OWNER'S MANUAL
SERIES 2000
MODEL APT 2211
HEAVY DUTY, HIGH CYCLE
BELT DRIVEN TROLLEY OPERATOR
©
COMMERCIAL DOOR OPERATOR
LISTED
®
NOT FOR RESIDENTIAL USE
®
The Chamberlain Group, Inc.
A DUCHOSSOIS ENTERPRISE
845 Larch Avenue
Elmhurst, Illinois 60126

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Chamberlain 2000 Series

Summary of Contents for Chamberlain 2000 Series

  • Page 1 The Chamberlain Group, Inc. A DUCHOSSOIS ENTERPRISE 845 Larch Avenue © Elmhurst, Illinois 60126 OWNER'S MANUAL SERIES 2000 MODEL APT 2211 HEAVY DUTY, HIGH CYCLE BELT DRIVEN TROLLEY OPERATOR Serial # (located on electrical box cover) COMMERCIAL DOOR OPERATOR Date of Installation LISTED ®...

  • Page 2: Specifications

    SPANS AMERICA ADDRESS ORDER TO: INSTALLATION AND SERVICE INFORMATION ARE AVAILABLE 6 DAYS A WEEK THE CHAMBERLAIN GROUP, INC. Electronic Parts & Service Dept. CALL OUR TOLL FREE NUMBER - 1-800-528-6563 2301 N. Forbes Blvd., Suite 104 HOURS 7:00 TO 3:30 p.m. (Mountain Std. Time)
  • Page 3 ASSEMBLE TRACK AND OPERATOR WARNING WARNING KEEP DOOR BALANCED. STICKING OR BINDING DO NOT CONNECT ELECTRIC POWER UNTIL DOORS MUST BE REPAIRED. DOORS, DOOR INSTRUCTED TO DO SO. SPRINGS, CABLES, PULLEYS, BRACKETS AND THEIR HARDWARE MAY BE UNDER EXTREME TENSION AND CAN CAUSE SERIOUS PERSONAL INJURY OR DEATH.
  • Page 4 INSTALL OPERATOR CAUTION: AT LEAST TWO PERSONS AND A STRONG, SAFE WORKING PLATFORM ARE REQUIRED FOR THE INSTALLATION OF OPERATOR. CAUTION FIGURE 2 Building TO AVOID DAMAGE TO DOOR AND OPERATOR, Support MAKE ALL DOOR LOCKS INOPERATIVE. SECURE LOCK(S) IN "OPEN" POSITION. Vertical IF THE DOOR LOCK NEEDS TO REMAIN Centerline...
  • Page 5 9. Raise operator straight up until the door can be COIL CORD (OPTIONAL) raised to the full open position. See Figure 5. REFER TO (A) IN ILLUSTRATION Temporarily secure to ceiling or rafters with rope Connect operator end of coil cord to junction box (not or other suitable means.
  • Page 6 CONNECT OPERATOR TO POWER SUPPLY AND INSTALL CONTROL STATION WARNING WARNING DISCONNECT POWER AT THE FUSE BOX BEFORE INSTALL THE CONTROL STATION WHERE THE DOOR PROCEEDING. IS VISIBLE, BUT AWAY FROM THE DOOR AND ITS HARDWARE. IF CONTROL STATION CANNOT BE OPERATOR MUST BE PROPERLY GROUNDED AND INSTALLED WHERE DOOR IS VISIBLE, OR IF ANY CONNECTED IN ACCORDANCE WITH LOCAL...

  • Page 7: Emergency Disconnect System

    EMERGENCY DISCONNECT SYSTEM WARNING DOOR ARM IS RELEASED FROM TROLLEY Track WHEN EMERGENCY DISCONNECT OPENS. TO AVOID BEING STRUCK BY DOOR ARM, DO NOT STAND UNDER THE ROPE OR DOOR ARM WHEN PULLING THE EMERGENCY RELEASE. Clevis Emergency Chain Disconnect TO DISCONNECT DOOR Straight Emergency...

