Controls

OSM (On-Screen Manager) control buttons on the front of the monitor function
®
as follows:
To access OSM menu, press any of the control buttons (
To change signal input, press the SELECT button.
NOTE: OSM must be closed in order to change signal input.
Button
MENU/EXIT
Left/Right
Down/Up
SELECT
RESET/DV MODE
NOTE: When RESET is pressed in the main and sub-menu, a warning window will
appear allowing you to cancel the RESET function by pressing the MENU/EXIT
button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO Contrast (Analog input only)
Adjusts the image displayed to optimal settings.
DV MODE
Allows you to select the suitable setting for Movie, Picture , etc.
Auto Adjust
Automatically adjusts the Image Position, H. Size and Fine settings.
Image Controls
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
H.SIZE
Adjust this setting to increase or decrease the horizontal size.
FINE
Adjust this setting to improve focus, clarity, and image stability.
Menu
Exits the OSM controls.
Exits to the OSM main menu.
Moves the highlighted area left/right to select control menus.
Moves the bar left/right to increase or decrease the adjustment.
Moves the highlighted area down/up to select one of the controls.
Active Auto Adjust function. Enter the OSM sub menu.
Resets the highlighted control menu to the factory setting.
Enter the DV MODE.
(Analog input only)
(Analog input only)
MENU/EXIT,
0
Left, Right, Down, Up).
