inches (W) x 14.4 - 19.5 inches (H) x 7.9 inches (D)
Portrait: 340 mm (W) x 458.3 - 547.3 mm (H) x 200 mm (D)
13.4 inches (W) x 18.0 - 21.5 inches (H) x 7.9 inches (D)
130 mm / 5.1 inches (Landscape)
10.5 kg
23.1 lbs
5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Feet: 0 to 12,000 Feet
-10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Feet: 0 to 40,000 Feet
14
14
Notes
2080UX+
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.255 mm dot
pitch; 250cd/m 2 white luminence; XtraView™
technology; 400:1 contrast ratio, typical
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal
