Controls
OSD (On-Screen Display) control buttons on the right side of the
monitor function as follows:
1
2
3
4
5
OSD Main Menu
For screen adjustments, press the [
Main Menu shown below. Press the [▲] or [▼] button to scroll up or down the menu to
your required options. The OSD will automatically turn off in 30 seconds without any
manipulation. Press the [a] button to adjust the image for best performance.
Contrast: Adjusts the image brightness in relation to the background.
Brightness: Adjusts the overall image and background screen brightness.
Color Adjust: Five color presets select the desired color setting (9300K, 6500K,
5400K, 5000K and Native color preset can not be changed). User Color: increases
or decreases Red, Green or Blue color depending on selection. The change in color
will appear on screen and the increase or decrease direction will be shown on the
bars. Native: original color displayed by the LCD panel that is unadjustable.
Manual Image Adjust
H. Position: Moves the screen image on the screen to the right or left.
V. Position: Moves the screen image on the screen up or down.
H. Size: Adjusts the width of the screen.
Fine Tune: Adjusts the image performance.
Sharpness: Adjusts the image sharpness.
Language Select: Selects preferred language used in the OSD menus.
LCD15651765manual.p65
–MultiSync LCD1765
1. Power switch
2. Auto-Sync
3. Opens Contrast & Brightness menu/Menu
4. Opens Contrast & Brightness menu/Menu
5. Enters the OSD controls, OSD sub-menu,
] button to display the OSD (On-Screen Display)
7
7
Scroll up/Moves the bar left to decrease the
adjustment
scroll down/Moves the bar right to
increase the adjustment
and EXIT
