OWNER'S MANUAL
MODEL APT 211
SOLID STATE
HEAVY DUTY, HIGH CYCLE
BELT DRIVEN TROLLEY OPERATOR
©
COMMERCIAL DOOR OPERATOR
LISTED
®
NOT FOR RESIDENTIAL USE
The Chamberlain Group, Inc.
A DUCHOSSOIS ENTERPRISE
845 Larch Avenue
Elmhurst, Illinois 60126

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APT 211 and is the answer not in the manual?

Questions and answers

Related Manuals for Chamberlain APT 211

Summary of Contents for Chamberlain APT 211

  • Page 1 The Chamberlain Group, Inc. A DUCHOSSOIS ENTERPRISE 845 Larch Avenue © Elmhurst, Illinois 60126 OWNER'S MANUAL MODEL APT 211 SOLID STATE HEAVY DUTY, HIGH CYCLE BELT DRIVEN TROLLEY OPERATOR Serial # ___________________ (located on electrical box cover) COMMERCIAL DOOR OPERATOR...
  • Page 2 SPECIFICATIONS MOTOR ELECTRICAL (RESILIENT MOUNTING) CONTROL VOLTAGE:........5V dc TYPE:...........Continuous duty AUXILIARYVOLTAGE: ........24V dc HORSEPOWER: ..........1/2 Hp CONTROL STATION: ........3 Button Single phase OPEN/CLOSE/STOP, NEMA 1 WIRING TYPE: ........B2 (Standard) SPEED: ............1725 RPM Momentary contact to OPEN/CLOSE/STOP plus VOLTAGE:............115 Volt wiring for sensing device to reverse and auxiliary devices to open and close with open override (other CURRENT:............10 AMP types available.
  • Page 3 ASSEMBLE TRACK AND OPERATOR WARNING WARNING KEEP DOOR BALANCED. STICKING OR BINDING DO NOT CONNECT ELECTRIC POWER UNTIL DOORS MUST BE REPAIRED. DOORS, DOOR INSTRUCTED TO DO SO. SPRINGS, CABLES, PULLEYS, BRACKETS AND THEIR HARDWARE MAY BE UNDER EXTREME TENSION AND CAN CAUSE SERIOUS PERSONAL INJURY OR DEATH.
  • Page 4 INSTALL OPERATOR CAUTION: AT LEAST TWO PERSONS AND A STRONG, SAFE WORKING PLATFORM ARE REQUIRED FOR THE INSTALLATION OF OPERATOR. CAUTION FIGURE 2 Building TO AVOID DAMAGE TO DOOR AND OPERATOR, Support MAKE ALL DOOR LOCKS INOPERATIVE. SECURE LOCK(S) IN "OPEN" POSITION. Vertical IF THE DOOR LOCK NEEDS TO REMAIN Centerline...
  • Page 5 9. Raise operator straight up until the door can be COIL CORD (OPTIONAL) raised to the full open position. See Figure 5. REFER TO (A) IN ILLUSTRATION Temporarily secure to ceiling or rafters with rope Connect operator end of coil cord to junction box (not or other suitable means.
  • Page 6 CONNECT OPERATOR TO POWER SUPPLY AND INSTALL CONTROL STATION WARNING WARNING DISCONNECT POWER AT THE FUSE BOX BEFORE INSTALL THE CONTROL STATION WHERE THE PROCEEDING. DOOR IS VISIBLE, BUT AWAY FROM THE DOOR AND ITS HARDWARE. IF CONTROL STATION CANNOT BE OPERATOR MUST BE PROPERLY GROUNDED AND INSTALLED WHERE DOOR IS VISIBLE, OR IF ANY CONNECTED IN ACCORDANCE WITH LOCAL...

  • Page 7: Emergency Disconnect System

    EMERGENCY DISCONNECT SYSTEM WARNING DOOR ARM IS RELEASED FROM TROLLEY WHEN EMERGENCY DISCONNECT OPENS. TO AVOID BEING STRUCK BY DOOR ARM, DO NOT STAND UNDER THE ROPE OR DOOR ARM WHEN PULLING THE EMERGENCY RELEASE. Trolley Track Header Bracket Clevis TO DISCONNECT Emergency Emergency...

  • Page 8: Adjust Clutch

    ADJUST CLUTCH Adjust clutch so that it is tight enough to open and close the door but will slip when the door meets an Clutch Pad Adjusting Nut obstruction. Either loosen or tighten the clutch nut Spring with 1/4 turn increments. The clutch will require Clutch Plate periodic inspection and adjustment.
  • Page 9 BRAKE INSTALLATION & ASSEMBLY PARTS HTL /APT Shown APT Bearings Shown. Models HTL and APT Brake Installation Identical WARNING Cotter TO AVOID SERIOUS PERSONAL INJURY OR DEATH FROM ELECTROCUTION, DISCONNECT ELECTRICAL 3/4" Washer POWER TO OPERATOR BEFORE PROCEEDING. 3/4" Washer Clutch Pulley Shaft 1.
  • Page 10 SOLID STATE SINGLE PHASE WIRING DIAGRAM SENSING LIMIT Yellow SWITCH White White OPEN CLOSE LIMIT Blue LIMIT SWITCH SWITCH Black White White White OVERLOAD PROTECTOR Black Blue White Yellow Blue Yellow Orange White Orange MOTOR Black Black THIS WIRE NOT USED WITH POWER INDUCTOR POWER Black...
  • Page 11 Hot 115V, 208-230V, 1Ø TB1- Remove Jumper Open to Install Interlock Close Open / Close Stop Sensing Device RADIO CONTROL (24V dc only) The Chamberlain Group, Inc. 1Ø Standard Power & Control Connection Diagram Solid State CDO 2/22/94 - 2/25/94...
  • Page 12 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 13: Optional Settings

    MEMO: OPTIONAL SETTINGS Set Maximum Run Timer Begin with door in closed position. Set dip switch to max. run timer mode. Press control station open button to operate door from closed to max. full open position without stopping. Set dip switch to desired operating mode (B2, C2, D1, E2, T, TS).

  • Page 14: Operating Mode

    OPERATING MODE TYPE STATION 3 Button, 1 Button, 1 & 3 Button Radio Control Function: Momentary contact to open, close and stop, plus wiring for sensing device to reverse and auxiliary devices to open and close with open override. 3 Button, 3 Button Radio Control Function: Momentary contact to open and stop with constant pressure to close, open override plus wiring for sensing device to reverse.
  • Page 15 NEMA MOTOR WIRING DIAGRAMS SINGLE VOLTAGE The Chamberlain Group, Inc. 1/3 & 1/2HP 115V only NEMA Motor Wiring Diagrams 2/19/94 115V Motor Black T1 - Blue Blue T4 - Yellow Yellow T5 - Black Orange T8 - Red Cable 1 PHASE...
  • Page 16 ILLUSTRATED PARTS - SOLID STATE ELECTRICAL BOX...
  • Page 17 ELECTRICAL BOX PARTS LIST 211 SOLID STATE ITEM PART NO. QTY. DESCRIPTION 1B3727 Terminal Assy. 3-Lug 41K4304 Switch Bracket Assy. (Aux. & Sensing) 1B3796 Limit Shaft-Sprocket Assy. 1B4681 Cover & Hinge Assy. 1C4691 Electric Box Assy. 1B4683 Wire Harness Limit Switch 11A012 Flanged Sleeve Bearing 12B552...
  • Page 18 ILLUSTRATED PARTS - OPERATOR MODEL APT 211...
  • Page 19 REPAIR PARTS FOR MODEL APT 211 ITEM PART NO. DESCRIPTION Electrical Box Assy. (See detail) HOW TO ORDER REPAIR PARTS 1B4684 Motor Cable Assy. OUR LARGE SERVICE ORGANIZATION 123D141 Motor 1/2 hp 115V 1 Phase SPANS AMERICA 1C4707 Motor Mounting Bracket Assy.

  • Page 20: Control Connection Diagram

    B2, T & TS MODE ONLY RADIO CONTROL (24Vdc only) SENSING DEVICE TO REVERSE OR STOP EXTERNAL INTERLOCK REMOVE JUMPER 2 OR MORE WIRING TYPES - ALL © 1995, The Chamberlain Group, Inc. 114A1797C All Rights Reserved Printed in Mexico...
