We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you
USE AND CARE GUIDE
59IN ROSEMONT FIREPLACE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
for choosing Home Decorators Collection!
THANK YOU
Model # WSFP59HD-1
WSFP59ECHD-1
WSFP59ECHD-2
Advertisement
Related Manuals for Home Decorators Collection WSFP59ECHD-2
Summary of Contents for Home Decorators Collection WSFP59ECHD-2
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ............... 3 Table of Contents ............2 Safety Information ............2 Package Contents ................ 3 Warranty ................. 2 Assembly ............... 5 Pre-Assembly ..............2 Care and Maintenance ..........15 Planning Assembly ............... 2 Tools required ................2 Safety Information Please read and understand these instructions before assembling and using this console. -
Page 3: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22 MAXIMUM LOAD 50 MAXIMUM MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB MAXIMUM L Part... - Page 4 Base Lower right partition panel Upper back panel Lower side panel Lower back panel Door Upper partition panel Fireplace insert Upper side panel Remote control with battery Firebox support...
-
Page 5: Assembly
Assembly Screwing the cam bolts NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. Unpack the unit and confirm that you have all the hardware and required parts listed. Assembly the unit on a carpeted floor or the empty □... - Page 6 Assembly (continued) Attaching the lower partition panels Insert six wood dowels (CC) into the inner holes of the lower partition panels (L and M) and attach them to the base (D) by using four □ long screws (DD). Screwing the cam bolt Securely screw eleven cam bolts (BB) into the designated small holes on the center shelf (C).
- Page 7 Assembly (continued) Attaching the middle crossbar assembly Align and attach the middle crossbar assembly (J) to the center shelf (C) by using two wood dowels (CC) and three cam locks (AA). □ Installing the center shelf assembly Insert ten wood dowels (CC) into the top inner holes of the lower panels (L, M and N). □...
- Page 8 Assembly (continued) Screwing the cam bolt Stand last assembly upright. □ Securely screw six cam bolts (BB) into the designated small holes on the center shelf (C). Fully tighten with a phillips screwdriver. □ Installing the upper side and partition panel □...
- Page 9 Assembly (continued) Screwing the cam bolt to top panel Securely screw nine cam bolts (BB) into the designated small holes on the top panel (A). Fully tighten with a phillips screwdriver. □ Installing the top front stretcher Align and attach the top front stretcher (B) to the top panel (A) by using two wood dowels (CC) and three cam locks (AA). □...
- Page 10 Assembly (continued) Attaching the top panel Insert five wood dowels (CC) into the inner holes of the upper side panels and partition panel (H and G ). Position the top panel (A) onto □ the inserted wood dowels (CC) and fasten it in place with six cam locks (AA). Installing the metal plate Fasten the middle crossbar assembly (J) to the front molding of lower partition panels (L and M) by attaching two metal plates (II) at the □...
- Page 11 Assembly (continued) Attaching the back panels Pick up the upper back panel (E) and align the drilled holes with the pilot holes on the back stretcher of top panel (A). Attach the back □ panel (E) in place using the provided washer head screws (GG). Attaching two lower back panels (F) in place with the provided washer head screws (GG).
- Page 12 Assembly (continued) Attaching the door Pick up one door (O) and attach the extended hinge arms to the hinge bases installed on one side panel (N). Loosen the bolt on the back □ of hinge base for an easy fit. Align and insert the “U” slot on hinge arm under the bolt head on the back of hinge base. Make sure that both door hinges engage and function properly.
- Page 13 Assembly (continued) Attaching the rubber bumper and cam lock cover Plug the cam lock covers (JJ) onto the visible cams locks to conceal the cams. □ □ Stick the rubber bumpers (NN) at the corners of the doors (O) as shown. Installing the fireplace insert □...
- Page 14 Assembly (continued) Attaching the firebox support Align and attach the firebox support (I) onto the base (D) by screwing two bolts (HH) into the countersunk holes. □ Electric Firebox Attaching the acrylic stopper NOTE: You must install the Acrylic TV Stopper to prevent TV from tipping when placing your flat panel television on the table-top Remove the paper backing of acrylic stopper (OO), then properly align the acrylic stopper into the cut-out on the acrylic stopper □...
- Page 15 Assembly (continued) Installing the tipping restraint hardware NOTE: Young children can be seriously injured by tipping furniture. You must install the tipping restraint hardware with the unit to prevent the unit from tipping, causing any accidents or damage. The tipping restraints are intended only as a deterrent, they are not a substitute for proper adult supervision. The tipping restraints are not earthquake restraints.
-
Page 16: Care And Maintenance
Care and Maintenance A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping. To clean and care for your furniture: □ Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polishes is not necessary. - Page 17 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
