OMSID # 207000471
Model # WSFP60ECHD-22
ASSEMBLY INSTRUCTIONS
Brookdale 60 in. Media Console with Infrared Electric Fireplace
in Natural Beige Driftwood Finish
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection WSFP60ECHD-22
Summary of Contents for Home Decorators Collection WSFP60ECHD-22
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
- Page 2 Table of Contents Table of Contents ............... 2 Hardware Included ..............3 Safety Information .............. 2 Package Contents ..............4 Warranty ................2 Assembly ................5 Pre-Assembly ..............2 Care and Maintenance ............16 Planning Assembly ..............2 Tools required ................2 Safety Information Fits up to most 177.8 cm / 70 in. flat panel TVs Please read and understand these instructions before assembling Maximum load 61.2 kg / 135 lb and using this console.
- Page 3 Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Cam lock 34 + 1 extra Rubber bumper 4 + 1 extra Cam bolt 34 + 1 extra L-shaped metal brace Wood dowel 42 + 2 extra Triangle metal plate Long wood screw...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Right lower partition panel Center shelf Right lower side panel Bottom panel Left middle stile Upper back panel Right middle stile Bottom back stretcher Middle crossbar Bottom front stretcher Middle crossbar molding Left door Upper side panel...
- Page 5 Assembly Screwing the cam bolts NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty □...
- Page 6 Assembly (continued) Combining the middle crossbar and molding NOTE: The middle crossbar (P) and middle stiles (N and O) are designed to be reversible so that you can choose the same finish as the whole unit or achieve slate surround for the fireplace insert. Refer to the dowel assembling guide drawing in this step for further clarification on how to properly glue in the wooden dowels.
- Page 7 Assembly (continued) Attaching the middle stiles Choose the same configuration as you chose for the middle crossbar (P). Fasten the left middle stile (N) to the left lower partition □ panel (K) with two wood dowels (CC) and three medium wood screws (EE) as shown. Repeat the same procedure to combine the right middle stile (O) and right lower partition panel (L) together.
- Page 8 Assembly (continued) Attaching the partition panels to bottom panel Glue four wood dowels (CC) into the bottom inner holes of both partition panels (K and L) and attach them to the bottom panel (C) with □ four long wood screws (DD). Installing the side panels Glue six wood dowels (CC) into the inner holes of the bottom panel assembly at both ends.
- Page 9 Assembly (continued) Installing the center shelf Glue eight wood dowels (CC) into the top inner holes of both side panels (J and M) and partition panels (K and L). □ Ask for assistance to position the center shelf (B) onto the inserted wood dowels (CC) and attach it in place by engaging eight cam □...
- Page 10 Assembly (continued) Attaching the top panel Glue five wood dowels (CC) into the top inner holes on both upper side panels (R) and partition panel (S). Position the top panel (A) □ onto the inserted wood dowels (CC) and fasten it in place by engaging six cam locks (AA). Installing the triangle metal plates Using the pilot holes as a guide, fasten two triangle metal plates (MM) at the bottom joints between the bottom front stretcher (F) and □...
- Page 11 Assembly (continued) Screwing the floor levelers Screw two floor levelers (NN) into the installed triangle metal plates (MM). □ Securing the middle crossbar molding Flip the assembled unit around at its front edges. Insert two medium wood screws (EE) through the drilled holes on the left and right □...
- Page 12 Assembly (continued) Attaching the back panels Pick up the upper back panel (D) and align the drilled holes against the upper long edge with the pilot holes on the back stretcher of □ the top panel (A). Attach the upper back panel (D) in place using the provided washer head screws (FF). Align and attach two lower back panels (I) to the lower side panels (J and M) and partition panels (K and L) with the provided washer □...
- Page 13 Assembly (continued) Attaching the handles and rubber bumpers Attach one handle (OO) to the front side of each door with the handle bolts (PP). □ Stick the rubber bumpers (KK) at the outer corners of both doors (G and H) as shown. □...
- Page 14 Assembly (continued) Installing the fireplace insert Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the □ bottom panel (C) as it may scratch the unit. Electric Firebox Attaching the L-shaped metal braces...
- Page 15 Assembly (continued) Attaching the acrylic stopper Remove the paper backing from the acrylic stopper (QQ). Then properly align the acrylic stopper into the cut-out on the acrylic stopper □ template on the front of the top panel (A). Press down on the acrylic stopper to help adhesion. At the back of the top panel (A), carefully pull out the thumb tacks to remove the acrylic stopper template.
- Page 16 Citrus oil based products can be obtained at supermarkets or hardware stores. Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