  • Page 8: Adjust Clutch

    ADJUST CLUTCH Adjust clutch so that it is tight enough to open and close the door but will slip when the door meets an Clutch Pad Adjusting Nut obstruction. Either loosen or tighten the clutch nut Spring with 1/4 turn increments. The clutch will require Clutch Plate periodic inspection and adjustment.
  • Page 9 1A3989, 1A4045, 1A4046 & 1A4047 BRAKE INSTALLATION & ASSEMBLY PARTS WARNING Clutch TO AVOID SERIOUS PERSONAL INJURY OR DEATH Pulley Cotter FROM ELECTROCUTION, DISCONNECT ELECTRICAL Shaft POWER TO OPERATOR BEFORE PROCEEDING. 3/4" Washer 1. Install brake drum on clutch pulley shaft as illustrated in Fig.

  • Page 10: Single Phase Wiring Diagram

    SINGLE PHASE WIRING DIAGRAM (For PC Board #14D0379) The Chamberlain Group, Inc. Brown Wiring Diagram Standard Duty 1Ø SENSING AUXILARY LIMIT DEVICE LIMIT (Reference Label 132B2041B) SWITCH SWITCH 4/28/91 - 6/1/91 - 6/11/91 - 6/15/91 6/27/91 - 7/1/91 - 7/12/91 - 7/22/91...
  • Page 11 SINGLE PHASE SCHEMATIC DIAGRAM (For P.C. Board #14D0379) Neutral 115v 1Ø Hot 115v 1Ø The Chamberlain Group, Inc. Schematic Diagram Standard Duty Single Phase Schematic White Black New PC Board Single Phase 8/23/91 - 8/27/91 - 9/2/91 - 9/5/91 Overload...
  • Page 12 MEMO:...
  • Page 13 MEMO:...
  • Page 14 WIRING KITS TYPE STATION B2, C2, D1, E2, T D1, E2 3 Button Function: Momentary contact to open, close and stop, plus wiring for sensing device to reverse and auxiliary devices to open and close with open override. B2, T, B2, C2, E2 T, TS B2, C2,...
  • Page 15 The Chamberlain Group, Inc. NEMA Motor Wiring Diagrams NEMA MOTOR WIRING DIAGRAMS 5/1/92 SINGLE VOLTAGE 1 PHASE 1/3 & 1/2 H.P. 115 V only 115V 115V 230V Motor Motor Motor T2 White Black T1 - Blue Yellow T4 Yellow Yellow...
  • Page 16 ILLUSTRATED PARTS - ELECTRICAL BOX...
  • Page 17 ELECTRICAL BOX PARTS LIST 2211 ITEM PART NO. DESCRIPTION 1B3727 Terminal Assy. 3-Lug 41K4304 Switch Bracket Assy. (Aux. & Sensing) 1B3796 Ltd. Shaft-Sprocket Assy. 1B3938 Cover & Hinge Assy. 1C3937 Electric Box Assy. 1D4017 Wire Harness 11A012 Flanged Sleeve Bearing 41K4303 Limit Bracket (Adj.) Kit 1B4062...
  • Page 18 ILLUSTRATED PARTS - OPERATOR MODEL APT...
  • Page 19 REPAIR PARTS FOR MODEL 2211 ITEM PART NO. DESCRIPTION Electrical Box Assy. (See detail) 1B4062 Motor Cable Assy. 123D141 Motor 1/2 hp 115V 1 Phase 1C3972 Motor Plate Assy. 1A3971 Chain Assy. (49 Pitches) 1B3632 Sprocket-Hub Assy. 13-3/4 See Chart L-Rail 1B4001 Trolley Assy.
  • Page 20 TIMER DEFEAT SWITCH REMOVE JUMPER TIMER 2 OR MORE WIRING TYPES - B2, C2, D1, E2, T & TS WIRING TYPES - ALL WIRING TYPES - T & TS © 1992, The Chamberlain Group, Inc. 114A1662B All Rights Reserved Printed in Mexico...
