Operation and Programming
SwitchPak - SPAK BAS

How Do I Check the Relay Status and Timeout Value?

SwitchPak can display each relay's status, ON or OFF, as well as the current timeout value (if there is one in effect)
The flow diagram below shows the steps to check relay status.
START
HERE
MENU
PRESS AND RELEASE
THE DOWN ARROW
DIAGNOSTIC
UNTIL
IS SELECTED

How Do I Use Flash To Find To Locate the Circuit(s) Being Controlled?

Flash To Find turns the selected relay on and off repeatedly, once every 2 seconds (approx), allowing you to move about
the areas being controlled and locate the fixtures (loads) controlled by that particular relay.
START
HERE
MENU
PRESS AND RELEASE
THE DOWN ARROW
UNTIL DIAGNOSTIC
IS SELECTED
DIAGNOSTIC
[BACK] [OK]
RELAY 3 STATUS
OFF
[BACK]
DIAGNOSTIC
[BACK] [OK]
BUTTON(S) OF
Synergy Lighting Controls
TEL : (800)-533-2719
PRESS AND
RELAY STATUS
RELEASE THE
COMM STATUS
DOWN ARROW
FLASH TO FIND
UNTIL
[BACK]
RELAY STATUS
IS SELECTED
PRESS AND
RELEASE THE
RELAY STATUS
DOWN ARROW COMM STATUS
FLASH TO FIND
UNTIL
[BACK]
FLASH TO FIND
IS SELECTED
RELAYS
1
PRESS THE
2
THE RELAYS
TO FLASH
3
4
Conyers Ga, 30012
www.Synergylightingcontrols.com
PRESS
RELAY BUTTON(S)
TO VIEW
STATUS
RELAYS
1
[OK]
2
3
4
FLASH TO FIND
Select relays using
the RELAY keys.
[OK] [BACK]
Part No. CDCS000310 Rev B
8/11 Page 21
