Specifications

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DVI:
DisplayPort:
DisplayPort Connector:
VGA:
15pin Mini D-sub:
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active
Landscape: Horiz.: 376.3 mm/14.8 inches
Display Area
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
Headphone Output:
STEREO Mini Jack:
Speakers
Practical Audio Output:
Power Supply
Current Rating
Power
Maximun Operation:
Consumption
Normal Operation:
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifications are subject to change without notice.
MultiSync EA192M
Diagonal: 48.2 cm/19.0 inches
48.2 cm/19.0 inches
1280 x 1024
DVI-D 24pin:
Digital RGB
Digital RGB
Analog RGB 0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
16,777,216
Horizontal:
31.5 kHz to 81.1 kHz (Analog)
31.5 kHz to 81.1 kHz (Digital)
Vertical:
56.0 Hz to 75.0 Hz
Left/Right:
±85° (CR > 10)
Up/Down:
75°/85° (CR > 10)
720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 864*
1152 x 870*
1280 x 960*
1280 x 1024*
Vert.:
301.1 mm/11.9 inches
Portrait: Horiz.: 301.1 mm/11.9 inches
Vert.:
376.3 mm/14.8 inches
Analog Audio
Digital Audio
1.0 W + 1.0 W
AC 100-240 V ~ 50/60 Hz
0.60-0.35 A (with Audio)
32 W
23 W
Landscape:
408.0 mm (W) x 386.4 - 496.4 mm (H) x 213.9 mm (D)
16.1 inches (W) x 15.2 - 19.5 inches (H) x 8.4 inches (D)
Portrait:
338.0 mm (W) x 424.7 - 532.4 mm (H) x 213.9 mm (D)
13.3 inches (W) x 16.7 - 21.0 inches (H) x 8.4 inches (D)
110 mm/4.3 inches (Landscape condition)
107.7 mm/4.2 inches (Portrait condition)
5.5 kg (12.1 lbs)
5°C to 35°C/41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
1
: VGA text
1
@ 60 Hz to 75 Hz
1
@ 56 Hz to 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 60 Hz to 75 Hz............ resolution for optimal display performance.
English-14
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.294 mm dot pitch;
2
250 cd/m
white luminence; 1000:1 contrast ratio,
typical (25000:1 Contrast ratio, Dynamic).
DVI-D with HDCP
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
Depends on display card used.
Automatically
Automatically
Automatically
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites recommended
Stereo L/R 500mV rms
PCM 2ch 32, 44.1, 48 KHz (16/20/24bit)
Headphone Impedance 32 Ohm
