2.8.2.

Single phase installation

In the case of single-phase installation, follow the steps below:
1.
Loosen the left-hand box sheath (P) and insert the Ø 25 mm corrugated sheath.
2.
Tighten the box sheath (P).
3.
Insert the power supply cables and connect phase, neutral N and earthing cable PE to
the CN1 power supply terminal block, making sure that the entire stripped section of
each cable is fully inserted into each terminal.
